APPLICATIONS
APPLICATIONS
APPLICATIONS
APPLICATIONS
INSTXSVI-2003-NAV REV. 06/28/10
1-800-221-0932 www.metraonline.com
METRA ELECTRONICS CORPORATION © COPYRIGHT 2010
INSTXSVI-2003-NAV REV. 06/28/10
1-800-221-0932 www.metraonline.com
METRA ELECTRONICS CORPORATION © COPYRIGHT 2010
INSTXSVI-2003-NAV REV. 06/28/10
1-800-221-0932 www.metraonline.com
METRA ELECTRONICS CORPORATION © COPYRIGHT 2010
INSTXSVI-2003-NAV REV. 06/28/10
1-800-221-0932 www.metraonline.com
METRA ELECTRONICS CORPORATION © COPYRIGHT 2010
BUICK
• ALLURE 2005-09
• CENTURY 2004-05
• LACROSSE 2005-09
• RAINIER 2004-07
• RENDEZVOUS 2002-07
• TERRAZA 2005-08
CHEVROLET
• AVALANCHE 2003-06
• CAVALIER 2000-05
• COLORADO 2004-10
• EXPRESS 2003-07
• IMPALA 2000-05
• MALIBU 2001-03
• MALIBU CLASSIC 2004-05
• MONTE CARLO 2000-05
• SILVERADO PICKUP
CLASSIC 2007
• SILVERADO PICKUP
(All Models) 2003-06
• SSR 2003-06
• SUBURBAN 2003-06
• TAHOE 2003-2006
• TRAILBLAZER 2002-09
• UPLANDER 2005-08
• VENTURE VAN 2000-05
GMC
• CANYON 2004-10
• ENVOY 2002-09
• SAVANNA FULL SIZE VAN
2003-07
• SIERRA CLASSIC 2007
• SIERRA 2003-2006
• YUKON/ YUKON XL 2003-06
HUMMER
• H3 2006-09
ISUZU
• ASCENDER 2003-08
• I SERIES PICKUPS 2006-08
OLDSMOBILE
• ALERO 2001-04
• BRAVADA 2002-05
• INTRIGUE 2002
• SILHOUETTE 2000-04
PONTIAC
• AZTEC 2001-05
* GRAND AM 2001-05
• GRAND PRIX 2004-08
• MONTANA SV6 (CANADA)
2005-08
• MONTANA 2000-05
• SUNFIRE 2000-05
SAAB
• 9-7X 2005-09
SATURN
• RELAY 2005-07
BUICK
• ALLURE 2005-09
• CENTURY 2004-05
• LACROSSE 2005-09
• RAINIER 2004-07
• RENDEZVOUS 2002-07
• TERRAZA 2005-08
CHEVROLET
• AVALANCHE 2003-06
• CAVALIER 2000-05
• COLORADO 2004-10
• EXPRESS 2003-07
• IMPALA 2000-05
• MALIBU 2001-03
• MALIBU CLASSIC 2004-05
• MONTE CARLO 2000-05
• SILVERADO PICKUP
CLASSIC 2007
• SILVERADO PICKUP
(All Models) 2003-06
• SSR 2003-06
• SUBURBAN 2003-06
• TAHOE 2003-2006
• TRAILBLAZER 2002-09
• UPLANDER 2005-08
• VENTURE VAN 2000-05
GMC
• CANYON 2004-10
• ENVOY 2002-09
• SAVANNA FULL SIZE VAN
2003-07
• SIERRA CLASSIC 2007
• SIERRA 2003-2006
• YUKON/ YUKON XL 2003-06
HUMMER
• H3 2006-09
ISUZU
• ASCENDER 2003-08
• I SERIES PICKUPS 2006-08
OLDSMOBILE
• ALERO 2001-04
• BRAVADA 2002-05
• INTRIGUE 2002
• SILHOUETTE 2000-04
PONTIAC
• AZTEC 2001-05
* GRAND AM 2001-05
• GRAND PRIX 2004-08
• MONTANA SV6 (CANADA)
2005-08
• MONTANA 2000-05
• SUNFIRE 2000-05
SAAB
• 9-7X 2005-09
SATURN
• RELAY 2005-07
BUICK
• ALLURE 2005-09
• CENTURY 2004-05
