www.avsl.com 910120.UK User Manual

Outdoor Amplified HDTV Aerial

for Caravans and Boats

Order ref: 120.910 UK

User Manual

Outdoor HDTV aerial specially designed for camping and marine use and compatible with Digital

Terrestrial TV and DAB/FM radio signals. The built-in amplifier gives a clear picture even if the signal

reception is weak. Can be mounted on a pole of up to 38mmØ using the clamp supplied.

Specification:

Frequency ran (U) geHF

470MHz - 694MHz(5G)

Frequency ran (V) geHF

40MHz - 230MHz

Impedance

75Ω

Gain (UHF/VHF)

20 dB

Max loss

2dB

Output level

100dBµV max.

Power supply

100-240Vac~50/60Hz 0.15A Max / 12Vdc-0.2A 2.4W

Dimensions

260 x 334 x 80mm

Weight

1.5kg

Features:

•Compatible with Digital Terrestrial TV and DAB/FM radio signals.

•Ideal f installation on caravans, campers or boats. or

•Unidirectional with built-in high gain amplifier.

•Integrated LTE signal filter avoids interference from 4G/5G mobile signals

•Features a splitter to connect a second radio or TV set.

•Supplied with mounting materials, 6m connection cable and power supply.

Ithe box: n

•Antenna main unit

•Mast clamp

•Water-proof boot

•Power insert

•DC cord

•AC/DC adapter

•Coaxial cable 6m

•1.2m TV cable with RF male and F

connector

Installation:

1.Connecting the mast xture to the antennafi: Use the 2 screws supplied, connect the mast

fixture to the antenna body and tighten it securely (see Fig 1).

2.Power supply cord connection: Connect the coaxial cable to the ampli input. Plug the F fier

connector to the socket on the bottom of the antenna and push the water-proof kit over it. Choice of

AC mains powered or 12/24V DC powered (see Fig 2).
