Läs gratis den bruksanvisning för Neff T27DA79N0D (16 sidor) i kategorin Ugn. Guiden har ansetts hjälpsam av 5 personer och har ett genomsnittsbetyg på 4.9 stjärnor baserat på 3 recensioner. Har du en fråga om Neff T27DA79N0D eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/16

[en] INSTRUCTION MANUAL

GAS HOB

T26DA....., T27DA....., T29DA....

! Pan supports

" Control knobs

# Economy burner with an output of up to 1 kW

$ Standard-output burner with an output of up to

1.75 kW

% High-output burner with an output of up to 3 kW

& Mini wok burner up to 3.5 kW

' Dual-wok burner with an output of up to 5 kW

7'$









7'$









7'$











7'$











7'$











7'$











Table of contents

[en]INSTRUCTI ON MANUAL

8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

( Important safety information . . . . . . . . . . . . . . . 4

* Getting to know your appliance . . . . . . . . . . . . . 5

Controls and burners . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Residual heat indicator. . . . . . . . . . . . . . . . . . . . . . . . . 6

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Ä Gas burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Switching on manually . . . . . . . . . . . . . . . . . . . . . . . . . 7

Automatic ignition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Safety system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Switching off a burner . . . . . . . . . . . . . . . . . . . . . . . . . 7

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

J Settings table and tips. . . . . . . . . . . . . . . . . . . . . 7

Suitable pans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Instructions for use. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Table of cooking times. . . . . . . . . . . . . . . . . . . . . . . . . 8

2 Cleaning and maintenance . . . . . . . . . . . . . . . . 12

Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 12

4 Customer service . . . . . . . . . . . . . . . . . . . . . . . . 13

Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . 13

7 Environmental protection . . . . . . . . . . . . . . . . . 14

Environmentally-friendly disposal . . . . . . . . . . . . . . . . 14

Produktinfo

Additional information on products, accessories,

replacement parts and services can be found at

www.neff-international.com and in the online shop

www.neff-eshop.com

8Intended use

Intended use

Read these instructions carefully. You will only

be able to use your appliance safely and

effectively when you have read them. These

operating and installation instructions should

be retained, and passed onto the buyer if the

appliance is sold.

The manufacturer is exempt from all

responsibility if the requirements of this

manual are not complied with.

The images shown in these instructions are for

guidance only.

Do not remove the appliance from its

protective packaging until it is installed in the

unit. Do not switch on the appliance if it is

damaged in any way. Contact our Technical

Assistance Service.

This appliance is class 3 type, according to

the EN 30-1-1 regulation for gas appliances:

built-in appliance.

Before installing your new hob, ensure that it is

being installed according to the installation

instructions.

This appliance cannot be installed on yachts

or in caravans.

This appliance must only be used in well

ventilated places.

This appliance is not intended for operation

with an external clock timer or a remote

control.

All operations relating to installation,

connection, regulation and conversion to

other gas types must be performed by an

authorised technician, respecting all

applicable regulations, standards and the

specifications of the local gas and electricity

suppliers. Special attention shall be paid to

ventilation regulations.

This appliance leaves the factory set to the

gas type that is indicated on the specifications

plate. If this needs to be changed, please

consult the assembly instructions. It is

recommended you contact the Technical

Assistance Service to change to another gas

type.

This appliance has been designed for home

use only, not for commercial or professional

use. This appliance is only intended for

Produktspecifikationer

Varumärke:	Neff
Kategori:	Ugn
Modell:	T27DA79N0D
Vikt:	13000 g
Bredd:	750 mm
Djup:	520 mm
Höjd:	45 mm
Sladdlängd:	1 m
Elektronisk tändning:	Ja
Antal gasbrännare:	5
Certifiering:	CE
Produktens färg:	Svart, silver
Kontrolltyp:	Rotations-
Vikt inkl. förpackning:	14000 g
Wok brännare:	Ja
AC-inspänning:	220-240 V
Apparatens placering:	Inbyggd
Växelström Frekvens:	50 - 60 hz
Ström:	3 A
Installationsfack, bredd:	560 mm
Installationsfack, djup:	492 mm
Installationsfack, höjd:	45 mm
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	5
Kokzon 3, form:	Rund
Placering av platta/tillagningsyta 4:	Höger bak
Typ av platta/tillagningsyta 4:	Stor
Typ av platta/tillagningsyta 3:	Sjudning
Kokzon 1, form:	Rund
Placering av platta/tillagningsyta 3:	Mitten fram
Kokzon 2, form:	Rund
Strömförsörjning till platta/tillagningsyta 3:	gas
Typ av platta/tillagningsyta 1:	Extra stor
Placering av platta/tillagningsyta 2:	Mitten bak
Strömförsörjning till platta/tillagningsyta 4:	gas
Strömförsörjning till platta/tillagningsyta 2:	gas
Typ av platta/tillagningsyta 2:	Vanlig
Kokzon 4, form:	Rund
Strömförsörjning till platta/tillagningsyta 1:	gas
Placering av platta/tillagningsyta 1:	Vänster
Sjuda brännare / kokzon:	1000 W
Regelbunden brännare / kokzon:	1750 W
Stora brännare / kokzon:	3000 W
Manöverplats:	Framsida
Maximal kabelförlust med anslutning:	Ja
Effekt på platta/tillagningsyta 1:	5000 W
Effekt på platta/tillagningsyta 2:	1700 W
Effekt på platta/tillagningsyta 3:	1000 W
Extra stor hög hastighet brännare / kokzon:	3500 W
Effekt på platta/tillagningsyta 4:	3000 W
Typ av ytskikt:	Rostfritt stål
Anslutningseffekt (elektrisk):	2 W
Installation fack djup (min):	480 mm
Installation fack djup (max):	492 mm
Anslutningseffekt (gas):	12500 W
Wok brännare läge:	Vänster
Effekt på platta/tillagningsyta 5:	1700 W
Wokbrännarens effekt:	5000 W
Typ av platta/tillagningsyta 5:	Vanlig
Kokzon 5, form:	Rund
Placering av platta/tillagningsyta 5:	Höger fram
Strömförsörjning till platta/tillagningsyta 5:	gas
Antal kokzoner som kan användas samtidigt:	5
Hällskydd för spishäll:	Nej
Form på standardplatta/tillagningsyta:	Rund
Form på stor platta/tillagningsyta:	Rund
Form på småkokningsplatta/tillagningsyta:	Rund
Form på extra stor höghastighetsplatta/tillagningsyta:	Rund
