Sida 1/36

Operating and installation instructions

Cooker hood

To prevent the risk of accidents or damage to the appliance, it is

essential to read these instructions before it is installed and used for

the first time.

en-GB M.-Nr. 09 704 870

Contents

Warning and Safety instructions.......................................................................... 3

Caring for the environment................................................................................. 12

Modes of operation.............................................................................................. 13

Guide to the appliance......................................................................................... 14

Operation.............................................................................................................. 16

Switching the fan on.............................................................................................. 16

Selecting the power level....................................................................................... 16

Switching the fan off.............................................................................................. 17

Switching the hob lighting on / off......................................................................... 17

Safety switch-off.................................................................................................... 17

Cleaning and care................................................................................................ 18

Housing.................................................................................................................. 18

Grease filters.......................................................................................................... 19

Charcoal filter......................................................................................................... 21

Disposing of the charcoal filter......................................................................... 21

Changing a halogen lamp...................................................................................... 22

Installation............................................................................................................ 23

Before installation.................................................................................................. 23

Protective foil......................................................................................................... 23

Installation instructions.......................................................................................... 23

Dismantling............................................................................................................ 23

Assembly parts...................................................................................................... 24

Appliance dimensions............................................................................................ 26

Safety distance between hob and cooker hood.................................................... 27

Installation recommendations................................................................................ 28

Drilling diagram for wall mounting......................................................................... 28

Connection for air extraction.............................................................................. 29

Condensate trap.................................................................................................... 30

Silencer.................................................................................................................. 30

Electrical connection........................................................................................... 32

After Sales / Guarantee....................................................................................... 33

Position of the data plate....................................................................................... 33

Technical data...................................................................................................... 34

Warning and Safety instructions

This appliance complies with all relevant local and national safety

requirements. Inappropriate use can, however, lead to personal

injury and damage to property.

To avoid the risk of accidents and damage to the appliance,

please read these instructions carefully before using it for the first

time. They contain important notes on the safety, installation, use

and maintenance of the appliance. Miele cannot be held liable for

non-compliance with these instructions.

Keep these instructions in a safe place and ensure that all users

are familiar with the contents. Pass them on to any future owner of

the appliance.

Correct application

 This cooker hood is intended for use in domestic households and

similar working and residential environments.

 The cooker hood is not intended for outdoor use.

 It must only be used as a domestic appliance to extract vapours

and remove odours from cooking.

Any other usage is not supported by the manufacturer and could be

dangerous.

 The cooker hood can only be used by people with reduced

physical, sensory or mental capabilities, or lack of experience and

knowledge, if they are supervised whilst using it, or have been

shown how to use it in a safe way and recognise and understand the

consequences of incorrect operation.
