© 2006-2012 Microchip Technology Inc. DS70183D-page 16-1
Analog-to-Digital
Converter (ADC)
16
Section 16. Analog-to-Digital Converter (ADC)
HIGHLIGHTS
This section of the manual contains the following major topics:
16.1 Introduction .................................................................................................................. 16-2
16.2 Control Registers ......................................................................................................... 16-6
16.3 Overview of Sample and Conversion Sequence ....................................................... 16-17
16.4 ADC Configuration..................................................................................................... 16-27
16.5 ADC Interrupt Generation .......................................................................................... 16-33
16.6 Analog Input Selection for Conversion....................................................................... 16-35
16.7 Specifying Conversion Results Buffering for Devices with DMA................................ 16-44
16.8 ADC Configuration Example ...................................................................................... 16-48
16.9 ADC Configuration for 1.1 Msps ................................................................................16-49
16.10 Sample and Conversion Sequence Examples for Devices without DMA .................. 16-51
16.11 Sample and Conversion Sequence Examples for Devices with DMA ....................... 16-63
16.12 Analog-to-Digital Sampling Requirements ................................................................. 16-73
16.13 Reading the ADC Result Buffer .................................................................................16-74
16.14 Transfer Functions ..................................................................................................... 16-76
16.15 ADC Accuracy/Error................................................................................................... 16-78
16.16 Connection Considerations........................................................................................ 16-78
16.17 Operation During Sleep and Idle Modes .................................................................... 16-79
16.18 Effects of a Reset....................................................................................................... 16-79
16.19 Special Function Registers ........................................................................................ 16-80
16.20 Design Tips ................................................................................................................ 16-81
16.21 Related Application Notes.......................................................................................... 16-82
16.22 Revision History ......................................................................................................... 16-83
dsPIC33F/PIC24H Family Reference Manual
DS70183D-page 16-2 © 2006-2012 Microchip Technology Inc.
16.1 INTRODUCTION
This document describes the features and associated operational modes of the Successive
Approximation (SAR) Analog-to-Digital Converter (ADC) available on the dsPIC33F/PIC24H
families of devices.
The ADC module can be configured by the user application to function as a 10-bit, 4-channel
ADC (for devices with 10-bit only ADC) or a 12-bit, single-channel ADC (for devices with
selectable 10-bit or 12-bit ADC).
Figure 16-1 illustrates a block diagram of the ADC module for devices with DMA. Figure 16-2
illustrates a block diagram of the ADC module for devices without DMA.
The dsPIC33F/PIC24H ADC module has the following key features:
• SAR conversion
• Up to 1.1 Msps conversion speed
• Up to 32 analog input pins
• External voltage reference input pins
• Four unipolar differential Sample and Hold (S&H) amplifiers
• Simultaneous sampling of up to four analog input pins
• Automatic Channel Scan mode
• Selectable conversion trigger source
• Up to 16-word conversion result buffer
• Selectable Buffer Fill modes (not available on all devices)
• DMA support, including Peripheral Indirect Addressing (not available on all devices)
• Operation during CPU Sleep and Idle modes
Depending on the device variant, the ADC module may have up to 32 analog input pins,
designated AN0-AN31. These analog inputs are connected by multiplexers to four S&H
amplifiers, designated CH0-CH3. The analog input multiplexers have two sets of control bits,
designated as MUXA (CHySA/CHyNA) and MUXB (CHySB/CHyNB). These control bits select a
particular analog input for conversion. The MUXA and MUXB control bits can alternatively select
the analog input for conversion. Unipolar differential conversions are possible on all channels
using certain input pins (see Figure 16-1 Figure 16-2 and ).
Channel Scan mode can be enabled for the CH0 S&H amplifier. Any subset of the analog inputs
(AN0 to AN31 based on availability) can be selected by the user application. The selected inputs
are converted in ascending order using CH0.
The ADC module supports simultaneous sampling using multiple S&H channels to sample the
inputs at the same time, and then performs the conversion for each channel sequentially. By
default, the multiple channels are sampled and converted sequentially.
For devices with DMA, the ADC module is connected to a single-word result buffer. However,
multiple conversion results can be stored in a DMA RAM buffer with no CPU overhead when
DMA is used with the ADC module. Each conversion result is converted to one of four 16-bit
output formats when it is read from the buffer.
