Sida 1/12
SNOITACIFICEPS
SSE
™
12
Description
The SSE is a new enclosure series
featuring high power ratings with custom
components, a sleek look and a unique,
snap-in metal grille. The SSE 12 is a
two-way system featuring the highly
acclaimed Peavey 14T titanium
compression driver with the diverse Sound
Guard IV tweeter protection network and
Peavey 12" woofer with 2.5" (64
mm) voice coil for smooth response. The
SSE 12 is rated at 500 Watts program and
1,000 Watts peak. This lightweight
speaker system is ideal for smaller venues
where space is at a premium. Connections
are made using a four-pin twist lock
connector or a paralleled two-position
terminal block for additional cabinets. The
SSE 12 incorporates ying points on the
top of the unit and mounting points on the
bottom for utilizing the Peavey VersaMount
70 mounting bracket. The SSE Series is
available in black or white nishes.
Features:
• Two-way sound reinforcement
enclosure
• Designed for permanent install
• Available in black or white nishes
• Peavey
®
12" woofer with
2.5" (64 mm) voice coil
• Peavey 14T
™
titanium diaphragm
compression driver
• Sound Guard
™
IV tweeter protection
network
• Seven ying points (six M10 for
suspension and one M6 for angle
adjustment)
• Mounting point for VersaMount
™
70
bracket
• 13 mm birch plywood construction
• 500 Watts program/1000 Watts peak
power handling
• 79 Hz to 17 kHz
• 98 dB at 1W/1m
• 8 Ohms
Frequency response, 1 meter on-axis,
swept-sine in anechoic environment:
79 Hz to 17 kHz (±3 dB)
Usable low frequency limit (-10 dB
point):
60 Hz
Power handling:
Full range:
500 W program
1,000 W peak
Sound pressure level, 1 Watt, 1 meter in
anechoic environment:
Full range:
98 dB SPL (2.83 V input)
Maximum sound pressure level
(1 meter):
Full range:
122 dB SPL continuous
128 dB SPL peak
2
Radiation angle measured at -6 dB
point of polar response:
500 Hz to 1.6 kHz:
Horiz. 110˚ ± 15˚
Vert. 120˚ ± 30˚
1.6 kHz to 5 kHz:
Horiz. 75˚ ± 15˚
Vert. 70˚ ± 25˚
5 kHz to 16 kHz:
Horiz. 85˚ ± 15˚
Vert. 40˚ ± 10˚
Directivity factor, Q (Mean):
10.27 ± 6.07
Directivity index, Di (Mean):
9.38 dB ± 2.57 dB
Transducer complement:
Low Frequency Section:
Peavey woofer with 2.5"
(64 mm) voice coil
High Frequency Section:
Peavey 14T
™
titanium diaphragm
compression driver on a 90° x 40°
constant directivity horn
Box tuning frequency:
Low frequency section:
74 Hz
Harmonic distortion:
1% rated power
Second harmonic:
100 Hz: 0.32%
1 kHz: 0.10%
Third harmonic:
100 Hz: 0.40%
1 kHz: 0.22%
10% rated power
Second harmonic:
100 Hz: 0.56%
1 kHz: 0.79%
Third harmonic:
100 Hz: 0.79
%
1 kHz: 0.25%
Electro-acoustic crossover frequency
(internal passive):
2.8 kHz
Impedance (Z):
Full range:
Nominal: 8 Ω
Minimum: 5.1 Ω
Input Connection:
1 four-Pin twist lock connector in parallel
with one 1-position terminal strip
Enclosure materials and nish
Trapezoidal, dado-joined 13 mm birch
enclosure nished with a textured acrylic
polyurethane with a full length metal
grille covered and acoustical-grade grille
cloth. Available in black or white or
nishes
Mounting provisions:
(6) M10 threaded mounting
suspension points (three each top and
one
each side and back). Use only
forged shoulder machinery eye bolt,
DIN 580, ASTM A489, or BGV-C1. (1) M6
x 1.0mm threaded mounting point on
back bottom for angle adjustments.
