Sida 1/22
PORTACOOL
JETSTREAM
OWNER’S
MANUAL
PACJS220, PACJS230,
PACJS250, PACJS260,
PACJS270
Remove box and pallet Position cooler on level surface Plug into appropriate outlet
Fill tank or attach water hose*
Fill the tank, then turn on the pump switch and the fan
For setup, Kuul® evaporative media should appear
wet before starting the fan. Check the water gauge to
monitor water level in tank. The water adjustment valve
on each portable evaporative cooler is set at max ow.
However, ensure the knob is turned completely to the
right before use. Turn to the left to increase water ow.
If entrainment occurs - water is spitting from the front
of the product - use the valve to decrease the water ow
until entrainment ceases.
2 4
5
1 3
QUICK SETUP
Ensure proper airflow is available
Your Portacool portable evaporative cooler can be used
in an open-air environment, such as a sports venue or
outdoor jobsite. Your evaporative cooler can also be
used in a semi-closed environment – such as a garage,
warehouse or factory – but you must provide adequate
ambient airow to ensure your evaporative cooler
works at its highest efciency. When using in a semi-
closed environment, be sure to leave a door or window
open to allow for the proper amount of airow.
6
*Maximum water pressure 50 psi/345 kPa
SAFETY
OPERATION WARNINGS
SAFE OPERATION
1) Not for use by children
2) Not for use by persons with reduced physical, sensory or mental capabilities
3) Not for use by persons who have not reviewed the owner’s manual and familiarized themselves with the operation of the product.
To reduce the risk of electric shock, re or injury:
• Do not operate any evaporative cooler with a damaged cord
or plug.
• Do not run power cord under carpeting or cover with
throwrugs, runners or similar coverings. Arrange power cord
away from trafc areas to avoid tripping hazards.
• Read the evaporative cooler’s instructions, owner’s manual
and labels throughly before use.
• Always unplug the power cord to the evaporative cooler
before performing inspections or repairs.
• Always unplug the evaporative cooler during lling and
cleaning.
• Do not step on or roll over power cord with heavy or sharp
objects.
• Do not operate evaporative cooler unless all Kuul
®
evaporative media is securely in place.
• Test the GFCI receptacle or breaker monthly to ensure it is
functioning properly if applicable.
• Remove the plug from the electrical receptacle by pulling on
the plug, not the power cord.
• Operation near open flames or sparks is not recommended.
• If operating near open flame or sparks, ensure the pump
is continuously running in order to saturate and wet Kuul
evaporative media.
• When cleaning your evaporative cooler, ensure water does
not get into the motor or electrical system to prevent
damage.
• The use of extension cords with your evaporative cooler is
not recommended. However, if the owner determines that
his or her circumstance or intended use requires the use of
an extension cord, the following requirements must be met:
- Use properly grounded 14 AWG or greater for
PACJS220-260
- Use properly grounded 12 AWG or greater for PACJS270
- Extension cord must not exceed 50 feet (15.24 meters) in
length; and
- Extension cord must be properly grounded
• Evaporative coolers should not be modified in any way
(other than repairs made by qualified individuals with
Portacool replacement parts).
• If the evaporative cooler is damaged or malfunctions,
do not continue to operate it. Refer to the warranty,
troubleshooting or FAQ sections of this owner’s manual, call
Portacool, LLC
Customer Service
at (936) 598-5651 or
(800) 695-2942, or email support@portacool.com.
Control panel
Water
adjustment valve
Liquid Level Indicator
Power cord
with GFCI*
Cord wrap
Heavy duty
casters
PACJS220
Hose connection
Manual water fill
OVERVIEW
Two inch drain
on bottom
Serial plate
Oscillating louvers
Kuul® Comfort
MicroTech
evaporative media
*Products not sold in North America or
products with 220/50 volt requirements will
not have a GFCI/ELCI.
Control panel
Water
adjustment valve
Liquid Level Indicator
Manual water fill
Power cord
with GFCI*
Cord wrap
Heavy duty casters
PACJS230
Hose connection
Kuul®
Comfort MicroTech
evaporative media
OVERVIEW
Two inch drain
on bottom
Serial plate
Oscillating louvers
*Products not sold in North America or
products with 220/50 volt requirements will
not have a GFCI/ELCI.
Control panel
Water
adjustment valve
Liquid Level Indicator
Manual water fill Power cord
with GFCI*
Cord wrap
Heavy duty casters
PACJS250
Hose connection
Kuul® Comfort
evaporative media
OVERVIEW
Two inch drain
on bottom
Serial plate
*Products not sold in North America or
products with 220/50 volt requirements will
not have a GFCI/ELCI.
OVERVIEW
Control panel
Water
adjustment valve
Liquid Level Indicator
Manual water fill
Hose connection
Cord wrap
Heavy duty casters
PACJS260
Power cord
with GFCI*
Kuul® Comfort
evaporative media
Two inch drain
on bottom
Serial plate
*Products not sold in North America or
products with 220/50 volt requirements will
not have a GFCI/ELCI.
