Sida 1/11

City Gas

Ambri

Delta

Milano

Porto

Ascona

Leon

Montreux

Geneva

Roma

Munich

Paris Deluxe

Venezia

www.outdoorchef.com

THE GAS KETTLE BARBECUE

MANUAL

Original OUTDOORCHEF Accessories

Item #: 18.211.51

Item #: 18.211.40 Item #: 18.211.41 Item #: 18.291.07

Item #: 18.291.08

Item #: 18.211.27

Item #: 18.211.22

Item #: 18.211.50 Item #: 18.211.52

Item #: 18.211.32

Item #: 18.211.30

Item #: 18.211.54

Item #: 18.211.24

Item #: 18.211.25

Item #: 18.211.29

Item #: 18.291.08

Item #: 18.291.05

Item #: 14.112.36 Item #: 14.421.16 Item #: various Item #: various Item #: 18.211.34 Item #: 14.421.12

Item #: 14.421.10 Item #: 14.112.18 Item #: 14.112.23 Item #: 14.112.35 Item #: 14.491.10 Item #: 14.491.16

Item #: 14.112.24 Item #: 14.212.06 Item #: various Item #: 18.291.23 Item #: 18.221.29

Item #: 18.221.30

Item #: 18.221.08

Gas-Cookingsystem

THE GAS KETTLE BARBECUE

User Guide

IMPORTANT: Please

make a note of your gas

barbecue’s serial number

on the back page of this

manual straight away. Depending on the model

the serial number can be found on the data

sticker which is either on the frame or on the base

plate. The serial number is important to ensure

queries, spare parts orders and warranty claims

can be dealt with easily. Please keep the instruc-

tion manual in a safe place. It contains important

information about safety, use and maintenance.

Please read these instructions carefully before using

your OUTDOORCHEF Gas Kettle Barbecue.

For Your Safety

Every person using this barbecue must understand

and exactly follow the ignition instructions. Do not

allow children to operate the barbecue. The user is

responsible for the correct assembly, handling and

maintenance of the barbecue. Disregard can cause

accidents.

Keep ﬂammable liquids, materials and spare gas

bottles away from the barbecue. Do not store or use

the barbecue or a spare gas bottle indoors.

Before starting up your Gas kettle barbecue, please

read, understand and observe the following instruc-

tions!

The barbecue is for outdoor use only. Keep it at a safe

distance of at least 1 meter from ﬂammable objects

(i.e. walls, projecting roofs, fences etc).

Gas Bottles

Gas bottles may have a maximum weight of 7.5 kg

when placed on the base plate. Position the bottle

on the designated spot, see assembly instructions.

Please make sure that the gas regulator and all other

connections are tightened. Conduct a “Leak Test”

before starting up the barbecue and after every

time you exchange the gas bottle. Gas bottles must

not be exposed to temperatures higher than 50 °C,

or stored in closed areas or in basements. Follow the

safety instructions mentioned on the gas bottle.

Safety Instructions

Operate your gas barbecue following these “Lighting

and Operating Instructions”.

• Thegasbarbecueisforoutdooruseonly.

• Never leave the barbecue unattended while in

use.

• Keepthebarbecueasafedistanceofatleast1

meter from ﬂammable objects (i.e. walls, project-

ing roofs, fences etc).

• WARNING:Somepartsbecomeveryhotduring

use, keep the barbecue out of the reach of chil-

dren.

• Keepammablematerialatasafedistanceaway

from the barbecue.

• Donotmovethebarbecuewheninuse.

• Donotpushapplianceswhicharettedwithcas-

tors over uneven surfaces or ledges!

• Wearprotectiveglovesoralongsleevedbarbe-

cue safety mitt when operating the barbecue.

• Afteruseturnoffthegassupplyonthebarbecue

ﬁrst and then turn off the gas cylinder.

• Whenchangingthegascylinder,ensurethatthe

gas supply is turned off both at the barbecue and

at the gas cylinder and make sure there are no

combustible materials nearby.

• Aftereverygascylinderreplacement,carryoutthe

leak test to ensure that there are no leakages.

• Ifyouthinkthereisagasleak,turnoffthebar-

becue and gas cylinder immediately and have the

ﬁttings checked by your local gas distributor.

• Ifthetubeisdamagedorwornout,replacethe

tube and regulator immediately. The tube must be

kept straight at all times. Ensure that it does not

bend or twist. Remember to turn off the gas sup-

ply on the barbecue and the gas cylinder before

removing the tube.

• OUTDOORCHEFrecommendsthatthegastube

and gas regulator be changed every two to three

years.

• Ensurethattheairventsinthebarbecuelidand

base remain clear at all times.

• Important:Ensurethatthegastubeisroutedaway

from the hot barbecue surfaces and that it is not

bent or twisted.

• Donotchangeoralteranyofthebarbecuecom-

ponents or settings.

• Important:Ensurethecorrectregulatorisused:28

mbar butane (not supplied but available locally),

37 mbar ﬁxed (not adjustable) propane (not sup-

plied but available locally).

• Ifthebarbecueisnotworkingatfullcapacityorif

there is suspicion of a blocked gas supply, consult

your local gas distributor.

Typ:

PIN 0063 BP 3505

DKB Household Switzerland AG

Eggbühlstrasse 28 8052 Zürich

0063 2013

Made in China

Cat.I

=30mbar

3 B/P

DK NO NL SE LU

=28-30/37mbar

Cat.I

GB FR BE

IT CH

30/37 mbar

Butane / Propane

G30 / G31

CZ RO

Serial No.:

Article No.:

Side burner: Qn=3.80kW(276g/h)

Kettle: large burner Qn=8.50kW(612g/h) small burner Qn=1.20kW(90g/h)

Total rate ∑Qn=9.70kW(702g/h)

X00X00--/00/00/00000

Produktspecifikationer

Varumärke:	Outdoorchef
Kategori:	Utegrill
Modell:	City Gas
Värmekälla:	gas
Bredd:	440 mm
Djup:	500 mm
Höjd:	- mm
Elektronisk tändning:	Ja
Modell:	Grill
Termometer:	Ja
Lock:	Ja
Ben:	Ja
Produktens färg:	Vit
Formfaktor:	Kittel
Antal ben:	3 ben
matlagningsyta:	1213 cm ^
Antal brännare / zoner matlagning:	1
Styrhjul:	Nej
Inbyggd förmåga:	Nej
Typ av ytskikt:	Galler
Total effekt:	4300 W
Form på matlagningsyta:	Rund
Lockegenskaper:	Lock med gångjärn
Material, matlagningsyta:	Gjutjärn
Tändsystem:	Piezo
Matlagningsyta, diameter:	395 mm
