MICROWAVE OVEN

OWNER’S MANUAL

PMD 201 W,B,R

Dear customer,

Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all

the instructions in this user’s manual.

EN - 1

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS ............................................................................................................2

EARTHING INSTRUCTIONS .............................................................................................................................7

INSTALLATION ..................................................................................................................................................7

SPECIFICATIONS ..............................................................................................................................................8

FEATURES DIAGRAM .....................................................................................................................................10

OPERATION PROCEDURE ..............................................................................................................................11

CARE OF YOUR MICROWAVE OVEN..............................................................................................................12

BEFORE YOU CALL FOR SERVICE .................................................................................................................. 14

CARING FOR YOUR MICROWAVE OVEN .......................................................................................................14

QUESTIONS AND ANSWERS .........................................................................................................................15

COOKING INSTRUCTIONS .............................................................................................................................16

USE YOUR MICROWAVE OVEN SAFELY ........................................................................................................17

MICROWAVING PRINCIPLES .........................................................................................................................18

CONVERSION CHARTS ................................................................................................................................... 20

COOKING TECHNIQUES .................................................................................................................................20

DEFROSTING GUIDE ......................................................................................................................................22

COOKING & REHEATING CHART ...................................................................................................................24

VEGETABLE CHART ........................................................................................................................................26

EN - 3

• Thisapplianceisdesignedfordomesticuseandsimilarlocations

suchas:

- kitchensinstores;ocesandotherworkenvironments;

- inagriculture;

- guestsofhotels,motelsandotheraccommodation

environments;

- inbedandbreakfastestablishments.

• Toensuresucientaircirculation,freespacemustbeleftaround

themicrowaveoven.Ensurefreespaceof20cmabovethetop

surfaceoftheoven,10cmfrombehindandonthesides.Donot

blockanyopeningoftheoven.Donotremovethefeetofthe

oven.

• Useonlycontainersthataresuitableforuseinmicrowaveovens.

• Donotuseanyofthefollowingkitchencookware,tablewareor

utensilsinthemicrowaveoven:

- metalpansandcrockerywithmetalhandlesorwithmetal

decorations;

- clampsonplasticbags;

- disheswithmelaminesurfacetreatment;

- standardthermometers,suchasareusedformeasuringthe

temperatureofmeat,etc.

• Whenheatingamealonplasticorpaperdishes,frequentlycheck

theoventopreventthemfromcatchingonre.

• Themicrowaveovenisdesignedforheatingfoodandbeverages.

Dehydratingfoodordryingclothesandheatingupheating

cushions,homefootwear,washingsponges,damptextilesand

similaritemsmayleadtoaninjuryhazard,ignitionorre.

EN - 6

• Keeptheinsideoftheovenclean.Ifthewallsoftheovenare

splatteredwithfoodjuicesthenwipethemawayusingadamp

cloth.Iftheovenisheavilysoiled,youcanuseaweaksolutionof

aneutralkitchendetergent.

• Donotusethemicrowaveovenifthepowercordorpowerplug

isdamaged,ifitisnotworkingcorrectly,ifitisdamagedorif

ithasbeendroppedontheoor.Anyrepairofthemicrowave

ovenorreplacementofadamagedpowercordmayonlybe

carriedoutbyanauthorisedservicecentre,asthiswillpreventa

dangeroussituationfromoccurring.

PLEASE READ AND FOLLOW THE INSTRUCTIONS BELOW.

SAVE THE INSTRUCTIONS IN CASE YOU NEED THEM AGAIN.

EN - 7

EARTHING INSTRUCTIONS

Thisappliancemustbeearthed.Intheeventofanelectricalshortcircuit,earthingreducestheriskofelectric

shockbyprovidinganescapewirefortheelectriccurrent.Thisapplianceisequippedwithacordhavinga

earthingwirewithanearthingplug.Theplugmustbepluggedintoanoutletthatisproperlyinstalledand

earthed.

WARNING: Improper use of the earthing plug can result in a risk of electric shock. Consult a qualied

electrician or serviceman if the earthing instructions are not completely understood, or if doubt exists as

to whether the appliance is properly earthed. If it is necessary to use an extension cord, use only a 3-wire

extension cord that has a 3-blade earthing plug, and a 3-slot receptacle that will accept the plug on the

appliance. The marked rating of the extension cord should be equal to or greater than the electrical

rating of the appliance.

INSTALLATION

1. Ventilation

 Donotblockairvents.Iftheyareblockedduringoperation,theovenmayoverheatandeventuallycause

afailure.Forproperventilation,allowabove100mmofspacebetweenovensides,rearandtheminimum

heightoffreespacenecessaryabovethetopsurfaceoftheovenis200mm.

2. Steady, at location

 Thisovenshouldbesetonasteady,atsurface.Thisovenisdesignedforcountertopuseonly.

 Themicrowaveovenshallnotbeplacedinacabinetunlessithasbeentestedinacabinet.

3. Leave space behind and side

 Allairventsshouldbekeptaclearance.Ifallventsarecoveredduringoperation,theovenmayoverheat

and,eventually,ovenfailure.

4. Away from radio and TV sets

 Poor television reception and radio interference may result if the oven is located close to a TV, Radio

antenna,feederandsoon.Positiontheovenasfarfromthemaspossible.

