Page 2 midlandusa.com

Model MXT275

Table of Contents

WELCOME TO THE WORLD OF MIDLAND 3…………………………………....…….

FEATURES………………………………………………………………………………………....3

FCC NOTICE…………………………………….……………………………………………..…..4

Exposure to Radio Frequency Energy………..……………………………………………........4

INSTALLING YOUR RADIO………………………………………………………………….…...5

Preparation for Installation…........…………………………………………....5

Installing the Mounting Bracket…...…………………………………………..6

Installing the Antenna……………….………………………………………….7

Electrical and Rear Panel Connections..……………………………………..8

Connecting the Microphone…………….……………………………………..8

Using an External Speaker……………….…………………………………...9

CONTROLS AND INDICATORS………………………………………………………………....9

Microphone Operating Controls…………..…………………………………..9

Front Panel Connections……………………………………………………..11

Back Panel Connections…………………...………………………………...11

LCD Display…………………………………...……………………….……...12

OPERATING YOUR RADIO…………………………………….……………………….……...13

About Range……………………………………….…………………….…....13

 PowerOn/O󰀨……………………………………..……………………….…..14

Selecting the Active Channel…………………….……………………….....14

Adjusting the Volume………………………………..………………………..14

To Transmit and Receive a Call……………………………………………...15

UTILITY FUNCTIONS………………………………………………….………………………...15

Locking the Keypad………………………………….………………………..15

Using Monitor Mode………………………………….……………………….16

Scanning for Active Channels………………………...……………………..17

NOAA Weather Radio/Scan……………………………..…………………...17

To Manually Set the Weather Channel………………………………………………………....18

To Enable Weather Alert………………………………………………………………………....18

MENU MODE FUNCTIONS……………………………………………………………………..19

Selecting a Privacy Code………………………………………………....….19

Selecting the Transmit (TX) Power Level………………………………..…21

Adjusting Squelch Sensitivity…………………………………………...…...21

Roger Beep……………………………………………………………….…...22

Call Alert Tone………………………………………………………………...23

Silent Operation………………………………………………………….…....23

Repeater Channels…………………………………………………………...24

Selecting the LCD Display Background Color……………………………..24

CHOOSING YOUR OUTPUT SPEAKER…………………………………………………......25

RESTORING THE DEFAULT SETTINGS……………………………………………………..25

CARE AND MAINTENANCE…………………………………………………………………....26

TROUBLESHOOTING GUIDE…………………………………………….…….…..26

SPECIFICATIONS…………………………………………………………...…........................27

GMRS Frequency Chart……………………………………….....................27

WX Weather Band Chart……………………………………........................27

GMRS Repeater Frequency Chart………………………….......................27

CTCSS Privacy Codes Frequency Chart……………………....................28

DCS Privacy Codes Frequency Chart......................................................28

Page 3midlandusa.com

Model MXT275

ACCESSORIES…………..……………………………………………………………………..30

LIMITED WARRANTY…………………………………………………………………………..31

WELCOME TO THE WORLD OF MIDLAND RADIO

Congratulations on your purchase of a high quality MIDLAND product.Your

MXT275 2-way radio represents state-of-the-art high tech engineering.

Designed for General Mobile radio Service (GMRS) operation, this

compact package is big on performance. It is a quality piece of electronic

equipment,skillfullyconstructedwiththenestcomponents.Thecircuitry

is all solid-state and mounted on a rugged printed circuit board. Your

MXT275 radio is designed for reliable and trouble-free performance for

years to come.

FEATURES

– 15 GMRS Channels

– 10 NOAA Weather Channels

– 8 Repeater Channels

– 142 Privacy Codes (38 CTCSS / 104 DCS)

– Monitor Function

– Keypad Lock

– Power Hi/Lo Settings

– External Speaker Jack

IMPORTANT!

Changes or modications to this unit not expressly approved by

MIDLAND RADIO CORPORATION could void your right to operate this

unit. Your radio is set up to transmit a regulated signal on an assigned

frequency. It is against the law to alter or adjust the settings inside the

COMMUNICATOR to exceed those limitations. Any adjustment to your

radiomustbemadebyqualiedtechnicians.
