INSTALLATION MANUAL

Motorized TV Mount

50kg

(110lbs)

RATED

Use with products heavier than the rated weights indicated may result in instability causing possible injury.

Please closely follow the assembly instructions. Improper installation may result in damage or serious personal injury.

Safety gear and proper tools must be used. This product should only be installed by professionals.

Make sure that the supporting surface will safely support the combined weight of the equipment and all attached hardware and components.

Use the mounting screws provided and DO NOT OVER TIGHTEN mounting screws.

This product contains small items that could be a choking hazard if swallowed. Keep these items away from children.

This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.

Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, contact your place of

purchase for a replacement.

Check that the product is secure and safe to use at regular intervals (at least every three months).

200x200/300x300

400x200/400x400

600x400

65"

MAX

Instructions of Safety and Warnings:

Notifications:

Disposal:

The product with this mark indicates that this product shouldn't be disposed with other household wastes

throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste

disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used

device, please use your local recycle service or contact your point of purchase to withdrawn the product.

·Any Incomplete Observation of the Instructions, Warnings and Additional Information Marked with the "Note" Symbol may Result in

Serious Damage to the System or its Components.

·This Product can be Used by Children Aged from 8 Years and above if They have been Given Supervision or Instruction Concerning

Use of the Appliance in a Safe Way and Understand the Hazards Involved. Children shall not Play with the Appliance. Cleaning and User

Maintenance shall not be Made by Children without Supervision.

·Persons with Reduced Physical, Mental Abilities and or Lack of Experience and Knowledge must not Use the Product, unless They're

under Supervision, Understand the Hazards involved or they have been Thoroughly Instructed in the Use of the Apparatus by a Person

who is Responsible for the Safety of these Persons.

·Users should Make Sure that They Never Lean against the TV Mounted on the Product in Order to Prevent Serious Bodily Injury.

Any Failure to Comply with the Safety and Installation Instructions in this Manual may Cause Serious Bodily Injury.

Unplug if doesn t use the System for long time and Place the Power '

Plug out of Children Reach.

This motorized TV lift consists of a heavy duty mounting bracket and a powerful lifting system Please read and completely - .

understand this manual before installation in order to make sure the safe and correct use of the system and maintain the

longevity of the overall construction and the built-in electronics.

Electrical Safety Instructions

The product is powered by electricity. In order to avoid burns, fire and electric shock, please read the instructions carefully.

·Don't clean the product while the power is still connected.

·Don't disassemble or replace components while the power is still connected.

·Never operate the system with a damaged cord or plug. Please contact your point of purchase to replace the damaged parts.

·Never operate the system if it's in moist environment or its electrical components has contact with liquids.

·Alterations of the Given and Remote Control aren't allowed.

·Outdoor use is prohibited.

Control Unit If either of them is missing or faulty, contact your place of

purchase for a replacement.

Please check all of the components shown in the component checklist. If any of the components are missing or damaged,

contact your point of purchase for a replacement.

Other Safety Instructions

·Don't leave the cords or plug unorganized in order to prevent tripping hazards.

·Any attempts to reconstruct the construction aren't allowed.

·Don't add anything to the opening of the product.

Clear up all obstacle within the range of motion.

STEP1: When the motorized TV lift is powered on, press and release the button inside the

control box as shown. It will beep once. After that, the remote control and the control

box begin to match. (This process will take at most 10 seconds)

STEP2: , . Press and release button on the remote control then you will hear beeps Wait

, for 10 seconds until hearing the final beep the matching will complete and exit the

. , .program Now you can control your TV lift directly from the remote control

: , . Note Before matching a different remote control the previous data need to be cleared

Press the button inside the box again as shown for 10 seconds until hearing a beep.

Remote Control Operation Instructions

A. Match the Remote Control with the Control Box

B. Introduce Button Function

Upward movement

Press until getting the desired position.

Downward movement

Press until getting the desired position.

To set a memory

Press for 3 seconds until hearing a beep.

To quick get to the memory position

Press and release.

(mem1 is corresponding to 1,

mem2 is corresponding to 2)

Reset mode

Press for 3 seconds until hearing a beep.

Beeping twice indicates the process is finished.

To get back to initial position

Press and release.

If need to stop, press again during the process.

Note: Attach TV with the column adjusted

to the lowest position.

VSM5830BK

Produktspecifikationer

Varumärke:	Nedis
Kategori:	TV-skåp
Modell:	TVSM5830BK
Typ av operation:	Knoppen
Färg på produkten:	Zwart
Inbyggd display:	Ja
Vikt:	17500 g
Bredd:	660 mm
Höjd:	1910 mm
Blixtlägen:	Rode-ogen-reductie
siffra:	1
Maximal räckvidd:	100 m
Fjärrstyrd:	Ja
Kompatibilitet:	Canon 500D 550D 600D 650D 700D 1000D 1100D 50D 60D 70D 1D 1D2 1D3 1D4 1Ds 1Ds2 1Ds3 1DX 1DC 5D 5D2 5D3 6D 7D
Fjärrkontroll ingår:	Ja
Typ produkt:	Ontvanger
Maximal skärmstorlek:	65 "
Type beeldscherm:	LCD
Minsta skärmstorlek:	37 "
Kompatibla kameramärken:	Canon
Märkesspecifika blixtsystem:	E-TTL I (Canon)
Blixtsynkroniseringshastighet:	1/8000 s
Maxvikt:	50 kg
Produktens färg:	Svart
Antal per förpackning:	1 styck
Material, hölje:	Stål
Monteringssätt:	Bord
Strömförbrukning i vänteläge:	0.5 W
Harmonized System (HS)-kod:	85299097
Gränsssnitt för panelmontering:	200 x 200,300 x 300,400 x 200,400 x 400,600 x 400 mm
Höjdjustering:	Ja
Antal displayer som stöds:	1
Monteringsgränssnitt kompatibilitet (min):	200 x 200 mm
Monteringsgränssnitt kompatibilitet (max):	600 x 400 mm
Höjdjusteringsintervall:	680 - 1580 mm
Djup (min):	215 mm
