Sida 1/2
Contact Details for Oricom Support
and Warranty claims in Australia
Oricom International Pty Ltd
Unit 1, 4 Sovereign Place
South Windsor, NSW 2756
Australia
Email: support@oricom.com.au
Phone: (02) 4574 8888 (Monday to
Friday 8am to 6pm AEST)
Web: www.oricom.com.au
Fax: (02) 4574 8898
Contact details for Oricom Support
and Warranty Claims in New Zealand
Email: support@oricom.co.nz
Phone: 0800 674 266
(Monday to Friday 10am to 8pm NZST)
ORICOM BRACKETMBL001 / MBL002 User Guide
• A completed Return Authorisation form
• A copy of your Proof of Purchase (please keep your original copy)
• The faulty product, including all accessories.
Send the approved returns to: Oricom
International Pty Ltd Locked Bag 658
South Windsor NSW 2756 Australia
Please note that this Express Warranty excludes expenses incurred by you in
returning any faulty product to us. You must arrange and pay any expenses
incurred (including postage, delivery, freight, transportation or insurance of the
product) o return the faulty product to us, however, we will t arrange delivery of the
repaired or replaced faulty product to you.
Important Information
Repair Notice
Please be aware that the repair of your goods may result in the loss of any user-
generated data (such as stored telephone numbers, text and contact messages
information). Please ensure data saved on that you have made a copy of any
your goods before sending for repair.
Please also be aware that goods presented for repair may be replaced by
refurbished goods or parts of the same type rather than being repaired.
MBL001 / MBL002
FITTING INSTRUCTIONS (For use with Oricom range of detachable antenna whips)
Choose a location:
1) Select an open position which will work to reduce the signal shadowing, and in turn,mounting ,
improve transmission range. The antenna should be mounted as far as possible from any
metal structure, including . vertical metal strips, cables, rods or railing
2) When selecting a position, ensure that the cable routing and distance to radio are considered.
It should also be considered that antenna whip will flex during motion, which will add stress tos
the bracket mounting point. A flat surface will aid in reducing any stress on the mounting
bracket.
3) Ensure that the selected location is free of electrical wiring, or other hazard, before safely
commencing the install (as per below instruction)ation .
4) An important consideration is the ability to fold down antenna bracket and whip, when not in
use. Select a location where the desired fold down of antenna whip is suitable.
USER GUIDE ORICOM ANTENNA BRACKET - VHF MBL001/MBL002
Installation:
1) Each marine bracket is supplied with a drilling template, located on the reverse side of the
bracket packaging card. Locate the template, and in the desired location, use this template as
your guide, drilling from the outside. Ensure that the antenna fold down position is considered
before drilling a hole.
2)
3)
Each of the four securing holes can be drilled using a suitable 7mm drill bit.
If the desire is to have the coaxial cable passing through the base of the bracket, blind holes
have been allocated for reference on the drilling template. It is recommended that a mm9.5
drill bit is used to remove the blind hole. The blind hole will also need to be removed from the
antenna base, so using the mm drill bit, locate the matching hole, and remove.9.5
4) Once holes are removed, antenna coaxial cable can be fed through the drilled hole on the
base of the bracket, and through the hole drilled into the suitable boat location. Each bracket
includes a split rubber grommet, which is designed to be wrapped around cable on underside
of the base of the bracket, and securely pushed into place in drilled hole. This is to ensure that
when the base is screwed into place, there is a seal of the gap between the cable and the
base.
5) Each of the four affixing screws can now be tightened, but be careful not to over tighten which
could damage the base or vessel. It is recommended that after 1 month of use, that the
retention screws are tightened once more.
6) waterproof A neutral cure silicon sealant can be used around the base of the bracket, to
ensure that the bracket is affixed and secure.
7) toThe antenna coaxial cable can now be installed the radio.
Note: Each Oricom marine whip is factory pre-tuned and must not be altered in any way. It is not
recommended to cut or alter the supplied coaxial cable in any way.
