2D Barcode for

HS/EK/TK/JK/HK Series

(SE4107 Scanner Engine)

Advanced Manual

Version: A0

REVISION HISTORY

Date

Version

Description

2021/07/27

For preliminary release


i

CONTENTS
REVISION HISTORY ........................................................................................................... 3
CONTENTS ..............................................................................................................................i
CHAPTER 1: GETTING STARTED .................................................................................... - 15 -
1.1 Introduction ............................................................................................................... - 15 -
1.2 Block Diagram .......................................................................................................... - 15 -
1.3 Theory of Operation .................................................................................................. - 16 -
1.4 Application Processor ................................................................................................ - 16 -
1.5 Power Management ................................................................................................... - 16 -
USB (SNAPI, USB HID Keyboard, Etc.) .......................................................................... - 16 -
SSI or RS-232 ................................................................................................................ - 17 -
1.6 Interfaces ................................................................................................................... - 17 -
Default Power Mode ................................................................................................... - 17 -
1.7 Beeper and Decode LED Signals from the SE4107 .................................................. - 18 -
1.8 Supported Symbologies ............................................................................................. - 19 -
1.9 Operating Modes ....................................................................................................... - 21 -
CHAPTER 2: 123SCAN AND SOFTWARE TOOLS ........................................................ - 22 -
2.1 Introduction ............................................................................................................... - 22 -
2.2 123Scan ..................................................................................................................... - 22 -
2.3 Communication with 123Scan .................................................................................. - 23 -
2.4 123Scan Requirements .............................................................................................. - 23 -
2.5 123Scan Information .................................................................. 錯誤!  尚未定義書籤。
2.6 Decoder SDK, Other Software Tools, and Videos .................................................... - 23 -
CHAPTER 3: USER PREFERENCES & MISCELLANEOUS OPTIONS ........................... - 25 -
3.1 Introduction ............................................................................................................... - 25 -
3.2 Changing Default Values .......................................................................................... - 25 -

Produktspecifikationer

Varumärke:	Posiflex
Kategori:	Låda
Modell:	HS-3512W
Vikt:	5300 g
Bredd:	297 mm
Djup:	198 mm
Höjd:	473 mm
Skärm diagonal:	12 "
Upplösning:	1024 x 768 pixlar
Pekskärm:	Ja
Processorfrekvens:	2 GHz
Processorfamilj:	Intel® Celeron®
Typ av lagringsmedia:	HDD, SSD
Processor:	J1900
Processorns cache:	2 MB
Maximalt internminne:	8 GB
Antal minnesplatser:	1
Produktens färg:	Svart
Skärmtyp:	LCD
Windows-operativsystem som stöds:	Windows 10, Windows 7, Windows 8.1
Tillverkare av grafikadapter:	Intel
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 50 ° C
Intervall för relativ operativ luftfuktighet:	0 - 40 %
Fuktighet (förvaring):	20 - 90 %
Seriella portar:	3
Typ av internminne:	DDR3L-SDRAM
Antal PS/2-portar:	1
Nätverksansluten (Ethernet):	Ja
Linje ut:	Ja
Antal USB 2.0 anslutningar:	4
Minnesplatser, typ:	SO-DIMM
Video adapter:	HD Graphics
Processorkärnor:	4
Kvalitet på VGA (D-Sub) porten:	1
Processortrådar:	4
Hårddiskens gränssnitt:	SATA
Parallellport:	1
Chassityp:	Allt-i-ett
