TDR1000/3
TDR1000/3P
CFL510G
TDR500/3
Time Domain Reflectometers
User Manual
2
CONTENTS
Introduction 6
Overview 8
Instrument layout and display 8
Controls 10
Rotary switch 10
Range and cursor control 11
Backlight and hold 12
Setup 13
Operation 14
General testing procedure 14
Operating modes 14
Connection to cable under test 15
Velocity factor 17
Pulse widths 18
Techniques 19
Test the cable from both ends 19
Care and maintenance 19
Battery 20
Battery replacement 20
Battery indicator 21
Specifications 22
Waste electrical and electronic equipment 24
Test Lead selection 26
Repair and warranty 27
Megger contact information 29
3
G SAFETY WARNINGS
Safety warnings and precautions must be read and understood before the instrument is used. All Safety warnings and
precautions must be observed during use.
The circuit under test must be switched off, de-energised, securely isolated and proved safe before test connections are
made.
Use the correct lead set. On power systems the Megger fused lead set must be used. Refer to the Test Lead selection page in
this user guide to identify the correct lead set.
The operator must verify that the circuit is safe before testing and take the appropriate precautions.
Ensure that hands remain behind guards of probes/clips when testing.
The instrument should not be used if any part of it is damaged. Also all test leads, probes and crocodile clips must be in good
order, clean and with no broken or cracked insulation.
Disconnect the test leads before removing the battery cover. The battery cover must be in place whilst conducting tests.
This product contains no user service parts.
All relevant safety procedures must be followed.
THE INSTRUMENT MUST ONLY BE USED BY SUITABLY
TRAINED AND COMPETENT PERSONS
