ISSUED: 07-26-12 SHEET #: 180-9024-6 (2016-05-29)

User Manual and Installation Guide

Models:

HDS-WHDI100

W I R E L E S S H D

MULTIMEDIA SYSTEM

2 of 28 ISSUED: 07-26-12 SHEET #: 180-9024-6 (2016-06-29)

Contents

Safety Precautions ��3

Important Information ��4

Unit Care Recommendations ��4

Introduction ��5

Package Contents 5 ��

Component Specications ��6

Transmitter 6 ��

Receiver 7 ��

Remote Control 8 ��

Installation and Operation ��9

Installing the Remote Control Batteries 9 ��

Wall Mounting the HDS-WHDI100 (Optional) 10 ��

Transmitter Setup ��11

Receiver Setup 12 ��

IR Flasher Setup 14 ��

System Operation ��13

Checking IR Flasher Frequency 15 ��

Changing IR Flasher Frequency 15 ��

Indicator Lights Decoded 16 ��

On Screen Display (OSD) Functions 17 ��

Troubleshooting ��19

Appendix ��21

Supported Resolution 21 ��

Audio Bit Rate Support 22 ��

Product Specications��23

FCC Statement ��24

Industry Canada Statement ��25

Warranty ��26

Contact Information ��27

3 of 28 ISSUED: 07-26-12 SHEET #: 180-9024-6 (2016-06-29)

WARNING!

RISK OF

ELECTRICAL

SHOCK

DO NOT OPEN

WARNING:

TO REDUCE THE RISK OF ELECTRICAL

SHOCK DO NOT REMOVE THE COVER�

NO USER-SERVICEABLE PARTS

ARE INSIDE� REFER SERVICING TO

QUALIFIED PERSONNEL

• Power to the units must be switched off before any work is undertaken, such as any AV device connection

or TV connection�

• To prevent electric shock, make sure to use the supplied DC adapters as power supply to the Transmitter

and Receiver�

• Be sure the power cord is routed so that it will not be stepped on or pinched by heavy items�

• Avoid overloading electrical outlets or extension cords which otherwise could result in electric shock or re.

• Disconnect the product from the power source if it is left unattended for an extended period of time, and to

protect the product from lightning�

• To reduce the risk of electric shocks or re, always disconnect the power cord from the power outlet when

you are not using your HDS-WHDI100 for an extended period of time�

• This product should not be exposed to dripping or splashing liquids. No object lled with liquids, such as

vases, should be placed on the product�

• To avoid electric shock, never stick anything in the slots on the case or remove the cover�

• Place Transmitter and Receiver on a at, hard and stable surface.

• Do not block the ventilation slots on the Transmitter or Receiver or place any heavy object on the top

cover. Blocking the airow could damage the Transmitter or Receiver. Arrange components so that

air can ow freely around the Transmitter and Receiver. Ensure that there is adequate ventilation if

the Transmitter and/or Receiver is placed in a cabinet� Put the Transmitter and Receiver in a properly

ventilated area, away from direct sunlight or any source of heat�

• To reduce the risk of re or electric shock, do not expose the Transmitter and/or Receiver to water or

moisture�

• This product is intended for indoor use only�

Safety Precautions
