NAVMAN

w w w . n a v m a n . c o m

Operation Manual

VHF 7000,

7100US, 7100EU

2 VHF 7000, 7100US, 7100EU Operation Manual

NAVMAN

IMPORTANT:

1. Some features described in this manual are not available on every model.

In particular, DSC functions are NOT available on the 7000.

2. DSC functions will not operate on the 7100US or the 7100EU until your

MMSID has been entered. Refer to section 4.2 for details.

3. The radio channels installed into the Navman VHF radio may vary from

country to country, depending upon the model, and government or

national communications authority regulations.

4. Navman NZ Ltd recommends that you check the radio operating licensing

requirements of your country before using the Navman VHF radio. The

operator is solely responsible for observing proper radio installation and

usage practices.

5. A DSC warning label is supplied with the 7100US. To comply with FCC

regulations, this label must be afxed in a location that is clearly visible

from the operating controls of this radio. Make sure that the chosen

location is clean and dry before applying this label.

It is the owner’s sole responsibility to install and use the instrument in such a manner that will

not cause accidents, personal injury or property damage.

Navman NZ Limited disclaims all liability for any use of this product in a way that may

cause accidents, damage or that may violate the law.

Governing Language: This statement, any instruction manuals, user guides and other

information relating to the product (Documentation) may be translated to, or has been

translated from, another language (Translation). In the event of any conict between any

Translation of Documentation, the English language version of the Documentation will be the

ofcial version of the Documentation.

This manual represents the Navman VHF 7000, 7100US, and &7100EU radios at the time

of printing. Navman NZ Limited reserves the right to make changes to specications without

notice.

trademark of Navman NZ Limited.

FCC Statement

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of FCC Rules. These

limits are designed to provide a reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try and correct the interference by one or more of the following

measures:

• reorient or relocate the receiving antenna.

• increase the separation between the equipment and receiver.

• connect the equipment into an outlet on a circuit different from that to

which the

receiver is connected.

• consult the dealer or an experienced radio/TV technician for help.

3VHF 7000, 7100US, 7100EU Operation Manual
NAVMAN
Contents
Section 1 - General Information .............................................................. 5
1-1 Features.................................................................................................... 5
1-2 Customizing Your Navman VHF Radio ..................................................... 6
1-3 How to Display and Navigate Menus ........................................................ 6
1-4 How to Enter Alphanumeric Data.............................................................. 6
1-5 LCD Symbols and Meanings  ................................................................... 6
1-6 Basic Operation and Key Functions.......................................................... 8
Section 2 - The Radio Menu (MENU)..................................................... 11
2-1 Radio Menu Options (Menu) ...................................................................11
2-2 Maintain Your Buddy List (BUDDY LIST)................................................ 12
2-2-1 Add an Entry...................................................................................... 12
2-2-2 Edit an Entry...................................................................................... 12
2-2-3 Delete an Entry.................................................................................. 13
2-3 Local or Distance Sensitivity (LOCAL/DIST)........................................... 13
2-3-1 Set Distance Sensitivity..................................................................... 13
2-3-2 Set Local Sensitivity .......................................................................... 13
2-4 Backlighting (BACKLIGHT) and Contrast (CONTRAST) ........................ 13
2-4-1 Set the Backlighting Level ................................................................. 14
2-4-2 Set the Contrast Level....................................................................... 14
2-5 GPS Data and Time (GPS/DATA) ........................................................... 14
2-5-1 Manually Enter Position and UTC Time (MANUAL) .......................... 14
2-5-2 Local Time (TIME OFFSET).............................................................. 14
2-5-3 Time Format Options (TIME FORMAT)............................................. 15
2-5-4 Time Display Options (TIME DISPLAY) ............................................ 15
2-5-5 Position Display Options (LL display) ................................................ 16
2-5-6 Course and Speed Display Options (COG/SOG).............................. 16
2-5-7 GPS Alert Options (ALERT)  ............................................................. 16
2-6 GPS Simulator (SIMULATOR) ................................................................ 17
2-7 Reset to factory defaults (RESET).......................................................... 17
Section 3 - Radio Setup Menu (RADIO SETUP)................................... 18
3-1 Radio Setup Menu (RADIO SETUP) ...................................................... 18
3-2  Channel Names (CH NAME) ................................................................. 18
3-3 RING & BEEP Volume  (RING VOLUME) & (BEEP VOLUME) .............. 19
3-4 Internal Speaker connections (INT SPEAKER) ...................................... 19
3-5 Set the Priority Channel (watch MODE) ................................................. 19
3-6 Weather Alert (Wx ALERT)  .................................................................... 20
3-7 NMEA protocol (COM PORT) ................................................................. 20
Section 4 - DSC Setup Menu (DSC SETUP) ......................................... 21
4-1 DSC Setup - Menu Options .................................................................... 21
4-2 Enter Your User MMSID (USER MMSID) ............................................... 21
4-3 Maintain Your Groups (GROUP SETUP)................................................ 22
4-3-1 Create a Group (GROUP SETUP) .................................................... 22
