LF Cast Chassis / Neo
NTR08-2011D
Features
8" neodymium magnet driver providing 200Wrms (AES standard) power handling
and 92dB sensitivity
2" high temperature copper voice coil
Suitable for line array applications, utilizing a space-ecient
octagonal chassis prole
Optimized ux distribution in magnet assembly provides low harmonic
distortion
"M-Roll" surround provides progressive excursion control, generating a
smooth frequency response
Intelligent heat management in both chassis and magnet assembly design
oers reduced thermal compression
8 Ω Frequency Response
1. Tested for two hours using a continuous, band-limited pink noise signal as per AES standard. Power
calculated on minimum impedance. Loudspeaker tested in free air.
2. Measured on axis at 1W, 1m in 2 anechoic environment.
3. Xmax derived from: (voice coil winding width-gap depth)/2.
4. Small signal parameters measured after unit subjected to pre-conditioning signal.
General Specications
Nominal diameter 203mm/8in
Power rating 1200Wrms
Nominal impedance 8 Ω
Sensitivity 292dB
Frequency range 70-6000Hz
Voice coil diameter 50mm/2in
Chassis type Cast aluminium
Magnet type Neodymium
Coil material Round copper
Former material Polyimide
Cone material Kevlar loaded paper with weather-resistant coating
Surround material Cloth-sealed
Suspension Single
Xmax 34mm/0.16in
Gap depth 8mm/0.32in
Voice coil winding width 16mm/0.63in
Small Signal Parameters4
D 0.17m/6.69in
Fs 80.3Hz
Mms 25.33g/0.89oz
Mmd 23.39g/0.826oz
Qms 1.33
Qes 0.59
Qts 0.41
Re 5.85 Ω
Vas 11.3lt/0.399ft3
BI 11.22Tm
Cms 0.16mm/N
Rms 9.6kg/s
Le (at 1kHz) 0.59mH
Mounting Information
Diameter 225mm/8.8in
Overall depth 100mm/4.16in
Cut-out diameter 100mm/4.16in
Mounting slot dimensions ø6.5mm/0.26in
Number of mounting slots 8
Mounting slot PCD 210/8.3
Unit weight 1.52kg/3.34lb
Packed Dimensions & Weight
Single pack size W x D x H 235mm x 235mm x 140mm
/9.2in x 9.2in x 5.5in
Single pack weight 1.75kg/3.85lb
Multi pack (8) size W x D x H 450mmx380mmx260mm
/17.7in x 15.0in x 10.2in
Multi pack (8) weight 16kg/35.2lb
Celestion, Claydon Business Park, Great Blakenham, Ipswich, IP6 0NL United Kingdom
