Sida 1/8

• This hob is intended for domestic cooking only. It is not designed for

commercial or industrial purposes.

• This appliance is not connected to a combustion products evacuation device.

It must be installed and connected in accordance with current installation

regulations. Particular attention shall be given to the relevant requirements

regarding ventilation.

• When in use a gas cooking hob will produce heat and moisture in the room

in which it has been installed. Ensure there is a continuous air supply, keeping

air vents in good condition or installing a cooker hood with a venting hose.

• Ensure a good ventilation around the appliance. A poor air supply could cause

lack of oxygen.

• This hob is designed to be operated by adults. Do not allow children to play

near or with the hob.

• This appliance is not intended for use by children or other persons whose

physical, sensory or mental capabilities or lack of experience and knowledge

prevents them from using the appliance safely without supervision or instruction

by a responsible person to ensure that they can use the appliance safely.

• The hob gets hot when it is in use. Children should be kept away until it has

cooled.

• Children can also injure themselves by pulling pans or pots off the hob.

When using the hob for a long period time, the ventilation should be

improved, by opening a window or increasing the extractor speed.

• Do not use this hob if it is in contact with water. Do not operate the hob with

wet hands Ensure the control knobs are in the ‘OFF’ position when not in use.

• When using other electrical appliances, ensure the cable does not come

into contact with the hot surfaces of the cooking appliance.

• Unstable or misshapen pans should not be used on the hob as unstable

pans can cause an accident by tipping or spillage.

• Never leave the hob unattended when cooking with oil and fats.

• Never use plastic or aluminium foil dishes on the hob.

• Perishable food, plastic items and areosols may be affected by heat and

should not be stored above or below the hob unit.

• This appliance cannot be cleaned with steam or with a steam cleaning

machine.

During Use

Child Safety

INDEX

Safety information..................................................................................

Models..................................................................................................

Gas connection......................................................................................

Insruction for use................................................................................

Cleaning and maintaining.....................................................................

Installation..........................................................................................

Installation instructions......................................................................

Using the hob corretly...........................................................................

3-4

5-6

7-8

9-10

Important Safety Information.................................................................12

Chıld Safety...........................................................................................13

Thank you for choosing our appliance. Before using the appliance, please read the warnings

and instructions in this manual. This will make it easier to operate and also prolong its service life.

Keep this booklet for further reference.

Safety information

a) The appliance is preset to 230 volt.

b) Because of the fact that the appliance of the plug is earthed plug, you have to use an

earthed socket too.

c) Pay attention to move the cable away from the hot surfaces.

d) Make sure that the gas pipe is conformable to standarts of your country and pay

attention to move the gas pipe away from the hot surfaces and to use soapsuds to

check whether there is a leakage of gas.

e) After clamping gas pipe with nozzle, fix it with pipe clip. Use soapsuds again to check

if there is a leakage of gas.

f) Make sure that LPG gas regulator that you will use for your appliance is conformable to

output pressure is 300mmHg (30mbar).

g) Natural gas pressure is 250mmHg (25mbar).

To convert your appliance to natural gas, please contact the technical service.

h) Make your fixture of appliance in the shortest and most air tight form. For your

safety, gas pipe must be shorter than 120 cm. A new additional ventilation might be

required depending on overuse. For this you use can use air conditioning system like

a suction device or admit fresh air into the room.

i) services can deal with it in return for a very little amount of payment when

the natural gas transformation is required for your appliance.

j) Contact us when you have any difficulty in using appliance.

When the feeder cable is damaged, this cable must be replaced with a special cable or

a set of cables which is provided from the manufacturer or the service

Note: Even if, it is normal or durable, change your gas pipe in every 4-5 years.

Do not expose the gas pipe to extra overweight and exposure strokes.

Do not strike pan to the burner.

Use pans whose diameter is proportional in size to that of burners. Use small

based pan for small diameter burner, use large based pan for large diameter burner.

