Operating and installation instructions

Cooker hood

To prevent the risk of accidents or damage to the appliance, it is essen‐

tial t

o read these instructions before it is installed and used for the first

time.

en-GB M.-Nr. 10 093 480

Contents

Warning and Safety instructions .......................................................................... 4

Caring for the environment.................................................................................

Modes of operation..............................................................................................

Con@ctivity 2.0 function ........................................................................................ 15

Guide to the appliance.........................................................................................

Operation (Automatic mode)...............................................................................

Cooking with Con@ctivity 2.0 (Automatic mode)................................................... 18

Leaving automatic mode temporarily..................................................................... 20

Returning to automatic mode ................................................................................ 20

Operation (Manual mode)....................................................................................

Cooking without Con@ctivity 2.0 (Manual mode).................................................. 21

Switching the fan on .............................................................................................. 21

Selecting the power level....................................................................................... 21

Selecting the run-on time....................................................................................... 22

Switching the fan off .............................................................................................. 22

Switching the hob lighting on/off........................................................................... 22

Power management............................................................................................... 23

Operation (Automatic and Manual modes)........................................................

Operating hours counters ...................................................................................... 24

Altering the operating hours counter for the grease filters ............................... 24

Activating and altering the charcoal filter operating hours counter.................. 25

Reading the filter operating hours counter ....................................................... 25

Energy saving tips................................................................................................

Cleaning and care................................................................................................

Casing.................................................................................................................... 27

Grease filters.......................................................................................................... 28

Charcoal filters....................................................................................................... 30

Resetting the charcoal filter operating hours counter....................................... 31

Disposing of the charcoal filters ....................................................................... 31

Installation ............................................................................................................

Appliance dimensions............................................................................................ 32

Safety distance between hob and cooker hood (S)............................................... 34

Installation recommendations................................................................................ 35

Before installation .................................................................................................. 35

Assembly parts ...................................................................................................... 36

Exhaust socket ...................................................................................................... 45

Contents

Setting up for recirculation mode .......................................................................... 46

Electrical connection.............................................................................................. 47

Electrical connection...........................................................................................

Connection for air extraction.............................................................................. 49

Condensate trap .................................................................................................... 50

Silencer .................................................................................................................. 50

Activating Con@ctivity 2.0................................................................................... 52

Installing the Con@ctivity 2.0 Stick........................................................................ 52

Activating Con@ctivity 2.0 ..................................................................................... 52

Activating the cooker hood............................................................................... 52

Activating the hob............................................................................................. 53

Activation failed ................................................................................................ 53

Deactivating Con@ctivity 2.0 ................................................................................. 53

After Sales / Guarantee .......................................................................................

Position of the data plate....................................................................................... 54

Technical data ...................................................................................................... 55

Conformity declaration........................................................................................... 55

Produktspecifikationer

Varumärke:	Miele
Kategori:	Fläktkåpa
Modell:	DA 3566
Inbyggd display:	Ja
Vikt:	15000 g
Bredd:	592 mm
Djup:	309 mm
Höjd:	37 mm
Årlig energiförbrukning:	31.5 kWh
Sladdlängd:	1.5 m
Motoreffekt:	- W
Belysningsstyrka:	420 lx
Motor ingår:	Ja
Ljudnivå (låg hastighet):	39 dB
Antal lampor:	2 lampor
Tvättbart filter:	Ja
Antal filter:	2 styck
Antal hastigheter:	3
Modell:	Inbyggd under
Produktens färg:	Rostfritt stål
Skärmtyp:	LED
Kontrolltyp:	Röra
Löstagbart filter:	Ja
Fettfilter typ:	Rostfritt stål
AC-inspänning:	230 V
Lamptyp:	LED
Växelström Frekvens:	50 hz
Ström:	10 A
Ljudnivå Lc IEC:	51 dB
Lampor:	4.5 W
Ansluten effekt:	101 W
Typ av fläkt:	Frånluft/recirkulerande
Maximal flödeskapacitet:	640 m³/h
Intensiv hastighet:	Ja
Evakueringsanslutning diameter:	150 mm
Diskmaskin filter:	Ja
Energiklass, flödesdynamik:	A
Energiklass, belysning:	A
Energiklass, fettfiltrering:	C
Exhaust plats:	Övre
Filterrengöring indikator:	Ja
Ljudnivå (hög hastighet):	51 dB
Minsta avstånd från elektrisk spis:	450 mm
Minsta avstånd från gashäll:	650 mm
Ljudnivå (medelhög hastighet):	45 dB
Ljudnivå (boostläge):	63 dB
