Peavey DM 112 Bruksanvisning

Peavey högtalare DM 112

Läs gratis den bruksanvisning för Peavey DM 112 (20 sidor) i kategorin högtalare. Guiden har ansetts hjälpsam av 3 personer och har ett genomsnittsbetyg på 4.8 stjärnor baserat på 2 recensioner. Har du en fråga om Peavey DM 112 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/20

www.peavey.com

DM™ 112

Powered Speaker System

Operating

Manual

FCC/ICESCompliancyStatement

This Standard(s).  device complies with Part 15 of   the RSS  FCC rules and  Industry Canada license‐ exempt  Operation is

subject following harmful interference, andtothe twoconditions:(1)thisdevicemaynotcause   (2)thisdevicemust

accept any interference may operation.  received, that   cause undesired 

Le conforme deprésent est appareil   aux CNR Canada d’lndustrie     applicables aux appareils radio exempts 

licence. est autoriséeL’exploitation        aux deux conditions suivantes: (1) I’appareil ne dedoit  pas produire 

brouillage, (2) I’utilisateur I’appareil brouillage leet  de doitacceptertout radioélectriquesubi,mêmesi 

brouillage susceptible fonctionnement.est d’encompromettrele 

Warning:               Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the

user’s  authority to use the  equipment.

Note –                  This equipment has been tested and found to comply with the limits for a Class Bdigital device,

pursuant to Rules. limits to provide reasona protection against Part15oftheFCC These aredesigned   ble  

harmful in a residential installation. generat uses, and radiointerference    Thisequipmentes,  canradiate 

frequency energy and, if installed and in accordance with t instructions, harmful   not  used    he maycause 

interference to dio However, ra communications. thereis gua that interference will occur in anorantee   not   

particular rainstallation.If     this equipment does cause harmful interference to  dio television reception,or  

which turning equipment and t is to andcanbedeterminedby the off on,heuser encouraged try correctthe

interference followingbyoneormoreofthe measures.

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Caution

The equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment.

Introduction

ank you for purchasing the powered Peavey® DM™ 112 powered speaker system. e DM™112 features a

reliable bi-amped power section that provides a total of 660 Watts of peak available dynamic power with signal

compression to prevent audible overload. e analog power ampliers and linear power supply are coupled

with a DSP based crossover and EQ.

e LCD display and EQ presets along with other operating parameters are accessed via a one-knob selector.

e DM™112 provides a balanced input via a combination jack that accepts balanced TRS 1/4 inch input as well

as a balanced XLR input. ere is a balanced ru output via a Male XLR. ere is an adjustable Gain control

as well as a combination LED indicator that lights when power is on and changes color when the “so-limiting”

compression circuit is activated.

Features

* Two-way bi-amplied analog amp powered speaker system

* 12” heavy-duty woofer

* DX™14 compression driver, with 1.4 inch titanium diaphragm

* 410 watts peak woofer power, 250 watts peak tweeter power

* DSP processing is 64 bit double-precision

* DSP I/O is at 96 kHz and 24 bits, with low-jitter, professional grade components

* Dynamic bass boost function

* Fan cooled for maximum reliability

* Patented Quadratic roat Waveguide™ technology, 110 by 80 degree coverage

* Input is via a combo female XLR and 1/4” TRS phone jack with balanced input

* A Mic/Line switch provides for two dierent gain settings

* ru output is via a male XLR jack

* Multiple Factory Preset EQ settings for the DSP crossover system

* User Preset EQ storage provisions allow storing custom presets for later recall

* Rugged plastic injection-molded trapezoidal enclosure

* Cabinet has dual rear corner angled sides for oor monitor use.

* Full-coverage perforated steel grille, with powder coat nish

* Pole mount molded-in for 1 3/8” diameter poles

Description

e DM™112 is a two-way sound reinforcement system based on a heavy-duty 12” woofer and a DX™14 titani-

um diaphragm dynamic compression driver mounted on a 110 by 80 degree coverage Quadratic roat Wave-

guide™. It’s contemporary appearance coupled with exceptional performance oer an highly desirable combi-

nation.

e light yet durable injection-molded plastic enclosure with molded-in stand mount cup eases portable use for

live music or PA sound. e trapezoidal cabinet has three handles for ease of portability, and two extra angled

sections on either side to allow use as a oor monitor. A full length black powder coated perforated steel grille

provides system protection and a professional appearance.

e heavy-duty 12” woofer has a warm punchy sound for plenty of bass. e DX™14 compression driver tweet-

er is coupled to a Quadratic roat™ constant directivity waveguide, covered under US patent #6,059,069 with

ENGLISH