The Portacool Jetstream™ series utilizes a GFCI (Grounded Fault Circuit Interrupter) or ELCI (Equipment Leakage Circuit
Interrupter) to help protect users against ground electrical faults, which prevent some fire and electrical shock hazards. These
devices are intended to trip at very low leakage currents.
• Portacool Jetstream models PACJS220, PACJS230, PACJS250 and PACJS260 use a GFCI, which is built into the power cord
• Portacool Jetstream model PACJS270 uses an ELCI, which is built into the power cord and requires a 5-20R (120V) electrical
outlet
The GFCI on models PACJS220, PACJS230, PACJS250 and PACJS260 will automatically reset when the evaporative cooler is plugged
into an electrical outlet. The ELCI on model PACJS270 will not automatically reset when the evaporative cooler is plugged into an
electrical outlet; the “reset” button located on the ELCI device must be pressed each time the evaporative cooler is plugged in.
If the GFCI is tripped and a simple “reset” will not work, please contact the Portacool Customer Service at (936) 598-5651 or
(800) 695-2942 for more troubleshooting information.
*Products not sold in North America or products with 220/50 volt requirements will not have a GFCI/ELCI.
GFCI/ELCI*
PLACEMENT
1) Make sure there is a clear, unobstructed path in front of the evaporative cooler to provide maximum airflow.
2) If the evaporative cooler is positioned on a raised platform, ensure the platform is stable, well constructed, and will not allow
the evaporative cooler to tip over and that it allows for the full weight of the evaporative cooler including a tank full of water. The
cooler must be level and in the upright position. The casters should also be locked to prevent the evaporative cooler from moving.
3) If placed near a wall or other obstruction, position the evaporative cooler a minimum of 3 feet (0.9 meters) from the wall or
obstruction with evaporative media facing the wall. This allows the unrestricted flow of warm air to the Kuul
ComfortTM
evaporative
media side of the evaporative cooler. When using multiple evaporative coolers in close proximity, be sure to aim each evaporative
cooler so the air flows complement each other to achieve maximum cooling capacity.
STARTING THE PUMP AND ADJUSTING THE WATER FLOW
Once the tank is full of water, moving the pump switch to the “ON” position on the control panel will turn on the pump. When initially turning
on the pump, the level in the water tank will drop suddenly and restart the flow of supply water. This is a normal condition, as the
evaporative
media requires a large amount of water for proper wetting.
New Kuul ComfortTM evaporative media will require an initial ‘breaking-in’ period. This period is required for the media to begin readily absorbing
water. It may require up to a week to achieve maximum efficiency.
It is important to ensure that the water flow to the
evaporative
media is properly adjusted when first starting the water flow in the evaporative
cooler. Increasing the flow using the water adjustment valve makes this adjustment. Proper water adjustment should leave the
evaporative
media saturated with water, but not flooded.
Evaporative m
edia should appear wet.
When turning the evaporative cooler off at the end of the day or week, the pump should be turned off about 15 minutes before the fan to allow
the Kuul evaporative media to dry.
STARTING THE PORTACOOL EVAPORATIVE COOLER
Start the fan by turning the fan switch to the desired speed on the control panel. Before starting, make sure casters are in locked position.
START UP
MAINTENANCE
ORDER PARTS
ONLINE
portacoolparts.com
While the rugged, corrosion-resistant construction ensures low maintenance will be required, keeping your evaporative cooler clean
will ensure it stays in peak operating condition.
DAILY MAINTENANCE
The pump should be turned off approximately 15 minutes before the fan is turned off, which allows the Kuul
® evaporative media to
dry. Ensuring your Kuul evaporative media is dry at the end of the day not only extends its life, it also helps control the growth of
mildew, mold, bacteria and other odor-causing elements.
WEEKLY MAINTENANCE
Your Portacool portable evaporative cooler should be shut down, disconnected from power and the tank should be drained once
a week by removing the drain cap. Once the tank is drained and the power disconnected, the Kuul evaporative media may be
removed to allow cleaning of the tank, where dust may collect over time. Replace Kuul evaporative media in correct airflow
direction, referring to the label on the Kuul evaporative media.
If conditions, such as hard water, warrant, Portacool Hard Water Treatment™ can be purchased at www.portacoolparts.com or
from authorized distributors. Portacool Hard Water Treatment keeps minerals present in your water in solution and off of your
Kuul evaporative media by changing the ionic structure of the particles. It can increase cooling efficiency, remove and inhibit scale
building up, reduce equipment corrosion, and extend evaporative media life.
STORAGE
1. Drain all water from the tank and wipe the tank clean, ensuring the Kuul evaporative media and tank are dry.
2. Roll up the power cord and secure it to ensure it will not be rolled over, tripped over or caught in equipment.
3. Cover the evaporative cooler completely to prevent dust build-up and store in a dry area. This also
helps to prevent damage to the Kuul evaporative media. Optional protective covers are available from
your distributor or at www.portacoolparts.com.
