Sida 1/19

Instruction Manual

OMEGA OVEN

OBO691TGG

Thank you for purchasing an Omega appliance

Tailored for the modern aesthetic and lifestyle of busy people, your new Omega Appliance will make a

welcome addition to the family.

Omega caters to style-savvy customers who look for balance between stunning form and clever function.

This means a combination of sleek, chic, sophisticated design yet effortless functionality.

And we source from the best. The best craftsmanship. The best innovation. From the best international

design houses.-

All brought together under an appliance that stands for design led balance.-

Please take the time to read through the following instruction manual to familiarise yourself with the

installation, operation requirements and maintenance to ensure optimum performance.

Further Information

For important information about your Omega Appliance such as warranty registration, manuals, features,

and specifications please visit (if you are in Australia) and omegaappliances.com.au

omegaappliances.co.nz (if you are in New Zealand) or contact our Customer Care team on the below email

or phone numbers.

Registering Your Warranty

For peace of mind you can register your warranty . Further information on the at omegaappliances.com.au

Warranty can be found at the end of this manual.

Our customer service here to help you with any question or concern. team is

They are on call Monday to Friday 8.30am to 5.00pm and of course you can always send a email at your

convenience.

Email: customercare@omegaappliances.com.au

Phone: 1300 739 033

To stay up to date and find simple and easy recipes, follow us on our socials:

facebook.com/omegaappliances

instagram.com/omegaappliances_aus

RE BEFORE INSTA ING IN AD THE INSTRUCTION BOOKLET LL AND US G THE

LIAN

CE.

It is important that you retain these instructions, proof of purchase as well as other important

documents about this product for future reference.

The manufacturer will not be responsible for any damage to property or to persons caused by

incorrect installation or improper use of the appliance.

Due to continual product development, Omega reserves the right to alter specifications and appearances

without notice.

Contents

Important Safety Warnings ............................................................................................................................................... 1

Appliance Details ............................................................................................................................................................... 2

Electrical Connections ....................................................................................................................................................... 2

Installation Instructions.................................................................................................................................................. 3-4

Operating Instructions 5- ................................................................................................................................................. 12

Accessories ...................................................................................................................................................................... 13

Replacing the Oven Lamp................................................................................................................................................ 13

Cleaning ........................................................................................................................................................................... 14

Troubleshooting .............................................................................................................................................................. 14

Australian & New Zealand Product Warranty Statements of Standard Warranty Conditions ....................................... 15

Disposal Information

• Most of the packaging materials are recyclable. Please dispose of these materials through your local recycling

depot or by placing them into appropriate collection containers.

• If you wish to discard this product, please contact your local authorities and ask for the correct method of

disposal.
