BRIDGEABLE FOUR-CHANNEL POWER AMPLIFIER

AMPLIFICATEUR DE PUISSANCE PONTABLE A

QUATRE VOIES

Owner’s Manual

GM-X574

GM-X374

Mode d’emploi

ENGLISH

ESPAÑOL

DEUTSCH

FRANÇAIS

ITALIANO

NEDERLANDS

1
Contents
Before Using This Product  ...................... 2
Composition of Manual  .................................... 2
In case of trouble  .............................................. 2
WARNING ........................................................ 2
Setting the Unit  .......................................... 3
Gain Control ...................................................... 3
Input Select Switch ............................................ 3
Power Indicator  ................................................ 4
BFC (Beat Frequency Control) Switch  ............ 4
LPF (Low-Pass Filter)/HPF (High-Pass
Filter) Select Switch  .................................. 4
Connecting the Unit  .................................. 5
Connection Diagram  ........................................ 7
Connecting the Power Terminal ........................ 8
Connecting the Speaker Output Terminals  ...... 8
Using the Speaker Input  .................................... 9
Connecting the Speaker wires  ........................ 10
Installation ................................................ 12
Example of installation on the floor mat
or on the chassis  ...................................... 12
Specifications .......................................... 13

Before Using This Product

ENGLISH ESPAÑOL DEUTSCH FRAN

ÇAIS

ITALIANO NEDERLANDS

Thank you for purchasing this PIONEER

product. Before attempting operation, be

sure to read this manual.

Composition of Manual

This manual applies to the GM-X574 and

GM-X374. However, the illustrations

show the GM-X574.

In case of trouble

When the unit does not operate properly,

contact your dealer or the nearest autho-

rized PIONEER Service Station.

WARNING

• Always use the special red battery and ground

wire [RD-223], which is sold separately. Connect

the battery wire directly to the car battery positive

terminal (+) and the ground wire to the car body.

• Do not touch the amplifier with wet hands.

Otherwise you may get an electric shock. Also,

do not touch the amplifier when it is wet.

• For traffic safety and to maintain safe driving

conditions, keep the volume low enough so that

you can still hear normal traffic sound.

• Check the connections of the power supply and

speakers if the fuse of the separately sold battery

wire or the amplifier fuse blows. Detect the cause

and solve the problem, then replace the fuse with

another one of the same size and rating.

• To prevent malfunction of the amplifier and

speakers, the protective circuit will cut the power

supply to the amplifier (sound will stop) when an

abnormal condition occurs. In such a case, switch

the power to the system OFF and check the

connection of the power supply and speakers.

Detect the cause and solve the problem.

• Contact the dealer if you cannot detect the cause.

• To prevent an electric shock or short-circuit

during connection and installation, be sure to

disconnect the negative (–) terminal of the battery

beforehand.

• Confirm that no parts are behind the panel when

drilling a hole for installation of the amplifier. Be

sure to protect all cables and important equipment

such as fuel lines, brake lines and the electrical

wiring from damage.

This product complies with the EMC

Directives (89/336/EEC, 92/31/EEC)

and CE Marking Directive (93/68/EEC).
