SINGLE-ZONE DUCTLESS
MINI-SPLIT SYSTEM
OWNER’S MANUAL
MODELS: 3PAMSH30B-SZW, 3PAMSH30B-SZO, 3PAMSH36B-SZW, 3PAMSH36B-SZO
2 3
TABLE OF CONTENTS
IMPORTANT NOTE: Please check the applicable models, technical data, F-GAS data, and manufacturer
information on the indoor and outdoor product stickers before installation.
SAFETY INSTRUCTIONS ................................................................................................................... 3
PREPARATION BEFORE USE ............................................................................................................ 4
PRESET ............................................................................................................................................................................................. 4
SAFEGUARDING THE ENVIRONMENT .................................................................................................................................. 4
INSTALLATION INSTRUCTIONS ...................................................................................................... 6
INSTALLATION DIAGRAM .......................................................................................................................................................... 6
BEST INSTALLATION PRACTICES .......................................................................................................................................... 6
BOX PART BREAKDOWN ........................................................................................................................................................... 7
SUGGESTED TOOLS ................................................................................................................................................................... 7
SITE INSTRUCTIONS ................................................................................................................................................................... 8
INDOOR UNIT INSTALLATION .................................................................................................................................................. 9
OUTDOOR UNIT INSTALLATION ...........................................................................................................................................14
POWER AND WIRING ................................................................................................................................................................15
WIRING DIAGRAM.......................................................................................................................................................................16
EVACUATION INSTRUCTIONS ...............................................................................................................................................17
START-UP ......................................................................................................................................................................................17
CARE AND MAINTENANCE .............................................................................................................18
FRONT PANEL MAINTENANCE .............................................................................................................................................18
AIR FILTER MAINTENANCE .....................................................................................................................................................18
PROTECTION ......................................................................................................................................19
NOISE POLLUTION ....................................................................................................................................................................19
FEATURES OF PROTECTOR ...................................................................................................................................................19
FEATURES OF HEATING MODE .............................................................................................................................................19
ENERGY SAVING TIPS ......................................................................................................................20
TROUBLESHOOTING........................................................................................................................21
IDENTIFICATION OF PARTS ...........................................................................................................22
INDOOR UNIT ...............................................................................................................................................................................22
OUTDOOR UNIT ..........................................................................................................................................................................22
DISPLAY INTRODUCTION ...............................................................................................................23
DISPLAY SCREEN .......................................................................................................................................................................23
EMERGENCY BUTTON ..............................................................................................................................................................23
SAFETY INSTRUCTIONS
To guarantee the unit works normally, please
read the manual carefully before installation,
and try to install strictly according to this
manual.
Do not let air enter the refrigeration system
or discharge refrigerant when moving the air
conditioner.
Properly ground the air conditioner.
Check the connecting cables and pipes
carefully, make sure they are correct and
rm before connecting the power of the air
conditioner.
There must be an electrical disconnect
switch.
After installing, the consumer must operate
the air conditioner correctly according
to this manual, keep a suitable storage
for maintenance and moving of the air
conditioner in the future.
The Fuse of the unit:
Model Max Fuse
9K(115V)
Max Fuse is
located on
outdoor unit
product sticker.
12K(115V)
9K-12K(208/230V)
18K(208/230V)
24K-36K(208/230V)
A residual current device (RCD) with the rating
of above 10mA shall be incorporated in the
xed wiring according to the national rule.
Warning: Risk of electric shock can cause
injury or death: Disconnect all remote electric
power supplies before servicing.
The best length of the connecting pipe
between the indoor unit and outdoor unit is
less than 24.6ft (7.5 meters). It will aect the
eciency of the air conditioner if the distance
longer than that length.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the appliance
in a safe way and understand the hazards
involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
The batteries in remote control must be
recycled or disposed of properly. Disposal
of Scrap Batteries --- Please discard the
batteries as sorted municipal waste at the
accessible collection point.
If the appliance is xed wiring, the appliance
must be tted with means for disconnection
from the supply mains having a contact
separation in all poles that provide full
disconnection under over voltage category
III conditions, and these means must be
incorporated in the xed wiring in accordance
with the wiring rules.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons in order to
avoid a hazard.
