UMT 70 S
Windscreen, anthraciteOrder-No. 202407
Order-No. 600018
Microphone holder, blackOrder-No. 202306
blackOrder-No. 600001
Elastic suspension, satin nickelOrder-No. 202318
Elastic suspension, black mattOrder-No. 202319
Elastic suspension, modified,anthraciteOrder-No. 600004
Power supplyOrder-No. 202101
Connection cableOrder-No. 202212
Popscreen, black
Clamp,
W 76
PO 70
MH 75
MKV 9
EA 21
EA 21
N 200
C 70
AT 8410 a
Accessories,optional
MICROTECHGEFELL
FÜRSTUDIO-UNDMESSTECHNIK
KONDENSATORMIKROFONE
SEIT 1928
Transformerless Condenser Microphone
with switchable polar pattern
TheUMT70Scondensermicrophone,equippedwithourreliablelarge
diaphragmcapsule,featuresoutstandingperformance,highsensitivity,and
improved signal-to-noise ratio.
TheUMT70Sguaranteesparticularlycleanandcolourlesssound
reproduction.Itiswellsuitedforinstrumentalandvocalsoloistsinradioand
television broadcasting and any other kind of accurate production.
Thepressuregradienttransducerisadualcapacitordesignthatusesa
singlebrassbackplateandtwolarge-diametergold-platedplastic
diaphragms.Varyingthepolarizationvoltageappliedtothediaphragms
resultsinthreedirectionalcharacteristics:omni,cardioidandfigure8.Aring
at the bottom of the microphone's head grille is used to select the pattern.
Theomni-directionalpatternshowsaslight2dBriseinthevicinityof
10,5kHzwhilethebassresponseisperfectlyflat.Thecardioidandfigure8
patternsexhibitasmoothpresenceboostrisingtoabout4dBinthe7kHz
range.Thisresponse,coupledwithaslightroll-offatlowfrequencies,is
responsible for the legendary 'presence' of this microphone.
Thedirectionofmaximumsensitivityisperpendiculartothemicrophone's
axis (side addressed).
Thenewlydevelopedtransformerlesscircuitdesignsubstitutestheprevious
transformerforasymmetricaloutputstageyieldingasuperbtransient
responsecombinedwithahighRFIrejection.Thecircuittechnologyalso
achievesawiderdynamicrangebyloweringtheself-noisefloorand
increasing the headroom for loud signals.
A10dBattenuatorhasbeeninstalledtoreducethesensitivityofthemicro-
phonewhenplacednearveryloudsoundsources.Asensitivityreductionfor
lowfrequenciescanbeutilizedtosuppresstheproximityeffectwhenclose-
miking with the cardioid or figure 8 patterns.
Themicrophoneisequippedwithastandard3-pinXLRconnectorfittingtoa
microphone cable, e.g. C 70.
TheoperationvoltagefortheUMT70Sisprovidedby48Vphantompower-
ing according to the international standards DIN 45596 and IEC 268-15.
The microphone is available in a satin nickel or a black matt finish.
Delivery
MicrophoneUMT 70 S in wooden case L x B x H 275 x 90 x 70 mm
satin nickelOrder-No. 211130
black mattOrder-No. 211131
MICROTECH GEFELL GMBH GEORGNEUMANNPLATZ D-07926 GEFELL TEL. ++49 (0)36649 / 882-0 FAX ++49 (36649 / 882 11--0)
INTERNET http://www.microtechgefell.dee-mail [email protected]