• LACROSSE 2005-09
• RAINIER 2004-07
• RENDEZVOUS 2002-07
• TERRAZA 2005-08
CHEVROLET
• AVALANCHE 2003-06
• CAVALIER 2000-05
• COLORADO 2004-10
• EXPRESS 2003-07
• IMPALA 2000-05
• MALIBU 2001-03
• MALIBU CLASSIC 2004-05
• MONTE CARLO 2000-05
• SILVERADO PICKUP
CLASSIC 2007
• SILVERADO PICKUP
(All Models) 2003-06
• SSR 2003-06
• SUBURBAN 2003-06
• TAHOE 2003-2006
• TRAILBLAZER 2002-09
• UPLANDER 2005-08
• VENTURE VAN 2000-05
GMC
• CANYON 2004-10
• ENVOY 2002-09
• SAVANNA FULL SIZE VAN
2003-07
• SIERRA CLASSIC 2007
• SIERRA 2003-2006
• YUKON/ YUKON XL 2003-06
HUMMER
• H3 2006-09
ISUZU
• ASCENDER 2003-08
• I SERIES PICKUPS 2006-08
OLDSMOBILE
• ALERO 2001-04
• BRAVADA 2002-05
• INTRIGUE 2002
• SILHOUETTE 2000-04
PONTIAC
• AZTEC 2001-05
* GRAND AM 2001-05
• GRAND PRIX 2004-08
• MONTANA SV6 (CANADA)
2005-08
• MONTANA 2000-05
• SUNFIRE 2000-05
SAAB
• 9-7X 2005-09
SATURN
• RELAY 2005-07
BUICK
• ALLURE 2005-09
• CENTURY 2004-05
• LACROSSE 2005-09
• RAINIER 2004-07
• RENDEZVOUS 2002-07
• TERRAZA 2005-08
CHEVROLET
• AVALANCHE 2003-06
• CAVALIER 2000-05
• COLORADO 2004-10
• EXPRESS 2003-07
• IMPALA 2000-05
• MALIBU 2001-03
• MALIBU CLASSIC 2004-05
• MONTE CARLO 2000-05
• SILVERADO PICKUP
CLASSIC 2007
• SILVERADO PICKUP
(All Models) 2003-06
• SSR 2003-06
• SUBURBAN 2003-06
• TAHOE 2003-2006
• TRAILBLAZER 2002-09
• UPLANDER 2005-08
• VENTURE VAN 2000-05
GMC
• CANYON 2004-10
• ENVOY 2002-09
• SAVANNA FULL SIZE VAN
2003-07
• SIERRA CLASSIC 2007
• SIERRA 2003-2006
• YUKON/ YUKON XL 2003-06
HUMMER
• H3 2006-09
ISUZU
• ASCENDER 2003-08
• I SERIES PICKUPS 2006-08
OLDSMOBILE
• ALERO 2001-04
• BRAVADA 2002-05
• INTRIGUE 2002
• SILHOUETTE 2000-04
PONTIAC
• AZTEC 2001-05
* GRAND AM 2001-05
• GRAND PRIX 2004-08
• MONTANA SV6 (CANADA)
2005-08
• MONTANA 2000-05
• SUNFIRE 2000-05
SAAB
• 9-7X 2005-09
SATURN
• RELAY 2005-07
XSVI-2003-NAV INSTALLATION INSTRUCTIONS
XSVI-2003-NAV INSTALLATION INSTRUCTIONS
XSVI-2003-NAV INSTALLATION INSTRUCTIONS
XSVI-2003-NAV INSTALLATION INSTRUCTIONS
NOTE: ASWC SOLD SEPERATELY
In the GM vehicles listed on back there are no 12 volt accessory wires in the fac-
tory radio harness making the installer run an accessory wire to the fuse box or
underneath the steering column when installing an aftermarket radio. The XSVI-
2003-NAV is designed to provide a 12 volt 10 amp switched accessory output
along with the rest of the wires needed to install an aftermarket radio. The R.A.P.
