Sida 1/2
SIA10
Mains test lead
Multifunction testers
and RCD testers
DESCRIPTION
BS1363 plug test lead with a single 3-core
cable terminated in red, blue and green 4 mm
right-angled shrouded safety plugs for direct
connection of a test instrument to a 13 A UK
wall-socket.
Ideal for installation testing in accordance with
BS7671 17th Edition wiring regulations.
IDEAL FOR
MFT1700 series
MFT1800 series
RCDT series
LRCD series
INCLUDED
SIA10 mains test lead
SPECIFICATION
Safety rating:
IEC61010-031 CAT II 300 V
Test end:
BS1363 13 A UK mains plug with fuse.
Instrument end:
4 mm right-angled shrouded safety plugs
Fuse rating:
10 A mains plug fuse to BS1362
User-replaceable
Lead length:
1.3 m (approx.)
Cable construction:
Flexible single cable with 3-core copper conductors.
PVC insulation has different colour inner layers to aid
identification of physical damage.
SIA10
Mains test lead
Multifunction testers
and RCD testers
Product Order Code
SIA10 1004-323B
ORDERING INFORMATION
Megger Limited Archcliffe Road Dover CT17 9EN
T: 01304 502101 F: 01304 207342 E: uksales@megger.com
The company reserves the right to change the
specification or design without prior notice.
Megger is a registered trademark
Part No. 1004-323--2002-084_UG_en_V03
www.megger.com
User guide
Megger test leads have been designed to be safe
when used with original Megger equipment for
which they have
been designated as an approved accessory. All
models are safety rated to IEC 61010-031 over-
voltage category rating and maximum voltage as
marked on the leadset.
G Refer to this User Guide
t Double insulated Class II
c Complies with relevant EU
directives
IEC 61010-2-030 defines measurement
categories I to IV relating to transient
overvoltages and locations within
electrical installations. An example of
category II is a mains socket outlet,
category III is the wiring between the
socket outlets and the consumer unit,
category IV is the supply to the
consumer cut-out from the distribution
network transformer.
For further information on category
ratings visit the relevant product page
on www.megger.com
G Safety Warnings
All safety warnings and precautions
provided with the original Megger
equipment to be used with these leads
must be read and understood before
these test leads are used. They must
be observed during use.
(Safety Warnings are provided within the user
guides for Megger test equipment, copies
available from www.megger.com)
n Check for damage before each
use.
n DO NOT USE if any part of this
lead or terminations are damaged.
n Replacement fuses must be of the
correct type and rating as marked
on the leadset.
n The safety rating of any
combination of instrument and
leadset is taken as the lowest
category rating statement visible
when in use.
n Use of non-Megger test lead
accessories including probe tips,
covers and clips will invalidate the
safety category rating of the leadset.
NOTE
THESE TEST LEADS MUST ONLY
BE USED BY SUITABLY TRAINED
AND COMPETENT PERSONS
Fused test leads may have different
resistance values to standard non-fused
test leads. It is important to adjust the
null-offset value on the instrument prior
to use. Refer to the instrument manual
for instructions.
Users of this equipment and/or their
employers are reminded that Health
and Safety Legislation requires them
to carry out valid risk assessments of
all electrical work so as to identify
potential sources of electrical danger
and risk of electrical injury such as
inadvertent short circuits. Where the
assessments show that the risk is
significant then the use of fused test
leads constructed in accordance with
the HSE guidance note GS38 ‘Electrical
Test Equipment for use by Electricians’
should be considered.
Clean with a damp cloth when
necessary and ensure item is dry prior
to use.