5. Away from heating appliance and water taps

 Keeptheovenawayfromhotair,steamorSplashwhenchoosingaplacetopositionit,ortheinsulation

mightbeadverselyaectedandbreakdownsoccur.

6. Power supply

• Checkyourlocalpowersource.Thisovenrequiresacurrentofapproximately6amperes,230V50Hz.

• Powersupplycordisabout0.8meterslong.

• Thevoltageusedmustbethesameasspeciedonthisoven.Usingahighervoltagemayresultina

reor otheraccident causingoven damage.Using lowvoltagewill cause slowcooking.Wearenot

responsiblefordamageresultingfromuseofthisovenwithavoltageofamperefuseotherthanthose

specied.

• Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,itsserviceagentorasimilarly

qualiedpersonsinordertoavoidahazard.

EN - 9

IMPORTANT

The wires in this mains lead tted to this appliance are coloured in accordance with the following code.

Green-and-yellow : Earth

Blue : Neutral

Brown : Live

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured

markings identifying the terminals in your plug, proceed as follows: the wire which is coloured green-

and-yellow must be connected to the terminal in the plug which is marked with the letter ‘E’, the earth

symbol or coloured green-and-yellow. The wire which is coloured blue must be connected to the

terminal which is marked with the letter ‘N’ or coloured black.

The wire which is coloured brown must be connected to the terminal which is marked with the letter ‘L’

or coloured red.

WARNING: This appliance must be earthed.

EN - 10

FEATURES DIAGRAM

   

  













1 Door latch -Whenthedoorisclosed,itwillautomaticallyshuto.Ifthedoorisopenedwhiletheovenis

operating,themagnetronwillautomaticallyshuto.

2 Door seal -Thedoorsealsurfacespreventmicrowavesescapingfromtheovencavity.

3 Oven cavity

4 Control panel

5 Oven lamp -Automaticallyturnsonduringovenoperating.

6 Roller guide -Thismustalwaysbeusedforcookingtogetherwiththeglasscookingtray.

7 Glass cooking tray -Madeofspecialheatresistantglass.Thetraymustalwaysbeinproperposition

beforeoperating.Donotcookfooddirectlyonthetray.

8 Viewing screen -Allowsviewingoffood.

 Thescreenisdesignedsothatlightcanpassthrough,butnotthemicrowave.

9 Waveguide cover -Protectsthemicrowaveoutletfromsplashesofcookingfoods.

0 Safety interlock system

 Variable power control knob -Usedtoselectamicrowavepowerlevel.

 Timer knob -Usedinsettingcookingtimeforallfunctions.

 Door open button -Toopenthedoorpushthedooropenbutton.

EN - 11

OPERATION PROCEDURE

Thissectionincludesusefulinformationaboutovenoperation.

1. Plugpowersupplycordinto230VAC50Hzpoweroutlet.

2. Afterplacingthefoodinasuitablecontainer,opentheovendoorandputitontheglasstray.

 Theglasstrayandrollerguidemustalwaysbeinplaceduringcooking.

3. Closethedoor.Makesurethatitisrmlyclosed.

 Theovendoorcanbeopenedatanytimeduringoperationbypushingthedooropenbutton.

 Theovenwillautomaticallyshuto.

4. Setthevariablepowercontrolknobtothedesiredpowerlevel.

SYMBOL POWER LEVEL

OUTPUT POWER

700 W 800 W

Gentleheating 120W 140W

Heat 180W 210W

Defrost 270W 310W

Lowstage 390W 450W

Medium 500W 570W

Mediumhigh 610W 700W

High 700W 800W

5. Settheoperatingtimebyturningthetimerknobtothedesiredcooktimeandthemicrowavecooking

starts.

• Ifsettingthetimercontrolforlessthan2minutes,turnitpast2minutesandthenbacktothedesired

time.

6. Microwaveenergywillbeturnedoautomaticallywhenthetimerknobreaches“OFF”.Thenfoodcanbe

takenoutoftheoven.

• Topreventtheovenfromoperatingwiththedooropen,yourmicrowaveovenisttedwithsafetydoor

interlockswitches.

• Ifyouwishtoinspectthefoodwhileitiscookingsimplyopenthedoor.

 Theovenwillautomaticallystopcooking.Tocontinuecooking,yousimplyclosethedoor.

• Ifyouwishtostopcooking,simplyturnthetimerknobtothe“OFF”position.Cookingcanberesetatany

timeduringthecookingcyclebyturningthetimercontrol.

• Donotletthetimercontinuetooperateafterremovingorwhenthereisnofood.

EN - 13

ROLLER GUIDE

1 TheROLLERGUIDEandovenoorshouldbecleanedfrequentlytopreventexcessivenoise.

2 TheROLLERGUIDEMUSTALWAYSbeusedforcookingtogetherwiththeGlassTray.

GLASS TRAY

1 DONOToperatetheovenwithouttheGlassTrayinplace.

2 DONOTuseanyotherGlassTraywiththisoven.

3 IfGlassTrayishot,ALLOWTOCOOLbeforecleaningorplacingitinwater.

4 DONOTcookdirectlyontheGlassTray.(Exceptforpopcorn)

GlassTray

RollerGuide
