THE ULTIMATE IN SOUND FOR MUSIC AND HOME THEATER™
IN-WALL / IN-CEILING SUBWOOFERS
Thank you for choosing award-winning Paradigm® in-wall/
in-ceiling subwoofer systems and congratulations! You are about
to hear the difference a sonically accurate subwoofer makes in your
audio/home theater system!
These subwoofers are the product of countless hours of comprehensive
research and development and will reward you with exceptional
sound for many years.
To ensure proper installation and enjoy all of the exceptional
sound they are designed to provide, please read this manual and
follow all instructions. If you have further questions contact your
Authorized Paradigm®Dealer or visit the Q&A page on our website
at www.paradigm.com.
IMPORTANT! Subwoofers covered by this manual are designed for use with a
Paradigm®Subwoofer Amplifier only. Use with any other brand of subwoofer amplifier
can cause permanent damage and will void the Paradigm®warranty.
OWNERS MANUAL OM-600
Paradigm Electronics Inc. In Canada: 205 Annagem Blvd., Mississauga, ON L5T 2V1• In the U.S.: MPO Box 2410, Niagara Falls, NY 14302
2
DIRECTIVES EUROPEENNES SUR LE RECYCLAGE ET LE TRAITEMENT DES DECHETS
Dans le respect de la directive WEEE (Waste Electrical & Electronic Equipment) mise en place par les
institutions Européennes à compter du 13 Août 2005, nous souhaitons vous informer que ce produit peut
contenir des matières devant faire l’objet d’une procédure de recyclage ou de traitement approprié des
déchets. Dans cette optique, Paradigm Electronics Inc (fabricant des enceintes ParadigmMD et des
électroniques AnthemMD) avec ses Distributeurs agréés dans l’Union Européenne, ont mis en place une
procédure de collecte et de retraitement gratuite. Pour en savoir davantage sur cette procédure veuillez
contacter votre revendeur, ou notre Distributeur dans votre pays (vous en obtiendrez les coordonnées sur
simple demande ou en consultant notre site internet www.paradigm.com).
Notez que seul le produit fini est concerné par cette directive et ses obligations. S’agissant de son emballage
et de ses accessoires de transport nous vous recommandons de les recycler selon les procédures mises en
place par votre commune ou votre département.
RECYCLING AND REUSE GUIDELINES FOR EUROPE
In accordance with the European Union WEEE (Waste Electrical and Electronic Equipment)
directive effective August 13, 2005, we would like to notify you that this product may
contain regulated materials which, upon disposal, according to the WEEE directive,
require special reuse and recycling processing. For this reason Paradigm Electronics Inc.
(manufacturers of Paradigm®speakers and Anthem®Electronics) has arranged with its
distributors in European Union member nations to collect and recycle this product at
no cost to you. To find your local distributor please contact the dealer from whom you
purchased this product or go to our website at www.paradigm.com.
Please note that only the product falls under the WEEE directive. When disposing of
packaging and other shipping material we encourage you to recycle through the
normal channels.
3
TABLE OF CONTENTS
IMPORTANT OPERATING INSTRUCTIONS:
READ BEFORE OPERATING SUBWOOFER
USING THE X-300 AMPLIFIER WITH YOUR SUBWOOFER:TO
TO PREVENT DAMAGE TO THE AMPLIFIER OR
SUBWOOFER AND ENSURE OPTIMAL SOUND,
THE 3-POSITION “EQ” SWITCH ON THE REAR
PANEL OF THE AMPLIFIER MUST BE CORRECTLY
CONFIGURED FOR USE WITH YOUR SETUP
(See Fig. 1). Additional details, page 5.
FAILURE TO POSITION THE SWITCH CORRECTLY
WILL RESULT IN PERMANENT DAMAGE TO
AMPLIFIER AND SUBWOOFER. SUCH DAMAGE
IS NOT COVERED UNDER THE PARADIGM
WARRANTY.
SUBWOOFER ASSEMBLY PARTS LIST
(one speaker)
• 1 subwoofer with mounting bracket attached
• 1 mounting template
• 1 paint mask
• 1 wire tie
Required, not included
• 1 Paradigm®X-300 Amplifier (for use with up to 4 Paradigm®PCS subwoofers)
Important Operating Instructions:
Read Before Operating Subwoofer . . . . . . . 3
Subwoofer Assembly Parts List . . . . . . . . . . 3
3-Position “EQ” Switch (Pictorial) . . . . . . . . 4
Your New Subwoofer . . . . . . . . . . . . . . . . . . 4
Configuring the Amplifier for use with Your
Subwoofer System . . . . . . . . . . . . . . . . . . . . 5
The Listening Room . . . . . . . . . . . . . . . . . . . . 5
Guidelines for Deciding on Subwoofer
Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Subwoofer Placement . . . . . . . . . . . . . . . . . . 6
Color Match Painting . . . . . . . . . . . . . . . . . . . 7
Installation into a Wall or Ceiling Without a
Backbox (Pictorial) . . . . . . . . . . . . . . . . . . . . . 8
Installation into a Paradigm®Backbox
(Pictorial) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation into a Wall or Ceiling Without a
Backbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Limited Warranty . . . . . . . . . . . . . . . . . . . . . 12