(4) M6 x 1.0mm threaded mounting points
on bottom to accommodate use of
VersaMount
™
70 adjustable mounting
bracket.
DO NOT suspend this unit upside
down using VersaMount system.
Dimensions (H x W x D):
Front:
24.5" x 17.43" x 13.20"
622 mm x 443 mm x 335 mm
Rear:
24.5" x 13.14" x 13.20"
622 mm x 334 mm x 335 mm
Net Weight:
40 lbs. (18.1 kg)
Frequency response
This measurement is useful in determining
how accurately a given unit reproduces an
input signal. The frequency response of
the SSE 12 is measured at a distance of 1
meter using a 1 Watt (into the nominal
impedance) swept-sine input signal. As
shown in gure 1, the selected drivers in
the SSE 12 combine to give a smooth
frequency response from 79 Hz to 17 kHz.
Directivity
Beamwidth is derived from the -6 dB
points from the polar plots (see gure 3)
which are measured in a whole space
anechoic environment. Q and Directivity
Index are plotted for the on-axis
measurement position. These
specications provide a reference to the
coverage characteristics of the unit and
provide insight into proper placement and
installation in the chosen environment. The
blending of the components of the SSE 12
exhibit a desirable beamwidth and
directivity (gures 3 & 4) suitable for
sound reinforcement applications.
Power handling
There are many dierent approaches to
power handling ratings. Peavey rates this
loudspeaker system’s power handling
using a full-range form of the AES
Standard 2-1984. Using audio band 20 Hz
to 20 kHz pink noise with peaks of four
times the RMS level, this strenuous test
signal assures the user that every portion
of this system can withstand today’s high
technology music. This rating is contingent
upon having a minimum of 3 dB of
amplier headroom available.
Harmonic distortion
Second and third harmonic distortions vs.
frequency are plotted in gures 5 & 6 for
two power levels. Ten percent (10%) of
rated input power and either one percent
(1%) of rated input power or 1 Watt,
whichever is greater. Distortion is read
from the graph as the dierence between
the fundamental signal (frequency
response) and the desired harmonic. As an
example, a distortion curve that is down
40 dB from the fundamental is equivalent
to 1% distortion.
Mounting
Caution: Before attempting to suspend or
mount this speaker, consult a certied
structural engineer. The speaker may fall
due to improper installation, resulting in
serious injury and property damage. DO
NOT suspend or mount any other product
or device from this enclosure. The
maximum enclosure angle is 45°. Use only
Grade 8.8 Metric hardware or better. All
rigging is the responsibility of others.
Architectural and Engineering
Specications
The loudspeaker system shall have an
operating bandwidth of 79 Hz to 17 kHz.
The nominal output level shall be 98 dB
when measured at a distance of 1 meter
with an input of 1 Watt. The nominal
impedance shall be 8 Ohms. The maximum
program power handling shall be 500
Watts with a peak power input of at least
1000 Watts and a minimum amplier
headroom of 3 dB. The nominal radiation
geometry shall be 90˚ in the horizontal
plane and 40˚ in the vertical plane. The
outside dimensions shall be 24.5" high by
17.43" wide by 13.20" deep. The weight
shall be 40 lbs. The loudspeaker system
shall be a model SSE 12.
Features and specications subject to
change without notice.
WARRANTY INFORMATION AVAILABLE ONLINE
NOTE:
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
60
70
80
90
100
110
dB SPL (re 20 Pa)
Amplitude Response (1W 1m On-Axis)
Figure 1
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
1
10
100
Q&Directivity Index
Q
Figure 4
20
10
Di
0
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
30
40
60
80
100
140
180
300
360
Beamwidth (Degrees)
Beamwidth
Vertical
Horizontal
Figure 3
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
1
2
3
5
10
20
30
50
100
Impedance
Z
(
)
Figure 2
3
SPECIFICATIONS
SSE
™
12
3
