Amplifier Manual

Manuel de l’amplificateur

Features Caractéristiques

Models: S1000.1

S400.4

• SeriousPerformanceinaCompactPackage

• 18dBVariableLowPassandSubsonicCrossovers(S1000.1)

• 12dBVariableHighandLowPassCrossovers(S400.4)

• HighLevelInputwithSignalSensingTurn-onforEasyOEMintegration

• OversizedDirectInsertPowerandSpeakerTerminals

• RobustUnregulatedPowerSupply

• AudiophileBi-PolarOutputTransistors

• LPL44-LowPassLevelControlReady

• AdvancedThermalandProtectionCircuitry

• Desérieusesperformancesdansunboîtiercompact

• 18dBPasseBasseVariableetSubsoniqueCroisé(S1000.1)

• 12dBHautetPasseBasseVariableCroisé(S400.4)

• LeNiveauSupérieurentrepourl’intégrationdeFABRICANT

D’ORIGINEfacile

• DirigerlePouvoird’InsertionetlesTerminauxdeHaut-parleur

• PouvoirnonRéguléeRobust

• AudiophileTransistorsdeBipolaire

• LPL44-LaPassebasseNivellePrêtdeContrôle

• AvancéThermiqueetlesCircuitsdeProtection

Amplier Owner’s Manual

MONOBLOCK SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >90dB

Subsonic and Low Pass Crossovers: 18dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Subsonic Crossover Range: 10Hz to 55Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

High Level Input Range: 400 millivolts to 12 volts

Lowest Recommend Load: 1 ohm

Typical Efciency: 80%

Damping Factor: Greater than 200

FOUR CHANNEL SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 20kHz

Signal to Noise Ratio: >110dB

High and Low Pass Crossovers: 12dB per Octave

Low Pass Crossover Range: 40Hz to 400Hz

High Pass Crossover Range: 40Hz to 400Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

High Level Input Range: 400 millivolts to 12 volts

Lowest Recommend Load: 4 ohm Bridged or 2 ohm Stereo

Typical Efciency: 50%

Damping Factor Greater than 200

S1000.1

Dynamic Power 14.4Vdc >1% THD 750 x 1 @ 2 ohm

1000 x 1 @ 1 ohm

RMS Power 14.4Vdc ≤ 1% THD 550 x 1 @ 2 ohm

800 x 1 @ 1 ohm

Recommended Fuse Size: 80 Amp

Power/Ground Wire Size: 4 Gauge

Dimensions: 9.1” L x 6.9” W x 2.1” H

230mm L x 175mm W x 52mm H

S400.4

Dynamic Power 14.4Vdc >1% THD 50 x 4 @ 4 ohm Stereo

75 x 4 @ 2 ohm Stereo

150 x 2 @ 4 ohm Bridged

RMS Power 14.4Vdc ≤1% THD 40 x 4 @ 4 ohm Stereo

55 x 4 @ 2 ohm Stereo

110 x 2 @ 4 ohm Bridged

Recommended Fuse Size: 40 amp

Power/Ground Wire Size: 8 Gauge

Dimensions: 9.9” L x 6.9” W x 2.1” H

250mm L x 175mm W x 52mm H

Specifications

Amplier Owner’s Manual

INPUT

Connectpreampsignalcablesfromtheheadunittotheseterminals.

OUTPUT

Providesafullrangesignalforanadditionalamplier.Thereisnosignal

lossifusingthisoutput.

CROSSOVER FREQUENCY

Controlsthelowpasscrossoverpointforthespeakeroutputs.

BASS BOOST

Variablebassboostfrom0to+18dB@45Hz.

LOW PASS LEVEL CONTROL (LPL)

Thisportisforconnectingtheoptionalremotelevelcontrol(LPL44).This

allowsupto20dBofvolumeadjustment.Thisisnotabassboost,it

controlsthelevelofthelowpasssignal.

LEVEL

Usedtoreachmaximumamplierpowerwithawidevarietyofheadunits.

HI INPUT

Connectafactorysystem’sheadunitoramplieroutputs.UsingtheHIlevelinputthe

amplierwillautomaticallyturnonandoffusingthefactorysystem’saudiosignalasa

trigger.Thehighlevelautoonswitchturnsofftheautoturnonfunction,butthehigh

levelinputstillworksasnormal.

SUBSONIC CROSSOVER FREQUENCY

Controlsthehighpasscrossoverpointforthespeakeroutputstoeliminateextreme

lowfrequencies.

12V+

Thismustbeconnectedtothefusedpositiveterminal(+12V)ofthecar’s

battery.Thefusemustbelocatedwithin18inchesofthebattery.

REMOTE

Thismustbeconnectedtoswitched+12V,usuallyatriggerwirecoming

fromtheheadunitorignition.ThisisnotusedifusingHiinputautoon

feature.

GND

Thismustbeconnectedtothenegativeterminalofthecar’sbatteryor

boltedtoaclean,unpaintedpartofthechassisofthevehicle.

SPEAKER OUTPUTS

Usedtoconnecttheampliertospeakers.S1000.1minimumimpedanceis1ohm.

s1000.1

Monoblock Power Amplifier
