ENGLISH
Installation Instructions
Wall Mount Bracket
Thank you for purchasing this Panasonic Product.
J
The “Installation Instructions” is common to the following products.
Wall mount bracket: ET-WBC100
Projector mount bracket: ET-PKC300B
J
To customers
The “Installation Instructions” is intended for use by installation personnel. Be sure to employ certied
personnel to perform the installation. After installation, have the installation personnel return the “Installation
Instructions” to you, and save it for future use. When moving or removing the projector, give the “Installation
Instructions” to the installation personnel and have them perform the procedure.
J
To installation personnel
Carefully read the “Installation Instructions” and install this product correctly and safely.
Be sure to read through the section entitled “Read this rst!” (
x
page 3) before proceeding with
the installation.
After installation, return the “Installation Instructions” to the customer.
DPQX1662ZA/X1
Model No.
ET-WBC100
ET-PKC300B
ENGLISH
FRANÇAIS
DEUTSCH
日本語
ET-WBC100
ET-PKC300B
2 - ENGLISH
Contents
Read this rst! ................................................................................................... 3
Product description (ET-WBC100) ................................................................... 4
Product description (ET-PKC300B) ................................................................. 6
Installation dimensions (ET-WBC100) ............................................................. 7
Installation (ET-WBC100) ................................................................................ 10
Setting up the screen ........................................................................................................ 10
Screws tightening torques ................................................................................................ 10
Attaching the projector drop-prevention kit ........................................................................11
Installing the projector mount bracket kit to the projector ..................................................11
Installing the wall mount bracket to the wall ..................................................................... 12
Installing the projector to the wall mount bracket ............................................................. 13
Attaching the wire rope to the wall .................................................................................... 14
Attaching the covers ......................................................................................................... 15
Making adjustments (ET-WBC100) ................................................................ 16
Replacing projector mount bracket
(ET-PKC300B) ............................................. 20
Removing the connecting plate ........................................................................................ 20
Installing the connecting plate .......................................................................................... 21
Specications (ET-WBC100)........................................................................... 22
Appendix .......................................................................................................... 23
Installing the Wireless Presentation System Receiver ..................................................... 23
Installing the 4K Integrated Camera ................................................................................. 23
