Auto Wah Pedal

6. Mode Switch:

7. RANGE Knob: Adjusts the frequency range of wah effects.

8. Q Knob: Adjusts the intensity of resonance.

1. TRUE BYPASS Footswitch:

Push down the footswitch to toggle

between on and bypass status.

2. ON/OFF LED:

3. DC IN Power Jack:

For power supply, use a 9-volt

DC regulated AC adapter (plug

polarity is positive on the barrel

and negative in the center).

4. INPUT Jack:

1/4 mono audio jack, for connecting ”

guitar.

5. OUTPUT Jack:

1/4” mono audio jack, outputs the signal.

Input: 1/4 monaural jack (impedance: 470k Ohms)”

Output: 1/4 monaural jack (impedance: 100 Ohms)”

Power Requirements: AC adapter 9V DC (center minus plug),

recommended to use Mooer Micro Power

Current Draw: 128 mA

Dimensions: 93.5mm (D) 42mm (W) × × 52mm (H)

Weight: 160g

Accessories: Owner’s Manual

* Disclaimer: Any specification’s update won't be amended in this manual.

Wide adjustable range auto wah effects

3 peak modes for chosing

Full metal shell

Very small and compact design

Switch between Hi Peak mode, Mid

Peak mode, and Low Peak mode (It

can change the depth of wah effects

from high to low).

Shows the on/off status of

Funky Monkey, when the LED

is lit the effect is engaged.

Main Features

9. RATE Knob: Adjusts the speed of wah effects.

True bypass switch

DC 9V adapter power supply

PLEASE READ CAREFULLY BEFORE PROCEEDING

Power Supply

Connections

Always turn off the power of this and all other equipment before connecting or

disconnecting, this will help prevent malfunction and / or damage to other devices.

Also make sure to disconnect all connection cables and the power cord before

moving this unit.

Cleaning

Clean only with a soft, dry cloth. If necessary, slightly moisten the cloth.

Do not use abrasive cleanser, cleaning alcohol, paint thinners, wax, solvents,

cleaning fluids, or chemical-impregnated wiping cloths.

Interference with other electrical devices

Radios and televisions placed nearby may experience reception interference.

Operate this unit at a suitable distance from radios and televisions.

Location

To avoid deformation, discoloration, or other serious damage, do not expose

this unit to the following conditions:

Direct sunlight Heat sources

Magnetic fields Extreme temperature or humidity

Excessive dusty or dirty location High humidity or moisture

Strong vibrations or shocks

Please connect the designated AC adapter to an AC outlet of the correct voltage.

Please be sure to use only an AC adapter which supplies 9V (±10%) DC, center

minus. The maximum working voltage shall not exceed 12V, otherwise may be

dangerous equipment damage, fire or other problems.

Unplug the AC power adapter when not using or during electrical storms.

Precautions

FCC certification

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received, including interference

that may cause undesired operation.
