EN - English -Quick Guide:
This "hAP ax³" series Quick Guide covers models: C53UiG+5HPaxD2HPaxD (hAP ax³).
This is a wireless network device. You can find the product model name on the case label (ID).
Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um
The most relevant technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, brochures, and more info about products at https://mikrotik.com/products
Configuration manual for software in your language with additional information can be found athttps://mt.lv/help
If you need help with configuration, please seek a consultanthttps://mikrotik.com/consultants
First steps:
Please attach provided antennas to the device, before connecting to the power
source;
Make sure your Internet service provider is allowing hardware change and will issue
an automatic IP address;
Connect the service provider cable to the Internet port and connect the device to the
power source;
Open network connections on your computer and search for MikroTik wireless
network - connect to it;
The configuration can be done through the wireless network using a web browser or
mobile app. Alternatively, you can use a WinBox configuration tool ;https://mt.lv/winbox
Openin your web browser to start configuration, user name: ahttp://192.168.88.1
dmin
and there is no password by default (or, for some models, check user and wireless
passwords on the sticker);
Click the "Check for updates" button and update RouterOS to the latest version;
For a manual update of the device, visit the products page atto find your product. The required packages are accessible under https://mikrotik.com/products
themenu;
"Support&Downloads"
Upload downloaded packages to themenu and reboot the device;
WebFigor
Winbox
"Files"
By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;
In themenu set up the following: Choose your country, to apply country regulation settings;
"QuickSet"
Set up your wireless network password in the left field;
Set up your router password in the bottom field.
This device needs to be upgraded to RouterOS v7.7 or the latest stable version, to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be installed according to instructions.
Produktspecifikationer
| Varumärke: | Mikrotik |
| Kategori: | Inte kategoriserad |
| Modell: | hAP ax³ |
| Produkttyp: | Bordsrouter |
| Processorfrekvens: | 1800 MHz |
| Wi-Fi-standarder: | 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Internminne: | 1024 MB |
| Flashminne: | 128 MB |
| Antenndesign: | Extern |
| Produktens färg: | Svart |
| processortillverkare: | Qualcomm |
| Inbyggd processor: | Ja |
| Datahastighet för Ethernet-LAN: | 10,100,1000 Mbit/s |
| Strömförsörjning via Ethernet (PoE) stöd: | Ja |
| Antal LAN (RJ-45) anslutningar: | 4 |
| Temperatur vid drift: | -40 - 70 ° C |
| Nätverksansluten (Ethernet): | Ja |
| Likströmsingång: | Ja |
| Strömkälla av typen: | DC, PoE |
| Antenner mängd: | 2 |
| Antenn ökningsnivå (max): | 5.5 dBi |
| USB-port: | Ja |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar: | 1 |
| Processorkärnor: | 4 |
| Typ av Ethernet LAN-gränssnitt: | Gigabit Ethernet |
| Wi-Fi-standard: | Wi-Fi 6 (802.11ax) |
| Wi-Fi-band: | Dual-band (2,4 GHz / 5 GHz) |
| Dataöverföringshastighet via WLAN (max): | 1200 Mbit/s |
| Dataöverföringshastighet via WLAN (första bandet): | 574 Mbit/s |
| Dataöverföringshastighet via WLAN (andra bandet): | 1200 Mbit/s |
| Kontrollampa: | Ja |
