Insert the connecting part of the Fresnel lens into the Bowens mount

of the CB300B light head and turn it clockwise to lock it in place.

Removing the Fresnel lens

(using the NEEWER CB300B as an example):

Package Contents

Installation Instructions

Safety Precautions

1 x Fresnel Lens

1 x Barndoor

1 x Carrying Bag

1 x User Manual

Do not look directly at the light source when using LED

photography lights to avoid eye damage.

When used with LED photography lights, the temperature of

the Fresnel lens will increase. Care should be taken not touch

it with bare hands.

The Fresnel lens is fragile and should be held gently to avoid

damage.

To prevent the device from falling, please secure the Fresnel

lens and accessories before focusing.

Installing the Fresnel lens

(using the NEEWER CB300B as an example):

Press down on the locking button located on the upper part of the

CB300B light head to unlock it. At the same time, rotate the Fresnel

lens counterclockwise and remove it from the Bowens mount.

Ensure that both actions are carried out simultaneously to smoothly

dismantle the Fresnel lens.

Installing the Barndoor:

1. Avoid direct eye contact with the light to prevent visual

impairment.

2. Refrain from disassembling any components not mentioned

in the manual, unless instructed by a member of our Customer

Support team.

3. Ensure all knobs and latches are securely locked during use.

4. Maintain device stability when removing or replacing

components to prevent accidental falls.

5. Do not subject the product to physical impact or allow it to

knock against other products.

6. Clean the product with a soft cloth and mild detergent

periodically, followed by drying it with a clean cloth.

7. When not in use for an extended period, please store the

product securely.

Model

Focus Range

Beam Angle Adjustable

Working Temperature

Storage Temperature

Product Weight

CSF10

10 to 35°

Variable beam angle in the light range of 10° to 35°.

-10℃～40℃

-20℃～65℃

9.1lb/4.13kg

Installation Instructions Performance

Speciﬁcations

Notes

1.5m

6800 LUX

22000 LUX

14800 LUX

49300 LUX

24500 LUX

84500 LUX

51000 LUX

177000 LUX

Center Illuminance Distribution Diagram

(using CB300B 5600K as an example):

Note: Illuminance values are averages and may vary slightly

from diﬀerent lights.

② Insert the fresnel with the

frame set at a slightly diagonal

angle into the installation slot

of the barndoor.

① First, push the retention

latches on the barndoor

outward to ensure it doesn't

obstruct the mounting hole.

③ Insert the Fresnel lens into

the mounting holes on the

barndoor, and ﬁnally, push

the retention latch back to

complete the installation.

Measured at 1m from the light source.

Floodlight

Spotlight