(Retained Accessory Power) function is retained by the XSVI-2003-NAV. Along
with OE equipped steering wheel controls using the steering wheel control output
of the aftermarket radio (if equipped).
The XSVI-2003-NAV also provides essential wires required for aftermarket
radios that have navigation. Provided is VSS (Vehicle Speed Sense), Reverse,
and Parking Brake. This cuts down the installation time since the installer does
not have to look for these wires in the vehicle.
NOTE: The XSVI-2003-NAV does not retain the factory warning chimes that are
provided by the factory radio, Onstar, or the factory amplier if so equipped.
Wiring the XSVI-2003-NAV
Wiring up the XSVI-2003-NAV is like wiring up any other wire harness that would
attach to the aftermarket radios harness. The Metra/EIA wire code can be found
on the back of this package that will aid you in the wiring of your aftermarket
radio.
Navigation wire colors:
Blue/Pink – VSS (Vehicle Speed Sense)
Green/Violet – Reverse
Lt. Green – Parking Brake
Once all connections have been made, plug in the aftermarket radio if not done
already.
Do not plug in the ASWC into the XSVI harness yet.
Initialize the XSVI interface
With all connections made and harnesses connected to the vehicle, turn the igni-
tion key to the ON position for thirty seconds, then turn the key off.
After the XSVI is initialized, plug in the ASWC and refer to the ASWC instructions.
NOTE: ASWC SOLD SEPERATELY
In the GM vehicles listed on back there are no 12 volt accessory wires in the fac-
tory radio harness making the installer run an accessory wire to the fuse box or
underneath the steering column when installing an aftermarket radio. The XSVI-
2003-NAV is designed to provide a 12 volt 10 amp switched accessory output
along with the rest of the wires needed to install an aftermarket radio. The R.A.P.
(Retained Accessory Power) function is retained by the XSVI-2003-NAV. Along
with OE equipped steering wheel controls using the steering wheel control output
of the aftermarket radio (if equipped).
The XSVI-2003-NAV also provides essential wires required for aftermarket
radios that have navigation. Provided is VSS (Vehicle Speed Sense), Reverse,
and Parking Brake. This cuts down the installation time since the installer does
not have to look for these wires in the vehicle.
NOTE: The XSVI-2003-NAV does not retain the factory warning chimes that are
provided by the factory radio, Onstar, or the factory amplier if so equipped.
Wiring the XSVI-2003-NAV
Wiring up the XSVI-2003-NAV is like wiring up any other wire harness that would
attach to the aftermarket radios harness. The Metra/EIA wire code can be found
on the back of this package that will aid you in the wiring of your aftermarket
radio.
Navigation wire colors:
Blue/Pink – VSS (Vehicle Speed Sense)
Green/Violet – Reverse
Lt. Green – Parking Brake
Once all connections have been made, plug in the aftermarket radio if not done
already.
Do not plug in the ASWC into the XSVI harness yet.
Initialize the XSVI interface
With all connections made and harnesses connected to the vehicle, turn the igni-
tion key to the ON position for thirty seconds, then turn the key off.
After the XSVI is initialized, plug in the ASWC and refer to the ASWC instructions.
NOTE: ASWC SOLD SEPERATELY
In the GM vehicles listed on back there are no 12 volt accessory wires in the fac-
tory radio harness making the installer run an accessory wire to the fuse box or
underneath the steering column when installing an aftermarket radio. The XSVI-
2003-NAV is designed to provide a 12 volt 10 amp switched accessory output
along with the rest of the wires needed to install an aftermarket radio. The R.A.P.
