www.avsl.com 525 User Manual 120. UK

Portable UHF Mast Aerial

for HDTV with Magnetic Base

Order ref: 120.525 UK

User Manual

Designed specifically for digital HDTV reception, this compact and lightweight aerial is perfect for portable

TV's and laptop TV tuners. Its magnetic base enables you to use the surface area of large metal objects to

enhance reception quality and makes it perfect for use on the roof of a car, truck, campervan or

motorhome. Simple to install with its 3m lead making positioning for the best signal quality a breeze, this

small yet powerful aerial is the perfect solution for both home and travel.

Specification:

Frequency ran : UHF ge

470-862MHz

Impedance

75Ω

Gain

2- 4 dB

Lead length

Dimensions

160 x 70 x 70mm

Weight

100g

Features:

• Compact, portable and lightweight design that's ideal for travel and easy to position for ultimate

signal performance.

• Optimized for digital reception - receives Digital Terrestrial TV broadcasts with ease.

• The magnetic base means it can be placed on metal surfaces to increase signal reach and reception

• Simple plug and play setup and operation.

• Extra long 3m RF (Coaxial) lead - ideal for attaching to the roof of trucks, cars, campervans and

motorhomes.

Connection and operation:

1. First connect the aerial’s coaxial lead either directly to the back of your Digital or Terrestrial set TV

top box.

www.avsl.com User Manual 120.525UK

2. Place the aerial in your desired location, for the best indoor reception try and position as high as

possible and away from large power consuming devices such as air-conditioning units, elevators,

microwave ovens, hair dryers etc.

3. For the best outdoor reception attach the aerial using the magnetic base to the roof of your vehicle

or camper/caravan. Try and place it as high and as far as possible away from any large objects that

could interrupt the signal from the nearest transmission tower.

4. Finally run the channel scan operation on your device and once complete test the quality of the

channels. It may be necessary to reposition the aerial and try again if the signal quality is low or you

are receiving interference or missing channels.

Safety warnings:

• Do not use this appliance it is damaged in any way. if

• Do not attempt to repair this appliance or take apart under any circumstances, as this will invalidate

your warranty.

• Please ensure you have read these instructions thoroughly before first e and keep them for future us

reference.

This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial was at the end te

of its useful life. The goods must be disposed of according to your local council guidelines.

Errors and omissions excepted.

Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
