Job Number:_____________________________________________ Location: ____________________________________________________________________ ____
• Add European style while creating dispense excitement
• Condition the glass before pouring – invert glass, push down on sprayer
for cold water rinsing
• Robust 18 gauge stainless steel construction
• Welded corners, nished smooth for safety and appearance
www.micromatic.com • 1 (866) 327-4159
SURFACE MOUNT SERIES 5" X 24"
DRIP TRAY
5" WIDTH TRAY WITH GLASS RINSER
DP-120D-24GR
Brushed Stainless Steel
NSF Certied
(Rinser Only)
Specifications
Central
10726 North Second St.
Machesney Park, IL 61115
Tel. (815) 968-7557
Fax. (815) 968-0363
Southeast
2364 Simon Ct.
Brooksville, FL 34604
Tel. (352) 799-6331
Fax. (352) 796-2429
Northeast
4601 Saucon Creek Rd.
Center Valley, PA 18034
Tel. (610) 625-4464
Fax. (610) 625-4466
West
19791 Bahama St.
Northridge, CA 91324
Tel. (818) 701-9765
Fax. (818) 701-9844
Toll-Free: 1-866-327-4159
www.micromatic.com
©2016 Micro Matic USA, Inc. All Rights Reserved.
Dimensions
Rinser Water Inlet Installation
• Always check local plumbing codes first.
• Install in-line water regulator set at 15 PSI from the street water supply (no greater, perfect operating pressure).
• Install in-line one way check valve from the street water supply (prevents pressure drop which can cause leaking).
• Install in-line shut-off for the rinser system from the street water supply (this must be turned off nightly).
• If teed into soda system make sure system can handle the increased water demand. Have plumber install a
45° 1/2" O.D. barb for the drains if line is not hard plumbed into the system.
• Install a shut-off for the rinser water supply if line is not hard plumbed into the system.
Micro Matic reserves the right to change specifications without notice.
000041S-D0216
127mm
5"
64mm
2 1/2"
64mm
2 1/2"
19mm
3/4"
305mm
12"
610mm
24"
140mm
5 1/2"
Part No. Dimensions Description Shipping Weight Box Dimensions
DP-120D-24GR 5"W x 24"L x 3/4"H Stainless Steel TBD TBD
Drain:
Threaded Brass
3 1/2" x 5/8" - 18
1/2" O.D.
7/8" - 14
1/2" BSP
3 3/4" Dia.
GR-1561
