Model: MCT-10QDS, MCT-10QDS-POE, MCT-10HPQ, MCT-10HPQ-POE
Please keep this manual for future reference.
TABLE OF CONTENTS
PAGE
DECLARATION……………....…………………..............……………............…....1
PRODUCT INSTRUCTIONS……….......……..............…………………....………………1
POWERING ON THE PRODUCT………...........………………………...….....….……….2
WITHOUT MOUNTING BRACKET…..........................................................2
WITH MOUNTING BRACKET…………….................................……3
INSERTING THE SD CARD.....………………….................………………………………3
INSERTING USB DEVICES……………..................……………......…………….……….3
HDMI OUTPUT.........................................................................................…..............3
HOME SCREEN.......………..…………….....................………….…......................……4
SYSTEM BAR….........................................................................................................8
APPLICATIONS.......................................................................................…11
LANGUAGE………………......…............................................................……12
DATE & TIME……………….....….......….............................…...................................13
VOLUME………………......….......….............................…...................................14
BRIGHTNESS………………......….......….............................…..............................14
SCHEDULED POWER ON/OFF………………......….......….......................................15
WI-FI....................………………......….......….............................................19
ETHERNET....................………………......….......….............................................20
BLUETOOTH....................………………......….......….............................................21
VIRTUAL KEYBOARD....................………………..........…........................................23
SWITCH INPUT METHODS......................………......….......…................................24
TAKE PHOTOS & SHOTS....................………………........…...................................26
SURF ONLINE................………………......….......….................................................29
BROWSE FILES................………………......….......…...............................................30
PLAY MEDIA................……………......….......…......................................................31
INSTALL & UNINSTALL APPS................………………......….......….......................31
INSTALL APPS................……………….......................................................31
UNINSTALL APPS................……………….....................................35
RESET TO FACTORY DEFAULT................………...................................................36
Adapt-IQ 10.1” User’s Manual
Mimo Monitors
info@mimomonitors.com
Sales: 1-855-YES-MIMO (937-6466)
1
1
Browse Files ...................................................................................................................... 30
Play Media ......................................................................................................................... 31
Install & Uninstall Apps .................................................................................................... 31
Install Apps ................................................................................................................... 31
Uninstall Apps .............................................................................................................. 35
Reset to Factory Default.................................................................................................. 36
Declaration
! Please read the instructions carefully before using the device.
! Do not put the product in high temperature, humid or dusty environment.
! Do not drop this product.
! Do not power off the device when it’s formatting or upgrading, otherwise it
will cause an operation system error.
! This product is not waterproof.
! Use only approved add-on devices.
Product Instructions
1. Camera (optional): 5M pixels camera
2. LED Indicator:
Green
Power supply is on.
Right Side
Back
To
p
Bottom
Front
Mimo Monitors
743 Alexander Rd. Suite 15
Princeton, NJ 08540
info@mimomonitors.com
Sales: 1-855-YES-MIMO (937-6466)
Mechanical Design
Front
1. Camera (optional)
Top
2. LED
3. SD card slot + cover
4. Menu/Enter button
5. Function keys (up/down)
6. Function keys (Vol+ / Vol-)
Back
7. Speakers
8. VESA mounting holes
9. DC in
10. Add on Module Slot
Bottom
9. DC in
10. Add on Module Slot
11. Ethernet RJ45 port
12. USB type A
13. Micro USB
14. Power switch
15. GPIO
16. RS232
9
10
11 12 13 14
2 3 4 5
6
1
10
10
10
8
7
7
9
2019-1118
Rev 3 - 79649
15
16
Mimo Monitors
743 Alexander Rd. Suite 15
Princeton, NJ 08540
info@mimomonitors.com
Sales: 1-855-YES-MIMO (937-6466)
Mechanical Design
Front
1. Camera (optional)
Top
2. LED
3. SD card slot + cover
4. Menu/Enter button
5. Function keys (up/down)
6. Function keys (Vol+ / Vol-)
Back
7. Speakers
8. VESA mounting holes
9. DC in
10. Add on Module Slot
Bottom
9. DC in
10. Add on Module Slot
11. Ethernet RJ45 port
12. USB type A
13. Micro USB
14. Power switch
15. GPIO
16. RS232
9
10
11 12 13 14
2 3 4 5
6
1
10
10
10
8
7
7
9
2019-1118
Rev 3 - 79649
15
16
Produktspecifikationer
| Varumärke: | Mimo Monitors |
| Kategori: | bildskärm |
| Modell: | Adapt-IQ MCT-10HPQ-POE |
| Vikt: | 595 g |
| Bredd: | 252 mm |
| Djup: | 24 mm |
| Höjd: | 178 mm |
| Skärm diagonal: | 10.1 " |
| Upplösning: | 1280 x 800 pixlar |
| Pekskärm: | Ja |
| Processorfrekvens: | 1.8 GHz |
| Processorfamilj: | ARM Cortex |
| Wi-Fi: | Ja |
| Ljudformat som stöds: | AAC, ASF, MP2, OGG, WAV, WMA |
| Videoformat som stöds: | 3GP, ASF, AVI, DAT, FLV, MKV, MOV, MP4, MPG, RM, TS, VOB, WMV |
| Ljusstyrka: | 350 cd/m² |
| LED-bakgrundsbelysning: | Ja |
| Inbyggda högtalare: | Ja |
| Antal inbyggda högtalare: | 2 |
| Certifiering: | FCC, CE, & RoHS |
| USB-version: | 2.0 |
| Processor: | A17 |
| Pekskärmsteknik: | Kapacitiv |
| Typ av minneskort: | SD |
| Produktens färg: | Svart |
| HD-typ: | Full HD |
| Skärmtyp: | LCD |
| VESA-fäste: | Ja |
| Inbyggd kortläsare: | Ja |
| Uteffekt (RMS): | 3 W |
| Inbyggd processor: | Ja |
| Installerat operativsystem: | Android 8.1 |
| Datahastighet för Ethernet-LAN: | 10,100,1000 Mbit/s |
| Antal LAN (RJ-45) anslutningar: | 1 |
| Strömförbrukning (vanlig): | 18 W |
| Temperatur vid drift: | -10 - 50 ° C |
| Temperaturintervall (förvaring): | -15 - 65 ° C |
| Intervall för relativ operativ luftfuktighet: | 10 - 90 % |
| Fuktighet (förvaring): | 10 - 90 % |
| Nätverksansluten (Ethernet): | Ja |
| Bildkomprimeringsformat: | BMP, GIF, JPG |
| USB-port: | Ja |
| Strömförbrukning i vänteläge: | - W |
| Kontrastförhållande (medel): | 800:1 |
| Native bildförhållande: | 16:10 |
| Processorkärnor: | 4 |
| Gränsssnitt för panelmontering: | 75 x 75 mm |
| Antalet samtidiga beröringspunkter: | 10 |
