PAT120

Portable Appliance Tester

User Guide

WWW.MEGGER.COM

www.megger.com

Contents

Unpacking the carton 3

Safety warnings 4

Symbols used on the instrument 5

Symbols used on the connection panel 6

Instrument layout 6

Display information

Measurement symbols

Instrument buttons

User guide instruction symbols

Carry strap ﬁtting and removal 9

Switching ON / OFF 10

Class I test using substitute leakage @ 40 V ac

Class II test Using Substitute Leakage @ 40 V ac

Power cord test

Extension lead test

Fail handling 15

Factory default settings 16

Battery and fuse replacement 17

Battery replacement

Fuse replacement

Preventive maintenance 18

Speciﬁcation 18

www.megger.com

Thank you for purchasing the Megger portable appliance tester.

For your own safety and to get the maximum beneﬁt from your instrument, please ensure that you read and understand the safety warnings and instructions before attempting to use the

instrument.

These instruments are designed and manufactured by:

Megger Instruments Limited

Archcliffe Road

Dover Kent

CT17 9EN

England

Megger Instruments Limited reserves the right to change the speciﬁcation of these instruments at any time without prior notice.

Unpacking the carton

Unpack the carton contents carefully. There are important documents that you should read and keep for future reference.

Please complete the pre-paid warranty card and return it to Megger Limited as soon as possible to help us reduce any delays in supporting you should you need assistance.
