METRA. The World’s best kits.™metraonline.com © COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
REV. 9/21/2015 INST95-7366B
Installation instructions for part 95-7366B
CAUTION!
Metra recommends disconnecting the negative bat
-
tery terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your local
Dealership for more information. All accessories, switches, climate
controls panels, and especially air bag indicator lights must be con-
nected before reconnecting the battery or cycling the ignition. Also,
do not remove the factory radio with the key in the on position, or the
vehicle running. It would be best to remove the key from the ignition
and then wait a few seconds before removing the factory radio.
• ISO DDIN radio provision
• Painted scratch resistant black
• A) Radio trim panel • B) Radio brackets
20;-,(;<9,:
20;*64765,5;:
>0905.(5;,55(*655,*;065: (sold separately)
Wiring Harness: • 70-7304, HYBL-04
Antenna Adapter: • Not required
• Panel removal tool • Phillips screwdriver • 10mm Socket wrench • Cutting tool
;663:9,8<09,+
Kia Sorento 2016-up
95-7366B
A B
Dash Disassembly ................................................. 2
Kit Preparation ....................................................... 2
Kit Assembly .......................................................... 3
Table of Contents
95-7366B
2
1.
Unclip and remove the factory radio
trim panel including the a/c vents.
(Figure A)
2. Remove (4) Phillips screws
securing the radio and then
remove. (Figure B)
Continue to kit preparation
Dash Disassembly
(Figure B)
(Figure A)
1. Cut the marked area in the
dash cavity. (Figure A)
2. Remove (1) 10mm nut holding the
area previously cut in step 1 to
remove the cut-out area.
Continue to kit assembly
Kit Preparation
(Figure A)
95-7366B
Kit Assembly
3
(Figure A)
ISO DDIN radio provision
1. Attach the radio brackets to the
radio using the screws supplied
with the radio. (Figure A)
2.
Locate the factory wiring harness
and antenna plug in the dash and
make all necessary connections to
the radio. Metra recommends using
the proper mating adapters from
Metra and/or AXXESS. Re-connect
the negative battery terminal and
test the radio for proper operation.
3. Secure the completed assembly
into the sub-dash using the factory
hardware.
4. Snap the 7366 radio trim panel
into the factory trim panel, and
then reassemble the dash in
reverse order of disassembly.
