Sida 1/6



DisplayPort to HDMI Converter



User Manual

Introduction…………………………………………...........…1

Features……………………………………………….............2

Package Includes...............................................................2

Panel Descriptions………………........................................3

Connections............. ......….................................... .............4

Wiring Diagram…………………………………....................4

Specications………………………………….......................5



INTRODUCTIONS DisplayPort to HDMI Converter

1



Dear Customer

Thank you for purchasing this product. For optimum performance and safety, please read these

instructions carefully before connecting, operating or adjusting this product. Please keep this

manual for future reference.

DisplayPort to HDMI Converter

This is a DisplayPort 1.2 to HDMI signal format converter for interfacing next generation

DisplayPort based PC and notebook computers with high definition displays. DisplayPort offers a

unified, scalable, and cost effective interface for embedded and external display applications. As

desktop and notebook PCs are increasingly transitioning from conventional analog type interfaces

to DisplayPort, the converter facilitates the transition by offering seamless connectivity between

new DisplayPort PC and the installed base HDMI monitors and projectors.

It offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and

Projector factory, noise space and security concerns, data center control, information distribution,

conference room presentation, school and corporate training environments.

nments.

Applications

It applies to ANY devices with HDMI port.

A premium quality HDMI to HDMI cable is suitable for use in HDTV, Home Theater, DVD player,

projector, PS3, Xbox360 and other HDMI devices

Operation Notes

 Specifications are subject to change without notice.

 Insert/ unplug transmission cables gently.

FEATURES      DisplayPort to HDMI Converter

2



Features

 Supports DisplayPort1.2 and 4 lanes.

 AC coupling capable for level shifting

 Support DisplayPort 1.2a input and HDMI1.4b output.

 Support 4K X 2K & 3D video formats over HDMI

 Supports multiple color format: RGB 6/8/10/12-bit per component (bpc) and YCbCr4:4:4,

YCbCr4:2:2, 8/10/12bpc.

 Compliant to HDMI 1.4b specification up to 3.0Gbps.

 Supports 10/12-bit deep color 1080p up to 2.25Gbps.

Package Includes

1) DisplayPort to HDMI Converter X1

2) User Manual X1

Produktspecifikationer

Varumärke:	Nedis
Kategori:	Nätverkskort/adapter
Modell:	CCBW37915AT
Maximal upplösning:	3840 x 2160 pixlar
Anslutning 1:	DisplayPort Male
Anslutning 2:	HDMI Male
Produktens färg:	Antracit
Förpackningstyp:	Låda
Plätering på anslutningskontakter:	Guld
