Page 1

AM SERIES

Professional Mixing Consoles

AM SERIES Data Sheet 10/28/2011

AM2442FX I AM3242FX

Features

Descripon

AM2442FX

24-Input 4-Bus Studio/Live Mixer with Digital EFX and GEQ

AM3242FX

32-Input 4-Bus Studio/Live Mixer with Digital EFX and GEQ

416 or 24 low-noise microphone preamps matched with 1/4” TRS line inputs

440-bit digital stereo mul-eect processor with 100 programs

49-band stereo graphic EQ

42 stereo input channels with 4-band EQ

42 addional stereo input channels with level and prefader AUX facilies

43-band EQ plus switchable low-cut lter on all mono channels

4Inserts on each mono channel and main mix

44 subgroups and addional mono output

44 AUX sends per channel

4Clip indicaon and gain level set LEDs plus mute switches for each channel

4Solo-In-Place and Pre-Fader Listen funcons

4Full-featured talkback secon

4Standby switch mutes all mic channels during breaks

4CD/tape inputs for playing break music

4Internal switching power supply with universal connector, 100-240V, 50/60Hz

Phonic’s AM2442FX and AM3242FX mixers are reliable and versale with 16 or 24 mono mic/line and 2 stereo line inputs. Ultra low-noise pre-

amps ensure high quality sound when used in project studios or in sound reinforcement. The 3-band EQ on mono channels and 4-band EQ on

stereo gives you total control over your mix. Each model oers a high volume headphone output with independent level control. The AM series

makes monitoring the mix even easier with dual 12-segment LED level meters and stereo control room outputs on select models. Both models

also feature a 32/40-bit mul-eect processor with 100 preset programs as well as tap delay eects and test tones. Aordable and easily

manageable, these AM models provide all the features that are important to you.

Page 2

Professional Mixing Consoles

AM SERIES

AM SERIES Data Sheet 10/28/2011

AM2442FX I AM3242FX

Specicaons

108 mm

/ 4.3"

893 mm / 35.2"

Dimension

AM2442FX dimensions can be found in the specs below

AM2442FX AM3242FX

Inputs

Total Channels 24 32

Balanced Mono Mic /

Line Channel 16 24

Balanced Stereo Line

Channel 4

Aux Return 4

2T Input 2

Outputs

Main L/R Stereo 2, (2*XLR, 2*1/4" TRS)

Rec Out 2, RCA

CTRL RM/PHONES 1, (1/4" TRS)

Mono (Sub) Out 1, (1/4" TRS)

Group Out 4 ( 4*1/4"TRS)

Channel Strips

EFX Send 1

Pan/Balance Control 1

Volume Controls 60mm fader

AUX Send 4 (Pre/Post switch on Aux 1/2)

Inserts 1

Master Secon

Phones Level Control 1 (Rotary control with route switch)

Mono (Sub) Out 60mm fader with sweptable LP

Main L/R Level Control 60mm fader

Metering

Number of Channels 2

Segments 12

Phantom Power Supply 48VDC

Frequency Response (Mic input to any output)

20Hz ~ 40KHz 0/-1dB

10Hz ~ 200KHz 0/-3dB

Crosstalk (1KHz @ 0dBu, 20Hz to 20KHz bandwidth, channel in to main

L/R outputs)

Channel fader down,

other channels at unity <-90dB

Noise (20Hz~20KHz; measured at main output, Channels 1-4 unit gain;

EQ at; all channels on main mix; channels 1/3 as far le as possible,

channels 2/4 as far right as possible

Master @ unity,

channel fader down -96dB

Master @ unity,

channel fader @ unity -84dB

S/N rao, ref to +4 -105dB

Microphone Preamp

E.I.N. (150 ohms

terminated, max gain)

<-123dBu

THD (Any output, 1KHz

@ +14dBu, 20Hz to

20KHz, channel inputs)

<0.014%

Maximum Level

Mic Preamp Input +12dBu

All Other Input +22dBu

CTRL RM/PHONES +17dBu/150ohms

Balanced Output +20dBu

Impedance

Mic Preamp Input 2.5k ohms

Mono Line Input 21k ohms

Stereo Line Input >10k ohms

AUX RTN >10k ohms

RCA 2T Input >10k ohms

All Other Output (except

REC Out, Phones Out) 120 ohms

CD/TAPE out 1.6k ohms

Phones Out 100 ohms

Equalizaon 3-band +/-15dB

Low EQ 80 Hz

Mid EQ Sweptable 100Hz~8k Hz

Hi EQ 12k Hz

Low Cut Filter 75Hz (-18 dB/oct)

32/40-bit Digital Eect

Processor 100 eects with tap delay control

Power Requirement 100-240V~, 50-60Hz, 50W

Weight 9.1 kg (20.1 lbs) 11.7 kg (25.9 lbs)

Dimensions (WxHxD) 682x108x242 mm

(26.9"x4.3"x16.7")

893x108x424 mm

(35.2"x4.3"x16.7")
