Ph Sf Cpny r eac n s gurte

FIRST OPENING ON FACTORY DEFAULT CODE

Factory code is 1 2 3 4 5 6

1. Touch the screen, to activate (1 bleep and screen illuminates).

2. Enter the user code (1st time usage 123456).

3. Touch , a melodic tone will sound and the display will OPEN

show .OPEnd

4. Turn handle counter clockwise and open the door while the

tone is sounding.

CAUTION

I. If an incorrect code is entered, Error will appear in the display

panel and a short warning tone will sound.

II. If a wrong code is entered 5 times the lock will cease to oper-

ate for 5 minutes. During which a warning tone will sound and

the display will indicate deLAY.

SETTING A NEW USER CODE

Set a new code with the door open and test the new code before

closing the door.

1. Touch the screen to activate

2. Touch ENTER

3. Type in the present code

4. Touch ENTER

5. Type in the new 4 – 16 digit code

6. Touch , a melodic tone will sound and the display will ENTER

show EntErd

For example:

If the present code is 1 2 3 4 5 6 and a new four digit code is

decided as 4 2 4 2 enter the following –

ENTER 1 2 3 4 5 6 ENTER 4 2 4 2 ENTER> > > >

EntErd will show in the display and a short tone will sound to

conrm the change to 4 2 4 2

INTRODUCING A FINGERPRINT

Open the door using the user code. Keep the door open while

carrying out this process.

1. Press the button on the back of door, the screen will be M

activated

2. Press on the screen3

3. Press ENTER

4. Enter the user code and press ENTER

5. Scan in the ngerprint twice

consecutively, by placing the

nger on the sensor. The screen

will show a melody will EntErd

sound.

NOTE: Check the nger print had

been set correctly following -

How to open with a ngerprint.

• A total of 128 nger prints can be

introduced into the lock.

HOW TO OPEN WITH A FINGERPRINT

1. Touch the screen to activate

2. Scan the ngerprint on the sensor, the screen will show

OPEnd and a melody will sound.

3. Turn the handle counter clockwise and open the door while the

tone is sounding.

CAUTION

I. will appear in the If an incorrect ngerprint is scanned, ErrOr

display and a short warning tone will sound.

II. If a wrong ngerprint is scanned 5 times the lock will cease to

operate for 5 minutes. During which a warning tone will sound

and the display will indicate deLAY.

V1 JUL 2018

Battery Case

Hold the upper part and turn it counter-clockwise to

disassemble (1,5V AA Alkaline 4 pcs)

Upper part Lower part

Reset Button

Upper

part

Lower

part

Securing

Hole

Memory Button

Door back or Top drawer back

Put Finger-print twice

While red lamp flickering,

put user’s finger on sensor.

After Bi- sound,

repeat the above

SS1160F OPERATING INSTRUCTIONS

& GUARANTEE REGISTRATION
