Sida 1/3
4
MENU
MIC
Rx Tx
Scan Dw Vox
MENU
MIC
Rx Tx
Scan Dw Vox
PTT MIC/CHG
Congratulations on your purchase!
The family of radio M24 Plus, M48 Plus and M99 Plus
are PMR 446 transceiver which may be used, without li-
cense, all over Europe. Please consult the “Restrictions
on the use” charts for information regarding country
specic limitations.
Main features:
Freq. 446.00625 ÷ 446.09375 MHz ›
Channels; ›
M24 Plus: 24 channels (8+16 pre-programmed)
M48 Plus: 48 channels (8+16 pre-programmed)
M99 Plus: 99 channels (8+16 pre-programmed)
38 CTCSS-Sub-Tones ›
Power: 500 mW ERP ›
VOX sensitivity adjustable in 2 levels ›
Battery pack: 600mAh 4,8V NiMH ›
Alphanumeric LCD Display ›
Battery life up to 12 hours ›
Operating temperature –20° +55° ›
Weight 95 gr (batteries excluded) ›
Size 58x160x28 mm ›
Jack MIC CHG: 2 pins for audio accessories, wall ›
charger
Specications are subject to change without notice.
Content model M24 Plus
2 transceivers with 24 channels ›
2 belt clips ›
Instruction manual ›
Content model M48 Plus
2 transceivers with 48 channels ›
2 belt clips ›
2 600mAh rechargeable battery packs ›
2 headsets ›
wall adaptor double plug ›
Instruction manual ›
Content model M99 Plus
2 transceivers with 99 channels ›
2 belt clips ›
2 600mAh rechargeable battery packs ›
1 double desktop charger ›
wall adaptor ›
2 “professional” headsets ›
2 carry cases with neck collars ›
Instruction manual ›
Coverage
The maximum range depends on terrain condition and
is obtained during use in an open space.
The only limitation to maximum possible range are en-
vironmental factors such as blockage caused by trees,
buildings, or other obstructions. Inside a car or a metallic
constructions, the range can be reduced. Normally the
coverage in the city, with buidings or other obstructions
is about 1 or 2 Km. In open space but with obstructions
like trees, leafs or houses the maximum possible range
is about 4-6 Km. In open space, without obstructions
and in sight, like for example in mountain, the coverage
can be more that 10 Km.
Battery and battery compartment
The transceiver accepts the rechargeable battery pack
(included only in the M48 Plus and M99 Plus models)
or 4AAA alkaline/ rechargeable batteries. To open the
battery compartment, hold the unit face down and un-
hook the battery holder in the lower part of the radio and
gently slide the cover.
Attention: the battery pack provided with the M48 Plus
and M99 Plus models, must be recharged before the
rst use (see the section “Recharging” for more info).
Midland M24 Plus, M48 Plus e M99 Plus
PMR446 TRANSCEIVER
5
LET’S COMMUNICATE!
To turn radio on/off
Hold down the
for 3 seconds.
Channel selection
Press once the “menu” button and then select the desired channel by the p/q but-
tons. Press PTT to conrm the selection. Remember in order to communicate, both
radios must be set on the same channel.
Transmission
Keep the PTT button pressed and speak into the unit. Hold the radio 4/10cm away
from your mouth. The display shows ‘TX’. When the PTT is released, the radio beeps
to conrm to other users that your transmission has nished (Roger beep. See the
paragraph).
Reception
Simply release the PTT button. When you receive a signal, ‘RX’ is displayed.
Volume adjustment
Use the p/q buttons to adjust the volume to the desired level.
CALL function
Sending audio signal
By pressing rapidly the PTT button twice, you will send an audio signal to other users
on the same channel.
“Menu” button
Following functions can be selected by pressing the “menu” button:
VOX ›
Roger Beep activation ›
Channel setting ›
CTCSS Tones setting ›
Monitor ›
› VOX function and its sensitivity
The VOX function lets you open the transmission by voice without the use of the
PTT button. To get the most use from the VOX feature you must rst determine what
sensitivity (noise level) is needed to activate the VOX.
Push the “menu” button for three times; ‘VOX’ blinks on the display. Select the
desired VOX level (HI or LO) by means of the p/q buttons and then press the PTT
button to conrm.
VOX can be adjusted in 2 positions:
• HI: high sensitivity (normal voice with no background noise)
• LO: low sensitivity (useful in very noisy areas or if you talk loudly)
To disable the VOX mode, press the “menu” button for three times. ‘VOX’ blinks
on the display. Select ‘OF’ by means of the p/q buttons and then push PTT to
conrm.
Attention: the VOX function can not be used with the M48 Plus provided headset
inserted. To use the VOX with the headset provided with the M99 Plus model, move
the small switch of the headset on the VOX position. Move it back on PTT position
if you don’t use the VOX function.
› Roger Beep: end transmission tone
When PTT is released the radio will beep to conrm to other users that your
transmission has nished. This feature is enabled by default and it is displayed with
the
icon.
To disable the Roger Beep
1. Push the “menu” until the display shows the symbol
2. Select ‘OF’ by means of the p/q buttons
3. Conrm the selection by pushing the PTT button.
› Channel setting
Press once the “menu” button and then select the desired channel by the p/q
buttons. Press PTT to conrm the selection.
› CTCSS-sub-tone setting
The CTCSS sub-tones, are code numbers (from 1 to 38) to be added to the rst
8 channels in order to create a new private channel. You can add up to 38 codes
to the channels named from P1 to P8, that means you can create up to 308 new
channels. For example if you add the CTCSS sub-tone “27” to the channel “P3”
you will obtain the new channel “P327” that will be able to communicate to other
transceivers only if they will be set on the same channel and sub tone.
To activate 38 different CTCSS sub-tones follow these steps:
1. Turn on the radio.
2. Press the “Menu” button and select with the p/q buttons one of the 8 channels
(from P1 to P8).
3. Press twice the “menu” button until the display shows the selected channel with
the ashing two digits CTCSS sub-tone (on the right of the channel)
4. Select with the p/q buttons the desired CTCSS sub-tone (from 1 to 38).
5. To conrm the setting press PTT.
Now the radio transmits and receives using the programmed CTCSS sub-tone. If
you don’t want to use any CTCSS tone, select “00”.
Show the CTCSS-sub-tone on the LCD
When you activate a CTCSS sub-tone, from P1 to P8, the tone is visible just on the
right side of the channel. For the other channels (from 9 up) the CTCSS sub-code is
pre-programmed and then “hidden”. To temporary show a pre-programmed channel
and his CTCSS sub-tone, press the “menu” button for more than 3 seconds.