Do not leave sharp materials on hob.

Pay attention that dropping the pan.

Note: You can regulate the flame by turning the button between large flame and low

flame.

Use 12-18 cm diameter of pan for auxiliary gas burner.

Use 24-28 cm diameter of to pan for powerful gas burner.

Do not use a pan that convey excess heat directly glass surface.

Fix the pan on the centre of burner.

Do not put sharp materials on the hob.

•

You MUST read these warnings carefully before installing or using the hob.

This appliance must be installed and serviced by a competent person as stated in the

Gas Safety (Installation and Use) Regulations Current Editions and the IEE Wiring

Regulations.

For appliances installed in the Republic of Ireland please refer to NSAIDomestic

Gas Installations I.S.813 Current Editions and the ETCI Rules for Electrical Installations.

Remove all packaging before using the hob.

Ensure that the gas and electrical supply complies with the type stated on the rating

plate,located near the gas supply pipe.

Do not attempt to modify the hob in any way.competent person, and in accordance

with existing rules and regulations.

The relevant instructions are to be found in the second section of this manual.

Please, ensure that, once the hob is installed, it is easily accessible for the engineer in

the event of a breakdown.

Once the hob has been installed, it is important to remove any protective

materials, which were put on in the factory.

The manufacturer will not accept liability, should the above instructions or

any of the other safety instructions incorporated in this book be ignored.

•

Important Safety Information

Installation

Environmental Information

After installation, please dispose of the packaging with due regard to safety and the

environment.

• When disposing of an old appliance, make it unusable, by cutting off the cable.

• The symbol on the product or on its packaging indicates that this product may

not be treated as household waste. Instead it shall be handed over to the applicable

collection point for the recycling of electrical and electronic equipment. By ensuring this

product is disposed of correctly you will help prevent potential negative consequences

for the environment and human health, which could otherwise be caused by inappropriate

waste handling of this product.For more detailed information about recycling of this

product,please contact your local city office,your household waste disposal service or the

shop where you purchased the product.

WHEN THE HOB IS FIRST INSTALLED

Produktspecifikationer

Varumärke:	Meireles
Kategori:	Spis
Modell:	MVG 4650 N NAT
Inbyggd display:	Nej
Timer:	Nej
Bredd:	- mm
Djup:	- mm
Höjd:	- mm
Elektronisk tändning:	Ja
Antal gasbrännare:	4
Produktens färg:	Svart
Kontrolltyp:	Rotations-
Wok brännare:	Ja
Apparatens placering:	Inbyggd
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	4
Kokzon 3, form:	Rund
Placering av platta/tillagningsyta 4:	Höger fram
Typ av platta/tillagningsyta 4:	Vanlig
Typ av platta/tillagningsyta 3:	Vanlig
Kokzon 1, form:	Rund
Placering av platta/tillagningsyta 3:	Höger bak
Kokzon 2, form:	Rund
Strömförsörjning till platta/tillagningsyta 3:	gas
Typ av platta/tillagningsyta 1:	Extra stor
Placering av platta/tillagningsyta 2:	Främre till vänster
Strömförsörjning till platta/tillagningsyta 4:	gas
Strömförsörjning till platta/tillagningsyta 2:	gas
Typ av platta/tillagningsyta 2:	Sjudning
Kokzon 4, form:	Rund
Strömförsörjning till platta/tillagningsyta 1:	gas
Placering av platta/tillagningsyta 1:	Vänster bak
Manöverplats:	Övre främre
Effekt på platta/tillagningsyta 1:	4000 W
Effekt på platta/tillagningsyta 2:	1000 W
Effekt på platta/tillagningsyta 3:	1750 W
Effekt på platta/tillagningsyta 4:	1750 W
Typ av ytskikt:	Keramiska
Anslutningseffekt (gas):	8300 W
Material i hällstativ:	Gjutjärn
Wokbrännarens effekt:	4000 W
Gastyp:	Gasol (LPG)
