Sida 1/5

D I O

S M C 2 A

A P P C O N T R O D H I D E A W A Y H E A D L L E U N I T

SHOW Y ST L US OUR IN AL

WWW E I SA.M MPHISCARAUD O.U

@MEMPH ARAUDISC IO

Electronics limited warranty (including Memphis accessories) When purchased from an Authorized Memphis Dealer, Memphis warrants this product to be free from

defects in material and workmanship under normal use for a period of ONE (1) YEAR from date of original purchase (receipt required),THREE (3)YEARS years if installed by

an authorized Memphis dealer (receipt required). If this product is identified as “Refurbished” or “B Goods”, the warranty is limited to a period of THREE (3) MONTHS from

date of original purchase. In all cases you must have the original receipt. Should service be necessary under this warranty for any reason due to manufacturing defect or

malfunction during the warranty period, Memphis will repair or replace (at its discretion) the defective merchandise with equivalent merchandise. Warranty replace-

ments may have cosmetic scratches and blemishes. Discontinued products may be replaced with more current equivalent products. Warranty is valid only for the original

purchaser and is not extended to owners of the product subsequent to the original purchaser. Any applicable implied warranties are limited in duration to a period of the

express warranty as provided herein beginning with the date of the original purchase at retail, and no warranties, whether express or implied, shall apply to this product

thereafter. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving

antenna. Increase the separation between the equipment and the receiver. Connect the equipment into an outlet or a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to this unit not expressly approved by the part responsible for

Compliance could void the user's authority to operate the equipment.

FCC Radiation Exposure Statement

This equipment complied with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum

distance 20cm between the radiator & your body.

Warranty

The SMC2A is an extremely innovative solution for creating a complete audio experience in your vehicle without the need to alter

your vehicles dash to accommodate an aftermarket head unit. Much more than a simple Bluetooth controller, this is an entire head

unit packed into a hideaway box. The SMC2A features a built-in 50x4 amplifier, 5 source options, and front /rear /subwoofer RCA

outputs allowing you to build your entire system directly off the unit. The hideaway box is controlled via the Memphis APP allowing

you to control your EQ, AM/FM presets, RGB LEDs and more. The attached wired remote fits in standard knock out locations but is not

required. This is the ultimate for powersports, marine, hot rod and classic car audio integration where you don’t want to alter the

appearance of your dash.

• 5 Source options: AUX, BT, AM/FM, Weatherband • RGB color source chart

• USB Charging

Color Source

Red FM

Yellow AM

Purple WB

Blue Bluetooth

Green AUX

• 50w x 4 built-in amplifier

• RGB LED control output

• Front/Rear/Subwoofer RCA output

• 2.5-Volt preamp output

• Conformal coated PCB IP66 rated

• Wired remote fits standard rocker switch cutout

• Wired remote w/ illuminating buttons

The Headless Unit

Features

• RGB Settings

• Custom EQ settings

• Balance, fade

• AM/FM Preset Control

• Radio search settings

• Manual/Seek/Presets

App Controls The Following

6.73”

171MM

2.067”

52.5MM

3.84”

97.5MM

POWER/AUDIO OUTPUTS

CONNECTIONS

1. Front Outputs

2. Rear Outputs

3. Subwoofer Outputs

4. USB For Charging

5. Antenna Input

6. Power/Audio Outputs

7. Line Input

8. RGB LED Output

9. Remote Control 1

10. In-Line 15A Fuse and Fuse Holder

11. Remote Control 2

610

789

Red// 12V+ Ignition

Black // Ground

Blue // Remote Turn On

Yellow // B+ Battery

White & Black // Left Front Speaker (-)

White // Left Front Speaker (+)

Grey & Black // Right Front Speaker (-)

Grey // Right Front Speaker (+)

Green & Black // Left Rear Speaker (-)

Green // Left Rear Speaker (+)

Purple & Black // Right Rear Speaker (-)

Purple // Right Rear Speaker (+)

*Note: Mounting depth is 90mm but room is required for wires and connections. Check available depth prior to mounting.

Measure before cutting and be certain you will not be drilling into any items that will damage your vehicle.

Wiring Overview

Dimensions
