Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 5/5/20 INST95-8733B
INSTALLATION INSTRUCTIONS
95-8733B
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DDIN radio provision
• Painted scratch resistant matte black
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Button housing • D) Button trim panel • E) Button blanks • F) Button panel hooks
• G) #4 x 3/8” Phillips screws (9) • H) Panel clips (2)
A B C
F F
G
D E
Mercedes-Benz C-class 2008-2011 (W204)
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• T-20 Torx driver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit assembly ...........................................................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: See metraonline.com or
axxessinterfaces.com for interface/harness.
Antenna Adapter: 40-EU56
386.257.1187
|
MetraOnline.com
2
1. Unclip the air vents, unplug and remove
(do not cycle the key while unplugged).
(Figure A)
2. Remove two T-20 Torx from the radio
and lift up on the two tabs located at
each mounting point. (See detail)
3. Slide the factory radio out paying
attention to the runners on the sides.
(Figure B)
(Figure D)
(Figure A) (Figure C)
DASH DISASSEMBLY
4. Unclip the trim at the bottom of the
radio and unscrew the factory buttons to
be relocated to the button trim panel in
kit assembly.
5. Remove two T-20 Torx screws from
the bottom of the factory radio screen
assembly and remove.
Continue to Kit Preparation
Detail
