Sida 1/16
Compact Industrial 8-Port
Gigabit Ethernet Switch
IGS-800T/IGS-820TF
User's Manual
Table of Contents
1. Package Contents ..........................................................................................3
2.ProductSpecications ....................................................................................4
3. Hardware Introduction ...................................................................................6
3.1 Switch Front Panel ..................................................................................6
3.2 LEDDenition: .......................................................................................6
3.3 Switch Upper Panel .................................................................................7
3.4 Wiring the Power Inputs ..........................................................................8
3.5 Grounding the Device ..............................................................................9
4. Installation .................................................................................................. 10
4.1 DIN-rail Installation ............................................................................... 10
4.2 Wall Mounting ....................................................................................... 11
4.3 Side Wall-mount Plate Mounting ............................................................. 11
5. Three-View Diagram .................................................................................... 12
6. Customer Support ....................................................................................... 14
3
1. Package Contents
Thank you for purchasing PLANET Compact Industrial 8-port Gigabit Ethernet Switch,
IGS-800T/IGS-820TF.Thetablebelowshowsthemodelswiththenumberofports:
Model Name Copper Port Fiber Port
IGS-800T 8 x 10/100/1000T RJ45 -
IGS-820TF 6 x 10/100/1000T RJ45 2 x 100/1000X SFP
In the following sections, the term “Industrial Gigabit Ethernet Switch”
mentioned in this user’s manual refer to the above models
Open the box of the Industrial Gigabit Ethernet Switch and carefully unpack it. The
boxshouldcontainthefollowingitems:
Industrial Gigabit
Ethernet Switch x 1 QR Code Sheet x 1 Wall-mount Kit x 1
Let’s get started with your PLANET product
IGS-500T
EN Please scan the QR code to browse our online User’s Manual or Quick
Installation Guide and follow the instructions to complete the setup.
User's Manual
DE
Bitte scannen Sie den QR- Code sie werden per Browser zur
Bedienungsanleitung oder Schnellanleitung weiter geleitet. Folgen Sie den
Anweisungen u m die Installation abzuschließen.
FR
Veuillez scanner le code QR pour obtenir notre Notice d’Utilisation en
ligne ou notre Guide d’Installation Rapide et suivez les instructions pour
compléter la conguration
ES
Escanee el código QR para encontrar el Manual del Usuario en línea o
la Guía de Instalación Rápida y siga las instrucciones para completar la
conguración.
IT Scansiona il codice QR per consultare online il Manu ale utente o la Guida di
installazione rapida e segui le istruzioni per completare la congurazione.
PT Por favor, escaneie o QR code para navegar no Manual do Usuário ou Guia
de Instalação Rápida. Siga as instruções para completar a conguração.
PL
Zeskanuj kod QR, aby otworzyć naszą internetową instrukcję obsługi
lub instrukcję szybkiej instalacji. Postępuj zgodnie z instrukcjami, aby
zakończyć poprawną kongurację.
RU
One word modify: Отсканируйте QR-код, чтобы просмотреть наше
онлайн-руководство пользователя или руководство по быстрой
настройке, и следуйте ин струкциям для завершения настройки
RO Te rugam sa scanezi codul QR, pentru a descarca User’s Manual sau Quick
Installation Guide si a urmari instructiunile necesare in nalizarea instalarii
AR
Need more help?
PLANET onlin e FAQs:
http://www.planet.com.tw/en/support/faq
Technical Support: support@planet.com.tw
Copyr ight © PLANET Technolo gy Corp. 2023.
Contents are subjec t to r evision without prio r no tice.
PLANET is a re gistered tradem ark of PLANET Techno logy Corp.
All o ther trad emark s belong to their resp ective owners .
Part No. 236 0-AH0810 -000
DIN-rail Kit x 1 RJ45 Dust Caps x 8 x 6 /SFP Dust Caps x 2 pcs
IGS-800T x 8
IGS-820TF x 6
IGS-820TF only
If any of these are missing or damaged, please contact your dealer immediately;
if possible, retain the carton including the original packing material, and use them
again to repack the product in case there is a need to return it to us for repair.
