Sida 1/31
User’s Manual
NOCPIX
ACE SERIES
Thermal Imaging Scope
1
Table of Contents
1. Overview .............................................................2
2. Features ..............................................................2
3. Tech Specs ...........................................................3
4. Accessories ..........................................................4
5. Components and Controls ...............................5
6. Description of Control Buttons & Shortcuts .. 6
7. Quick Start Guide ...............................................8
8. Charging the Built‑in Battery Pack ................9
9. Installing an 18650 Battery ..............................11
10. Battery Status Indicators ................................ 12
11. Switching the Battery Power Supply ............ 13
12. Battery Safety Warnings ................................ 14
13. External Power Supply .................................... 14
14. Operating Instructions .................................... 15
15. Zeroing the ACE Series ................................... 21
16. Non‑Uniformity Correction ............................22
17. Photography and Video Recording ...............23
18. Accessing the Internal Memory .....................25
19. Using The NOCPIX App ...................................26
20. Integrated Laser Rangefinder ........................27
21. Digital Zoom .....................................................28
22. Ultra‑Clear Mode .............................................28
23. Main Menu Options and Descriptions ...........29
24. Basic Inspection ............................................... 51
25. Basic Maintenance ............................................ 51
26. Warranty ............................................................52
27. FCC Statement .................................................53
28. General Troubleshooting ...............................53
29. Notes ..................................................................56
WARNING: CHOKING HAZARD
Children under 3 years old can choke or suocate on small parts of
this product. This product is not a toy; keep out of reach of children.
CAUTION
Use of controls or adjustments or performance of procedures other than those specied
herein may result in hazardous radiation exposure.
2601 State Hwy 121, Building 3, Suite 306, Lewisville, TX 75056
800.769.7125 info@irayusa.com
NOTICE: This product is a Class 3R laser product.
Explanatory Label Mfr ID and Certication Label
Laser Aperture
(Integrated into
the Objective)
WARNING!
ITAR REQUIREMENTS
These products may be subject to export and foreign trade control laws of
the United States and may not be exported without prior approval of the U.S.
Department of State. Learn more at irayusa.com/ITAR.
NOTE: There is no scheduled maintenance or service necessary to keep this product
in compliance and no user service or maintenance is required.
This Laser Product is designated as Class 3R during all procedures of operation.
Wavelength: 900 nm
Laser Power for Classication: <700nJ
Emission Type: Pulsed, Invisible
Pulse Width: 42 nSec
Emission Frequency 10 kHz
INVISIBLE LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
NOTES:
• There is no service required or allowed of this product by the end user.
• This product is to be serviced or repaired only by factory authorized technicians.
• This product is not to be opened or modied by the user.
• The user is not to modify the unit or remove protective covers or housing. Service
is only to be handled by authorized factory trained technicians. This product has no
user-serviceable parts.
• Do not point laser or allow laser light to be directed or reected toward other people
or reective objects.
• Operators should be trained to not target the eyes of people, animals, and pets or
aim at reective objects, etc.
• There is a potential hazard of eye or skin exposure to laser radiation if the included
instructions are not followed.
• This laser is never to be operated if the unit is defective or the cover or seal is
damaged.
• Always operate the product with the aperture pointed downrange.