Note: This family reference manual section is meant to serve as a complement to device
data sheets. Depending on the device variant, this manual section may not apply to
all dsPIC33F/PIC24H devices.
Please consult the note at the beginning of the “Analog-to-Digital Converter
(ADC)” chapter in the current device data sheet to check whether this document
supports the device you are using.
Device data sheets and family reference manual sections are available for
download from the Microchip Worldwide Web site at: http://www.microchip.com
© 2006-2012 Microchip Technology Inc. DS70183D-page 16-3
Section 16. Analog-to-Digital Converter (ADC)
Analog-to-Digital
Converter (ADC)
16
For devices without DMA, the ADC module is connected to a 16-word result buffer. The ADC
result is available in four different numerical formats (see Figure 16-14).
Note 1: A ‘y’ is used with MUXA and MUXB control bits to specify the S&H channel numbers
(y = 0 or 123).
2: Depending on a particular device pinout, the ADC can have up to 32 analog input
pins, designated AN0 through AN31. In addition, there are two analog input pins for
external voltage reference connections (VREF+, VREF-). These voltage reference
inputs can be shared with other analog input pins. The actual number of analog
input pins and external voltage reference input configuration depends on the
specific device. For further details, refer to the specific device data sheet.
dsPIC33F/PIC24H Family Reference Manual
DS70183D-page 16-6 © 2006-2012 Microchip Technology Inc.
16.2 CONTROL REGISTERS
The ADC module has ten Control and Status registers. These registers are:
•ADxCON1: ADCx Control Register 1
•ADxCON2: ADCx Control Register 2
•ADxCON3: ADCx Control Register 3
•ADxCON4: ADCx Control Register 4
•ADxCHS123: ADCx Input Channel 1, 2, 3 Select Register
•ADxCHS0: ADCx Input Channel 0 Select Register
•AD1CSSH: ADC1 Input Scan Select Register High
•ADxCSSL: ADCx Input Scan Select Register Low
•AD1PCFGH: ADC1 Port Configuration Register High
•ADxPCFGL: ADCx Port Configuration Register Low
The ADxCON1, ADxCON2 and ADxCON3 registers control the operation of the ADC module.
The ADxCON4 register sets up the number of conversion results stored in a DMA buffer for each
analog input in the Scatter/Gather mode for devices with DMA. The ADxCHS123 and ADxCHS0
registers select the input pins to be connected to the S&H amplifiers. The ADCSSH/L registers
select inputs to be sequentially scanned. The ADxPCFGH/L registers configure the analog input
pins as analog inputs or as digital I/O.
16.2.1 ADC Result Buffer
For devices with DMA, the ADC module contains a single-word result buffer, ADC1BUF0. For
devices without DMA, the ADC module contains a 16-word dual-port RAM, to buffer the results.
The 16 buffer locations are referred to as ADC1BUF0, ADC1BUF1, ADC1BUF2, ..., ADC1BUFE
and ADC1BUFF.
Note: After a device reset, the ADC buffer register(s) will contain unknown data.
dsPIC33F/PIC24H Family Reference Manual
DS70183D-page 16-12 © 2006-2012 Microchip Technology Inc.
Register 16-4: ADxCON4: ADCx Control Register 4
U-0 U-0 U-0 U-0 U-0 U-0 U-0 U-0
— — — — — — — —
bit 15 bit 8
U-0 U-0 U-0 U-0 U-0 R/W-0 R/W-0 R/W-0
— — — — — DMABL<2:0>
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-3 Unimplemented: Read as ‘0’
bit 2-0 DMABL<2:0>: DMA Buffer Locations per Analog Input bits
111 = Allocates 128 words of buffer to each analog input
110 = Allocates 64 words of buffer to each analog input
101 = Allocates 32 words of buffer to each analog input
100 = Allocates 16 words of buffer to each analog input
011 = Allocates 8 words of buffer to each analog input
010 = Allocates 4 words of buffer to each analog input
001 = Allocates 2 words of buffer to each analog input
000 = Allocates 1 word of buffer to each analog input
Note: This register is not available in devices without DMA. Refer to the “Direct Memory Access (DMA)”
chapter in the specific device data sheet for availability.
