Läs gratis den bruksanvisning för Monogram ZWL1126SJSS (3 sidor) i kategorin mikrovågsugn. Guiden har ansetts hjälpsam av 4 personer och har ett genomsnittsbetyg på 3.6 stjärnor baserat på 2.5 recensioner. Har du en fråga om Monogram ZWL1126SJSS eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/3
OVERALL DIMENSIONS
Actual product dimensions
may vary due to
manufacturing tolerances.
Dimensions in parentheses
are in centimeters unless
otherwise noted. Actual
product dimensions may
vary due to manufacturing
tolerances.
* Additional space will be needed for flush installation.
Product Specification Created 4/15
Monogram
®
1.2 Cu. Ft. Drawer Microwave
SPECIFICATIONS
Overall Width 23 7/8" (60.6 cm)
Overall Height 15 15/16" (40.5 cm)
Overall Depth
23 1/8" (58.8 cm)
Oven Door Clearance 15" (38.1 cm) Min
Overall Oven
Interior Capacity
1.2 cu. ft. (.02 cu. cm)
Oven Interior Dimensions
(W x H x D)
16 1/4" x 7 1/4" x 16 1/4"
(41.3 cm x 18.4 cm x 41.3cm)
Minimum Cabinet Width* 22" (55.9 cm)
Minimum Cabinet Depth* 23 1/2" (59.7 cm)
Minimum Base Support 110 lbs (49.9 kg)
Cutout Width* 24 3/16" (61.4 cm) Min
Cutout Height*
15 9/16" (395 cm) Min
Cutout Depth* 23 1/2" (59.7 cm) Min
Voltz/Hertz/Amps 120 VAC, 60 Hz
Cord Length 47 1/4" (119.4 cm)
Electrical Rating
1.67 kw@120v
Total Amps
15
Shipping Weight 90 lbs (39.4 kg)
ZWL1126JSS
ATTENTION ELECTRICIAN:
A 240/208V, 60Hz, 20 Amp circuit is required. An
individual properly grounded branch circuit or
circuit breaker is required. Hard wired junction
box is required for built-in product.
22 1/8" (56.2)
min cutout width
23 7/8" (60.6)
3/16"
(.5)
15 9/16"
(39.5)
min cutout
height
12 11/16"
(32.2)
3"
(7.6)
22 1/8" (56.2)
4"
(10.2)
19 7/8"
(50.5)
1 1/4" (3.2)
1 3/4"
(4.4)
1 1/8"
(2.9)
4"
(10.2)
1 1/4"
(3.2)
4 11/16"
(11.9)
16 15/16"
(43.0)
21 5/8"
(54.9)
15"
(38.1)
21 7/8"
(55.6)
8 5/16"
(21.1)
3 3/32"
(7.9)
15 15/16"
(40.5)
FRONT VIEW (SHOWING CUTOUT OVERLAP)
SIDE VIEW
TOP VIEW
OPEN DRAWER
SHOWING CLEARANCE
NOTES
4"
(10.2)
5"
(12.7)
24 3/16" (61.4) min
24 1/2" (62.2) max
cutout width
3/4"
(1.9)
18 1/2"
(46.9)
E
FLUSH INSTALLATION
FRONT VIEW
TOP VIEW
22" (55.9) mounting
cleat opening width
STANDARD
INSTALLATION
FLUSH INSET
INSTALLATION
23 1/2"
(59.7) min depth
23 1/2"
(59.7) min depth
1 3/16"
(3.0)
Side cleat
WALL INSTALLATION
A
Junction box location
(May also be located
in adjacent cabinet.)
B
To reduce the risk of
tipping of the drawer,
the Anti-Tip block must
be properly installed
located 14 13/16-inches
above the floor on
which the Microwave
Drawer will sit. The
6-inch Anti-Tip block
must be provided by the
installer. The Anti-Tip
block prevents serious
injury that might result
from spilled hot liquids.
C
Cleats may be visible
and should be finished
to match cabinetry.
For more details, refer to the installation instructions for this product on Monogram.com.
Dimensions in parentheses are in centimeters unless otherwise noted.
A
B
C
Product Specification Created 4/15
Monogram
®
1.2 Cu. Ft. Drawer Microwave ZWL1126JSS
FEATURES AND BENEFITS
R
Sophisticated styling - Offers a look of modern
refinement that blends beautifully with both
European and Professional styles.
1.2-cu.-ft. capacity - Accommodates large
plates and cookware with ease.
Flush installation capability - Enables the drawer
to be installed flush with cabinetry without any
additional parts.
Glass touch control with white LED display -
Makes it easy to adjust settings and adds to
the drawer’s sleek, streamlined appearance.
10 cooking modes, including Melt, Soften,
and Keep Warm - Provide cooking convenience
and flexibility.
900 Watts - Cooking power delivers rapid,
even heat.
Sensor cooking - Automatically adjusts time
and power settings for optimal results.
Quickstart option - Allows you to add 60 seconds
of cooking time with a simple touch
Control lock feature - Prevents unwanted use
for extra peace of mind.
Installation flexibility - Allows the drawer to
fit unobtrusively under a standard 24-in.-width
cabinet.
Easy access options - Allow you to open and
close the drawer with the push of a button or by
gently pulling or pushing the recessed handle.
Product Specification Created 4/15
Monogram
®
1.2 Cu. Ft. Drawer Microwave ZWL1126JSS
Produktspecifikationer
