IMPORTANTSAFETYINSTRUCTIONS
WARNING:TOREDUCETHERISKOFFIRE,
ELECTRICSHOCK,ORINJURYTOPERSONS,OBSERVETHE
FOLLOWING:
A.Usethisunitonlyinthemannerintendedbythemanufacturer.Ifyou
havequestions,contactthemanufacturer.
B.Beforeservicingorcleaningunit,switchpoweroffatservicepaneland
lockservicepaneltopreventpowerfrombeingswitchedonaccidentally.
Whentheservicedisconnectingmeanscannotbelocked,securely
fastenaprominentwarningdevice,suchasatag,totheservicepanel.
CAUTION:
Forgeneralventilatinguseonly.Donotusetoexhausthazardousor
explosivematerialsandvapors
.
INSTALLATIONINSTRUCTIONS
WARNING:TOREDUCETHERISKOFFIRE,
ELECTRICSHOCK,ORINJURYTOPERSONS,OBSERVETHE
FOLLOWING:
A.Installationworkandelectricalwiringmustbedonebyqualified
person(s)inaccordancewithallapplicablecodesandstandards,
includingfire-ratedconstruction.
B.Sufficientairisneededforpropercombustionandexhaustingofgases
throughtheflue(chimney)offuelburningequipmenttopreventback
drafting.Followtheheatingequipmentmanufacturer'sguidelineand
safetystandardssuchasthosepublishedbytheNationalFire
ProtectionAssociation(NFPA),andtheAmericanSocietyforHeating,
RefrigerationandAirConditioningEngineers(ASHRAE),andthelocal
codeauthorities.
C.Whencuttingordrillingintowallorceiling,donotdamageelectrical
wiringandotherhiddenutilities.
D.Ductedfansmustalwaysbeventedtotheoutdoors.
E.Ifthisunitistobeinstalledoveratuborshower,itmustbemarkedas
appropriatefortheapplication.
F.NEVERplaceaswitchwhereitcanbereachedfromatuborshower.
•
WARNING:Toreducetheriskoffireorelectricshock,donotuse
thisfanwithanysolid-statespeedcontroldevice.
•
WARNING:Toreducetheriskofshock,disconnectpowerbefore
servicing.
•
Notforuseinkitchens.
•
DonotinstallinaceilinginsulatedtoavaluegreaterthanR-40.
•
Forinstallationinslopedceilingsupto7/12pitch,ductworkmustpointup.
FORBESTRESULTS
Fornewconstructioninstallthehousingduringtherough-instageof
construction.Theblowerunit,lightandgrilleshouldbeinstalledafterthe
finishedceilingisinplace.
ToinstalltheExhaustFan-Lightinanexistingfinishedbuildingrequires
anaccessiblearea(atticorcrawlspace)abovetheplannedlocation.
PLANNINGDUCTWORKANDWIRING
DUCTWORK
1.Use4"roundduct.
2.Plantorunductfromthefan'sdischargeopeningtotheoutside.For
bestfanperformance,makeductrunasshortaspossibleanduse
minimumnumberofelbows.
3.UseoptionalNoneductingaccessoriesasneeded(refertoNone'suTuT
catalogforacompletelistingofoptionalaccessories).
WIRING
Plantorun120vAChousewiring(withground)fromapowersource,
throughastandardwallswitchoranoptionalNuTonedoubleFAN/LIGHT
switch,tothejunctionboxintheFan-Light'shousing.
INSTALLATIONINANEW
CONSTRUCTIONSITE
PREPARATION
1.Unplugthepowerunit.
2.RefertoFigure1.Removepowerunit/blowerassemblyfromthe
housing.Removescrewandpullpowerunitassemblytabsoutofslots
inhousing.Setunitasideuntilneeded.
3.Removeoneofthewiringknockoutsfromhousing.
MOUNTINGTHEHOUSING
USINGSIDEMOUNTINGTABS
RefertoFigure2.
1.Locatehousingnexttoceilingjoist.
2.Usewoodscrews(notprovided)tolooselyattachhousingtoceiling
joistthroughkeyholeslotsinmountingtabs.
3.Adjusthousingsothatitwillbeflushwiththefinishedceiling.
4.Whenhousingisproperlyadjusted,tightenscrewsinslots.
USINGHANGERBARS
(Hangerbarssoldseparately,ordermodelHB4)
RefertoFigure3.
1.Inserthangerbarsinslotsprovidedinhousing.
2.Locatefanhousingbetweenceilingjoistssothatbottomoffanhousing
isevenwiththeplannedfinishedceiling.
3.Usescrewsornailstosecuremountingbracketstoceilingjoists.
INSTALLINGDUCTWORK
1.RefertoFigure1.Placeductcollaroverflangesatdischargeopening
offan.Securecollarbysnappingtabsintoslotsinflanges.
2.RefertoFigure4.Run4"roundductfromoutsidetofan'sdischarge
opening.
3.Connectducttoductcollar.
INSTALLATIONINSTRUCTIONS
R
EAD&SAVETHESEINSTRUCTIONS!
CeilingFan-Light
MODEL:769RL
SUITABLEFORUSEOVERTUBORSHOWERENCLOSURE
WHENINSTALLEDINAGFCIPROTECTEDBRANCHCIRCUIT.
TOREGISTERTHISPRODUCT,VISITWWW.NUTONE.COM
