Sida 1/16

Quick start guide

USB Audio/Video Converter

VGRRU101BK

For more information see the extended manual

online: ned.is/vgrru101bk

Intended use

This product is intended as a USB Audio/Video Converter.

This product is intended to digitize analogue audio and

video signals.

The product is intended for indoor use only.

Any modication of the product may have consequences for

safety, warranty and proper functioning.

Main parts (image A)

1 SCART adapter

2 RCA video input

3 RCA audio input (R)

4 RCA audio input (L/Mono)

5 S-Video input

6 RCA A/V cable

7 USB output

Safety instructions

WARNING

• Ensure you have fully read and understood the

instructions in this document before you install or use the

product. Keep the packaging and this document for future

reference.

• Only use the product as described in this document.

• Do not use the product if a part is damaged or defective.

Replace a damaged or defective product immediately.

• Do not drop the product and avoid bumping.

• This product may only be serviced by a qualied

technician for maintenance to reduce the risk of electric

shock.

• Do not expose the product to water or moisture.

• Disconnect the product from the power source and other

equipment if problems occur.

Connecting the product (image B)

1 Input devices 2 computer

Installing the software

OBS is a free computer program that records video and

audio.

1. Download OBS via: https://obsproject.com/

2. Follow the instructions of the installation wizard.

3. Open the software.

4. Click + in the ‘source’ window.

5. Click Video Capture Device in the pop-up menu.

6. Click Create new.

7. Enter a name in the box.

8. Click OK to create a new video capture device.

A pop-up window appears. Follow the steps below to adjust

the video settings.

9. Click Device.

10. Select AV-USB 2.0.

If ‘AV-USB 2.0’ does not appear in the list, make sure the

product is connected properly.

11. Customize the video resolution and frames per second.

The video settings are set. Follow the steps below to adjust

the audio settings.

12. Click Audio output mode.

13. Select Output desktop audio (DirectSound).

14. Click Use custom audio device.

15. Select USB 2.0 MIC.

If ‘USB 2.0 MIC’ does not appear in the list, make sure the

product is connected properly.

Using the product

1. See image B for a connection overview.

2. Record audio and video using your preferred software.

See ‘Installing the software’ for instructions on how to

install a free audio and video recording software.

Kurzanleitung

USB-Audio/Video-Wandler

VGRRU101BK

Weitere Informationen nden Sie in der

erweiterten Anleitung online: ned.is/vgrru101bk

Bestimmungsgemäße Verwendung

Dieses Produkt ist als USB-Audio/Video-Wandler gedacht.

Dieses Produkt ist dazu gedacht, analoge Audio- und

Videosignale zu digitalisieren.

Das Produkt ist nur zur Verwendung innerhalb von

Gebäuden gedacht.

Jegliche Modikation des Produkts kann Folgen für die

Sicherheit, Garantie und ordnungsgemäße Funktionalität

haben.

Produktspecifikationer

Varumärke:	Nedis
Kategori:	Audio/video-omvandlare
Modell:	VGRRU101BK
Vikt:	36 g
Bredd:	23 mm
Djup:	56 mm
Höjd:	10 mm
Värdgränssnitt:	USB 2.0
Windows-operativsystem som stöds:	Windows 10, Windows 7, Windows 8
AC-inspänning:	5 V
Antal SCART-kontakter:	1
Bildupplösning vid videoinspelning (max):	852 x 480 pixlar
Harmonized System (HS)-kod:	85176990
Intern:	Nej
Nätaggregatstyp:	USB
Antal S-Video-ingångar:	3
Tas in från:	VCR
