Installation Manual

 Type：DC-DC converter（Families：PSD, SD, RSD）

 Introduction

A DC-DC converter is a device used to convert a DC source from one voltage level to another. Mean Well’s DC-DC

converters equipped with internal EMI filter stage that possess the required EMC performance.

 Installation

（1）Before commencing any installation or maintenance work, please disconnect your system from the

utility. Ensure that it cannot be re-connected inadvertently!

（2）For PCB type, at least 5mm insulation distance around the unit should be kept.

（3）Allow good ventilation for the unit in use to prevent it from overheating. Also, a 10-15 cm clearance

must be kept when the adjacent device is a heat source.

（4）Mounting orientations other than standard orientation or operate under high ambient temperature

may increase the internal component temperature and will require a de-rating in output current.

Please refer to the specification sheets to receive the optimum mounting position and information

about the de-rating curve.

（5）Recommended input/output wires are shown as below.

AWG

Rated Current of

Equipment (Amp)

6-10A

10-16A

16-25A

25-32A

32-40A

Cross-section of

Lead(mm

)

0.75

1.00

1.5

2.5

Note: Current each wire carries should be de-rated to 80% of the current

suggested above when using 5 or more wires connected to the unit.

（6）For PCB type, compatible mating housing please refers to the specifications

（7）For enclosed type, make sure that all strands of each stranded wire enter the terminal connection and the

screw terminals are securely fixed to prevent poor contact.

（8）For other information about the products, please refer to www.meanwell.com for details.

 Warning / Caution !!

（1）Risk of electrical shock and energy hazard. All failure should be examined by a qualified technician.

Please do not try to fix the converter by yourself!

（2）Risk of irreparable damage. Do not reverse polarity, both input and output.

（3）Please do not install converters in places with high moisture or near the water.

（4）Please do not install converters in places with high ambient temperature or near fire source. Please

refer to the specifications about the maximum ambient temperature limitations.

（5）Output current and output wattage must not exceed the rated values on specifications.

（6）The ground (FG) must be connected to earth ground.

（7）For system considerations, PCB and enclosed type converters may require an additional inrush

current limiting circuit to suppress high inrush current surges. If you are uncertain about that circuit,

contact Mean Well.

（8）All of Mean Well’s converters are designed in accordance with EMC regulations and the related test reports

are available by request. Since they are belong to component power supplies and will be installed inside

system enclosure, when they are integrated into a system, the EMC characteristics of the end system must be

re-verified again.

Produktspecifikationer

Varumärke:	Mean Well
Kategori:	Inte kategoriserad
Modell:	RSD-60H-12
Vikt:	290 g
Bredd:	60 mm
Djup:	128 mm
Höjd:	25 mm
Uteffekt:	5 A
Spänning:	40 - 160 V
Antal per förpackning:	48 styck
Hållbarhetscertifiering:	RoHS
Utgångsspänning:	12 V
