Installation Instructions for AX-NIS40SWC-6VInstallation Instructions for AX-NIS40SWC-6V
INTERFACE FEATURES
• Pre-wired ASWC-1 harness (ASWC-1 sold separately)
• Retains the factory AUX-IN jack
• Retains the factory backup camera to an aftermarket radio
• Includes the AX-CAM6V 12-volt to 6-volt converter
AX-NIS40SWC-6V
Pre-wired ASWC-1 Harness
Nissan Maxima 2016-up(without amp)
INTERFACE COMPONENTS
• AX-NIS40SWC-6V harness • AX-CAM6V 12-volt to 6-volt converter
• Wire cutter • Crimping tool • Solder gun • Tape
• Connectors (example: butt connectors, bell caps, etc.)
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Connections to be made
• Connect the Black wire with a ring terminal to chassis ground.
• Connect the Black wire of the AX-CAM6V wire to chassis ground.
• Connect the Red Blue/Red wire labeled "Camera Power 6V" to the wire
of the AX-CAM6V.
• Connect the Green/Purple wire to the reverse wire of the aftermarket radio,
and also to the wire of the AX-CAM6V.Blue/White
• Connect the Blue/Pink wire to the VSS/speed sense wire of the aftermarket radio
(if applicable).
• Connect the Light Green wire to the parking brake wire of the aftermarket radio
(if applicable).
• If retaining the factory AUX-IN jack, connect the & RCA jacks to Red White
the AUX input.
• Connect the Yellow RCA jack to the rear camera input of the aftermarket radio
.
12-pin pre-wired ASWC-1 harness:
This harness is to be used along with the optional ASWC-1 (not included) to
retain steering wheel audio controls. Please refer to the ASWC-1 instructions
for radio connections and programming.
Note: Disregard the harness that comes with the ASWC-1.