The appliance shall be installed in accordance
with local electrical safety regulations and
National Electrical Codes (NEC).
The air conditioner must be installed by
professional or qualied persons.
The appliance shall not be installed in the
laundry room.
Regarding to installation, please refer to
section “Installation instructions”.
Regarding to maintenance, please refer to
section “Care and Maintenance”.
4 5
NOTE:
•
When charging refrigerant into the
system, make sure to charge in liquid
state,if the refrigerant of the appliance is
R410A. Otherwise, chemical composition
of refrigerant (R410A) inside the system
may change and thus aect performance
of the air conditioner.
• According to the character of refrigerant
(R410A,the value of GWP is 2088), the
pressure of the tube is very high, so be
sure to be careful when you install and
repair the appliance.
•
If the supply cord is damaged, it
must be replaced by the manufacturer, its
service agent or similarly qualied persons
in order to avoid a hazard.
•
The air conditioner must be installed
by trained, qualied installers and service
mechanics.
•
The temperature of refrigerant
circuit will be high, please keep the
interconnection cable away from the
copper tube.
PREPARATION BEFORE USE
PRESET
Before using the air conditioner, be sure to check
and preset the following.
• Remote Control Presetting
Each time after the remote control is replaced
with new batteries or is energized, remote
control auto presetting heat pump. If the air
conditioner you purchased is a Cooling Only
one, heat pump remote control can also be
used.
• Back-light Function of Remote Control
Hold down any button on remote control to
activate the back light. It automatically shuts
o 10 seconds later.
• Auto Restart Presetting
The system has an Auto-Restart function and
will resume to previous settings once power
has been restored.
SAFEGUARDING THE ENVIRONMENT
This appliance is made of recyclable or
re-usable material. Scrapping must be carried
out in compliance with local waste disposal
regulations. Before scrapping it, make sure to
cut o the mains cord so that the appliance
cannot be re-used.
For more detailed information on handling
and recycling this product, contact your
local authorities who deal with the separate
collection of rubbish or the shop where you
bought the appliance.
SCRAPPING OF APPLIANCE
This marking indicates that this product should
not be disposed with other household wastes
throughout the North America. To prevent
possible harm to the environment or human
health from uncontrolled
waste disposal, recycle it
responsibly to promote
the sustainable reuse of
material resources. To
return your used device,
please use the return and
collection systems or
contact the retailer where
the product was purchased. They can take this
product for environmental safe recycling.
SAFETY PRECAUTIONS
Symbols in this Use and Care Manual are
interpreted as shown below.
Be sure not to do.
Pay attention to such a situation.
Grounding is essential.
Warning: Incorrect handling could cause
a serious hazard, such as death, serious
injury, etc.
Use correct power supply in accordance with the rating
plate requirement. Otherwise, serious faults or hazard may
occur or a re maybe break out.
Keep the power supply circuit breaker
or plug from dirt. Connect the power
supply cord to it rmly and correctly, lest
an electric shock or a re break out due to
insucient contact.
Do not use the power supply
circuit breaker or pull o the plug
to turn it o during operation.
This may cause a re due to spark, etc.
Do not knit, pull or press the
power supply cord, lest the power
supply cord be broken. An electric
shock or re is probably caused by
a broken power supply cord.
Never insert a stick or
similar obstacle to the unit.
Since the fan rotates at high
speed, this may cause an injury.
It is harmful to your
health if the cool air
reaches you for a long
time. It is advisable to let
the air ow be deected to all the room.
Turn o the appliance by
remote control rstly before cutting
o power supply if malfunction occurs.
Do not repair the appliance
by yourself. If this is done
incorrectly, it may cause
an electric shock, etc.
Prevent the
airow from reaching
the gas burners and stove.
Do not touch
the operation buttons
when your hands are wet.
Do not put any
objects on the outdoor unit.
It is the user's
responsibility to make the
appliance be grounded
according to local codes or
ordinances by a licensed technician.
