Sida 1/8
CVT8- 5G
Fiber Converter
Specications
CVT8- Fiber Converter Specications 5G
www.novastar.tech
1
Change History
Document Version
Release Date
Description
V1.0.4
2024 08- -10
Update the ber type and transmission distance for the multi-
mode optical module.
V1.0.3
2024 05- -07
Added Ethernet cable requirements.
V1.0.2
2024 11- -06
Updated the certication information.
V1.0.1
2023 18- -05
Updated the operating temperature range.
V1.0.0
2022 10- -07
First release
Introduction
The CVT8- ber converter oers a cost-eective way conversion between optical signals and electrical signals 5G of
for video sources to connect the sending card to the LED display. Delivering a full-duplex, ecient and stable data
transmission that is not easily interfered with, this converter is ideal for long-distance transmission.
The CVT8-5G hardware design focuses on the practicality and convenience of the on-site installation. It can be
mounted horizontally, in a suspended way, or rack mounted, which is easy, secure and reliable. For rack mounting,
two CVT8-5G devices, or one CVT8-5G device and a connecting piece can be combined into one assembly that is
1U in width.
Certications
RoHS, CE, FCC, IC, UL, CB
If the product does not have the relevant certications required by the countries or regions where it is to be
sold, please contact NovaStar to conrm or address the problem. Otherwise, the customer shall be
responsible for the legal risks caused or NovaStar has the right to claim compensation.
Features
Models include the CVT8- S (single-mode) and the CVT8- M (multi-mode). 5G 5G
1x optical port with bandwidth up to 40 Gbit/s and supports hot-swapping. (Ships with pre-installed optical
modules)
8 5G BaseT Ethernet ports, bandwidth of each up to 5 Gbit/s (supports CAT6 cables up to 100 meters) x
1x type-B USB control port
Appearance
Front Panel
CVT8- Fiber Converter Specications 5G
www.novastar.tech
2
Name
Description
USB
Type-B USB control port
Connect to the control computer (NovaLCT V5.4.0 or later) for upgrading the CVT8-5G program,
not for cascading.
PWR
Power indicator
Always on: The power supply is normal.
STAT
Running indicator
Flashing: The device is functioning normally.
OPT1
Optical port indicator
Always on: The optical ber connection is normal.
1 8 –
Ethernet port indicators
Always on: The Ethernet cable connection is normal.
Rear Panel
Name
Description
100-240V~,
50/60Hz, 1.5A
Power input connector
ON: Turn on the power.
O : Turn o the power. FF
For the PowerCON connector, users are not allowed to plug in hot.
Pour le connecteur PowerCON, les utilisateurs ne sont pas autorisés à se connecter à chaud.
OPT
40G optical port
CVT8- S optical module description: 5G
The optical port supports -swapping hot
Transmission rate: 40 Gbit/s
Wavelength: 1310 nm
Transmission distance: 10 km
CVT8- S optical ber selection: 5G
Model: OS1/OS2
Transmission mode: Single-mode twin-core
Cable diameter: 9/125 μm
Connector type: LC
Insertion loss: ≤ 0.3 dB
Return loss: ≥ 45 dB