(Retained Accessory Power) function is retained by the XSVI-2003-NAV. Along
with OE equipped steering wheel controls using the steering wheel control output
of the aftermarket radio (if equipped).
The XSVI-2003-NAV also provides essential wires required for aftermarket
radios that have navigation. Provided is VSS (Vehicle Speed Sense), Reverse,
and Parking Brake. This cuts down the installation time since the installer does
not have to look for these wires in the vehicle.
NOTE: The XSVI-2003-NAV does not retain the factory warning chimes that are
provided by the factory radio, Onstar, or the factory amplier if so equipped.
Wiring the XSVI-2003-NAV
Wiring up the XSVI-2003-NAV is like wiring up any other wire harness that would
attach to the aftermarket radios harness. The Metra/EIA wire code can be found
on the back of this package that will aid you in the wiring of your aftermarket
radio.
Navigation wire colors:
Blue/Pink – VSS (Vehicle Speed Sense)
Green/Violet – Reverse
Lt. Green – Parking Brake
Once all connections have been made, plug in the aftermarket radio if not done
already.
Do not plug in the ASWC into the XSVI harness yet.
Initialize the XSVI interface
With all connections made and harnesses connected to the vehicle, turn the igni-
tion key to the ON position for thirty seconds, then turn the key off.
After the XSVI is initialized, plug in the ASWC and refer to the ASWC instructions.
NOTE: ASWC SOLD SEPERATELY
In the GM vehicles listed on back there are no 12 volt accessory wires in the fac-
tory radio harness making the installer run an accessory wire to the fuse box or
underneath the steering column when installing an aftermarket radio. The XSVI-
2003-NAV is designed to provide a 12 volt 10 amp switched accessory output
along with the rest of the wires needed to install an aftermarket radio. The R.A.P.
(Retained Accessory Power) function is retained by the XSVI-2003-NAV. Along
with OE equipped steering wheel controls using the steering wheel control output
of the aftermarket radio (if equipped).
The XSVI-2003-NAV also provides essential wires required for aftermarket
radios that have navigation. Provided is VSS (Vehicle Speed Sense), Reverse,
and Parking Brake. This cuts down the installation time since the installer does
not have to look for these wires in the vehicle.
NOTE: The XSVI-2003-NAV does not retain the factory warning chimes that are
provided by the factory radio, Onstar, or the factory amplier if so equipped.
Wiring the XSVI-2003-NAV
Wiring up the XSVI-2003-NAV is like wiring up any other wire harness that would
attach to the aftermarket radios harness. The Metra/EIA wire code can be found
on the back of this package that will aid you in the wiring of your aftermarket
radio.
Navigation wire colors:
Blue/Pink – VSS (Vehicle Speed Sense)
Green/Violet – Reverse
Lt. Green – Parking Brake
Once all connections have been made, plug in the aftermarket radio if not done
already.
Do not plug in the ASWC into the XSVI harness yet.
Initialize the XSVI interface
With all connections made and harnesses connected to the vehicle, turn the igni-
tion key to the ON position for thirty seconds, then turn the key off.
After the XSVI is initialized, plug in the ASWC and refer to the ASWC instructions.
Produktspecifikationer
| Varumärke: | Metra |
| Kategori: | bilkit |
| Modell: | XSVI-2003-NAV |
Behöver du hjälp?
Om du behöver hjälp med Metra XSVI-2003-NAV ställ en fråga nedan och andra användare kommer att svara dig
bilkit Metra Manualer
15 Oktober 2025
15 Oktober 2025
14 Oktober 2025
14 Oktober 2025
14 Oktober 2025
14 Oktober 2025
14 Oktober 2025
14 Oktober 2025
14 Oktober 2025
14 Oktober 2025
bilkit Manualer
Nyaste bilkit Manualer
15 Oktober 2025
3 Oktober 2025
30 September 2025
30 September 2025
30 September 2025
29 September 2025
27 September 2025
27 September 2025
26 September 2025
23 September 2025
